AIM

4/20/23



10

1

4

Helicopter IFR Operations

TBL 10

1

1

Helicopter Use of Standard Instrument Approach Procedures

Procedure

Helicopter Visibility

Minima

Helicopter MDA/DA

Maximum Speed Limitations

Conventional
(non

Copter)

The greater of: one half
the Category A visibility
minima,

1

/

4

 statute mile

visibility, or 1200 RVR

As published for
Category A

The helicopter may initiate the final
approach segment at speeds up to
the upper limit of the highest
approach category authorized by the
procedure, but must be slowed to no
more than 90 KIAS at the MAP in
order to apply the visibility
reduction.

Copter Procedure

As published

As published

90 KIAS maximum when on a
published route/track.

RNAV (GPS) Copter
Procedure

As published

As published

The maximum speed for a Copter
approach will be 90 KIAS or as
published on the chart. Note: Higher
approach angles may require a
lower approach speed and aircraft
V

MINI

. Military procedures are

limited to 90 KIAS for all segments.

NOTE

Several factors affect the ability of the pilot to acquire and maintain the visual references specified in 14 CFR
Section 91.175(c), even in cases where the flight visibility may be at the minimum derived from the criteria in TBL 10

1

1.

These factors include, but are not limited to:

1.

Cockpit cutoff angle (the angle at which the cockpit or other airframe structure limits downward visibility below the

horizon).

2.

Combinations of high MDA/DH and low visibility minimum, such as approaches with reduced helicopter visibility

minima (per 14 CFR Section 97.3).

3.

Type, configuration, and intensity of approach and runway/heliport lighting systems.

4.

Type of obscuring phenomenon and/or windshield contamination.

10

1

3. Helicopter Approach Procedures to VFR Heliports

a.

The FAA may develop helicopter instrument approaches for heliports that do not meet the design standards

for an IFR heliport. The majority of IFR approaches to VFR heliports are developed in support of Helicopter Air
Ambulance (HAA) operators. These approaches may require use of conventional NAVAIDS or a RNAV system
(e.g., GPS). They may be developed either as a special approach (pilot training is required for special procedures
due to their unique characteristics) or a public approach (no special training required). These instrument
procedures may be designed to guide the helicopter to a specific landing area (Proceed Visually) or to a
point

in

space with a “Proceed VFR” segment.

1. An approach to a specific landing area.

 This type of approach is aligned to a missed approach point

from which a landing can be accomplished with a maximum course change of 30 degrees. The visual segment
from the MAP to the landing area is evaluated for obstacle hazards. These procedures are annotated: “PROCEED
VISUALLY FROM (named MAP) OR CONDUCT THE SPECIFIED MISSED APPROACH.”

(a)

“Proceed Visually” requires the pilot to acquire and maintain visual contact with the landing area at

or prior to the MAP, or execute a missed approach. The visibility minimum is based on the distance from the MAP
to the landing area, among other factors.

(b)

The pilot is required to have the published minimum visibility throughout the visual segment flying

the path described on the approach chart.

(c)

Similar to an approach to a runway, the pilot is responsible for obstacle or terrain avoidance from the

MAP to the landing area.
