152

14 CFR Ch. I (1–1–24 Edition)

§ 121.355

warning system audio and visual warn-
ings.

[Doc. No. 29312, 65 FR 16755, Mar. 29, 2000]

§ 121.355 Equipment for operations on

which specialized means of naviga-
tion are used.

(a) No certificate holder may conduct

an operation—

(1) Using Doppler Radar or an Iner-

tial Navigation System outside the 48
contiguous States and the District of
Columbia, unless such systems have
been approved in accordance with ap-
pendix G to this part; or

(2) Using Doppler Radar or an Iner-

tial Navigation System within the 48
contiguous States and the District of
Columbia, or any other specialized
means of navigation, unless it shows
that an adequate airborne system is
provided for the specialized navigation
authorized for the particular operation.

(b) Notwithstanding paragraph (a) of

this section, Doppler Radar and Iner-
tial Navigation Systems, and the train-
ing programs, maintenance programs,
relevant operations manual material,
and minimum equipment lists prepared
in accordance therewith, approved be-
fore April 29, 1972, are not required to
be approved in accordance with that
paragraph.

[Doc. No. 10204, 37 FR 6464, Mar. 30, 1972]

§ 121.356 Collision avoidance system.

Effective January 1, 2005, any air-

plane you operate under this part must
be equipped and operated according to
the following table:

C

OLLISION

A

VOIDANCE

S

YSTEMS



If you operate any—

Then you must operate that airplane

with—

(a) Turbine-powered

airplane of more
than 33,000
pounds maximum
certificated take-
off weight.

(1) An appropriate class of Mode S

transponder that meets Technical
Standard Order (TSO) C–112, or a
later version, and one of the fol-
lowing approved units:

(i) TCAS II that meets TSO C–119b

(version 7.0), or takeoff weight a
later version.

C

OLLISION

A

VOIDANCE

S

YSTEMS

—Continued

If you operate any—

Then you must operate that airplane

with—

(ii) TCAS II that meets TSO C–119a

(version 6.04A Enhanced) that was
installed in that airplane before May
1, 2003. If that TCAS II version
6.04A Enhanced no longer can be
repaired to TSO C–119a standards,
it must be replaced with a TCAS II
that meets TSO C–119b (version
7.0), or a later version.

(iii) A collision avoidance system equiv-

alent to TSO C–119b (version 7.0),
or a later version, capable of coordi-
nating with units that meet TSO C–
119a (version 6.04A Enhanced), or a
later version.

(b) Passenger or

combination
cargo/passenger
(combi) airplane
that has a pas-
senger seat con-
figuration of 10–
30 seats.

(1) TCAS I that meets TSO C–118, or

a later version, or

(2) A collision avoidance system equiv-

alent to has a TSO C–118, or a later
version, or

(3) A collision avoidance system and

Mode S transponder that meet para-
graph (a)(1) of this section.

(c) Piston-powered

airplane of more
than 33,000
pounds maximum
certificated take-
off weight.

(1) TCAS I that meets TSO C–118, or

a later version, or

(2) A collision avoidance system equiv-

alent to maximum TSO C–118, or a
later version, or

(3) A collision avoidance system and

Mode S transponder that meet para-
graph (a)(1) of this section.

[Doc. No. FAA–2001–10910, 68 FR 15902, Apr. 1,
2003]

§ 121.357 Airborne weather radar

equipment requirements.

(a) No person may operate any trans-

port category airplane (except C–46
type airplanes) or a nontransport cat-
egory airplane certificated after De-
cember 31, 1964, unless approved air-
borne weather radar equipment has
been installed in the airplane.

(b) [Reserved]
(c) Each person operating an airplane

required to have approved airborne
weather radar equipment installed
shall, when using it under this part, op-
erate it in accordance with the fol-
lowing:

(1)

Dispatch.

No person may dispatch

an airplane (or begin the flight of an
airplane in the case of a certificate
holder, that does not use a dispatch
system) under IFR or night VFR condi-
tions when current weather reports in-
dicate that thunderstorms, or other po-
tentially hazardous weather conditions
that can be detected with airborne

153

Federal Aviation Administration, DOT

§ 121.358

weather radar, may reasonably be ex-
pected along the route to be flown, un-
less the airborne weather radar equip-
ment is in satisfactory operating con-
dition.

(2) If the airborne weather radar be-

comes inoperative en route, the air-
plane must be operated in accordance
with the approved instructions and
procedures specified in the operations
manual for such an event.

(d) This section does not apply to air-

planes used solely within the State of
Hawaii or within the State of Alaska
and that part of Canada west of lon-
gitude 130 degrees W, between latitude
70 degrees N, and latitude 53 degrees N,
or during any training, test, or ferry
flight.

(e) Notwithstanding any other provi-

sion of this chapter, an alternate elec-
trical power supply is not required for
airborne weather radar equipment.

[Doc. No. 6258, 29 FR 19205, Dec. 31, 1964, as
amended by Amdt. 121–18, 31 FR 5825, Apr. 15,
1966; Amdt. 121–130, 41 FR 47229, Oct. 28, 1976;
Amdt. 121–251, 60 FR 65932, Dec. 20, 1995]

§ 121.358 Low-altitude windshear sys-

tem equipment requirements.

(a)

Airplanes manufactured after Janu-

ary 2, 1991.

No person may operate a

turbine-powered airplane manufac-
tured after January 2, 1991, unless it is
equipped with either an approved air-
borne windshear warning and flight
guidance system, an approved airborne
detection and avoidance system, or an
approved combination of these sys-
tems.

(b)

Airplanes manufactured before Jan-

uary 3, 1991.

Except as provided in para-

graph (c) of this section, after January
2, 1991, no person may operate a tur-
bine-powered airplane manufactured
before January 3, 1991 unless it meets
one of the following requirements as
applicable.

(1) The makes/models/series listed

below must be equipped with either an
approved airborne windshear warning
and flight guidance system, an ap-
proved airborne detection and avoid-
ance system, or an approved combina-
tion of these systems:

(i) A–300–600;
(ii) A–310—all series;
(iii) A–320—all series;
(iv) B–737–300, 400, and 500 series;

(v) B–747–400;
(vi) B–757—all series;
(vii) B–767—all series;
(viii) F–100—all series;
(ix) MD–11—all series; and
(x) MD–80 series equipped with an

EFIS and Honeywell-970 digital flight
guidance computer.

(2) All other turbine-powered air-

planes not listed above must be
equipped with as a minimum require-
ment, an approved airborne windshear
warning system. These airplanes may
be equipped with an approved airborne
windshear detection and avoidance sys-
tem, or an approved combination of
these systems.

(c)

Extension of the compliance date.

A

certificate holder may obtain an exten-
sion of the compliance date in para-
graph (b) of this section if it obtains
FAA approval of a retrofit schedule. To
obtain approval of a retrofit schedule
and show continued compliance with
that schedule, a certificate holder must
do the following:

(1) Submit a request for approval of a

retrofit schedule by June 1, 1990, to the
appropriate Flight Standards division
manager in the responsible Flight
Standards office.

(2) Show that all of the certificate

holder’s airplanes required to be
equipped in accordance with this sec-
tion will be equipped by the final com-
pliance date established for TCAS II
retrofit.

(3) Comply with its retrofit schedule

and submit status reports containing
information acceptable to the Adminis-
trator. The initial report must be sub-
mitted by January 2, 1991, and subse-
quent reports must be submitted every
six months thereafter until completion
of the schedule. The reports must be
submitted to the certificate holder’s
assigned Principal Avionics Inspector.

(d)

Definitions.

For the purposes of

this section the following definitions
apply—

(1)

Turbine-powered airplane

includes,

e.g., turbofan-, turbojet-, propfan-, and
ultra-high bypass fan-powered air-
planes. The definition specifically ex-
cludes turbopropeller-powered air-
planes.
