350

14 CFR Ch. I (1–1–24 Edition)

§ 125.224

route, the airplane must be operated
under the instructions and procedures
specified for that event in the manual
required by § 125.71.

(d) This section does not apply to air-

planes used solely within the State of
Hawaii, within the State of Alaska,
within that part of Canada west of lon-
gitude 130 degrees W, between latitude
70 degrees N, and latitude 53 degrees N,
or during any training, test, or ferry
flight.

(e) Without regard to any other pro-

vision of this part, an alternate elec-
trical power supply is not required for
airborne weather radar equipment.

§ 125.224 Collision avoidance system.

Effective January 1, 2005, any air-

plane you operate under this part 125
must be equipped and operated accord-
ing to the following table:

C

OLLISION

A

VOIDANCE

S

YSTEMS



If you operate any

. . .

Then you must operate that airplane

with:

(a) Turbine-powered

airplane of more
than 33,000
pounds maximum
certificated take-
off weight.

(1) An appropriate class of Mode S

transponder that meets Technical
Standard Order (TSO) C–112, or a
later version, and one of the fol-
lowing approved units:

(i) TCAS II that meets TSO C–119b

(version 7.0), or a later version.

(ii) TCAS II that meets TSO C–119a

(version 6.04A Enhanced) that was
installed in that airplane before May
1, 2003. If that TCAS II version
6.04A Enhanced no longer can be
repaired to TSO C–119a standards,
it must be replaced with a TCAS II
that meets TSO C–119b (version
7.0), or a later version.

(iii) A collision avoidance system equiv-

alent to TSO C–119b (version 7.0),
or a later version, capable of coordi-
nating with units that meet TSO C–
119a (version 6.04A Enhanced), or a
later version.

(b) Piston-powered

airplane of more
than 33,000
pounds maximum
certificated take-
off weight.

(1) TCAS I that meets TSO C–118, or

a later version, or

(2) A collision avoidance system equiv-

alent to TSO C–118, or a later
version, or

(1)(3) A collision avoidance system and

Mode S transponder that meet para-
graph (a)(1) of this section.

[Doc. No. FAA–2001–10910, 68 FR 15903, Apr. 1,
2003]

§ 125.225 Flight data recorders.

(a) Except as provided in paragraph

(d) of this section, after October 11,
1991, no person may operate a large air-
plane type certificated before October

1, 1969, for operations above 25,000 feet
altitude, nor a multiengine, turbine
powered airplane type certificated be-
fore October 1, 1969, unless it is
equipped with one or more approved
flight recorders that utilize a digital
method of recording and storing data
and a method of readily retrieving that
data from the storage medium. The fol-
lowing information must be able to be
determined within the ranges, accura-
cies, resolution, and recording inter-
vals specified in appendix D of this
part:

(1) Time;
(2) Altitude;
(3) Airspeed;
(4) Vertical acceleration;
(5) Heading;
(6) Time of each radio transmission

to or from air traffic control;

(7) Pitch attitude;
(8) Roll attitude;
(9) Longitudinal acceleration;
(10) Control column or pitch control

surface position; and

(11) Thrust of each engine.
(b) Except as provided in paragraph

(d) of this section, after October 11,
1991, no person may operate a large air-
plane type certificated after September
30, 1969, for operations above 25,000 feet
altitude, nor a multiengine, turbine
powered airplane type certificated
after September 30, 1969, unless it is
equipped with one or more approved
flight recorders that utilize a digital
method of recording and storing data
and a method of readily retrieving that
data from the storage medium. The fol-
lowing information must be able to be
determined within the ranges, accura-
cies, resolutions, and recording inter-
vals specified in appendix D of this
part:

(1) Time;
(2) Altitude;
(3) Airspeed;
(4) Vertical acceleration;
(5) Heading;
(6) Time of each radio transmission

either to or from air traffic control;

(7) Pitch attitude;
(8) Roll attitude;
(9) Longitudinal acceleration;
(10) Pitch trim position;
(11) Control column or pitch control

surface position;

351

Federal Aviation Administration, DOT

§ 125.225

(12) Control wheel or lateral control

surface position;

(13) Rudder pedal or yaw control sur-

face position;

(14) Thrust of each engine;
(15) Position of each trust reverser;
(16) Trailing edge flap or cockpit flap

control position; and

(17) Leading edge flap or cockpit flap

control position.

(c) After October 11, 1991, no person

may operate a large airplane equipped
with a digital data bus and ARINC 717
digital flight data acquisition unit
(DFDAU) or equivalent unless it is
equipped with one or more approved
flight recorders that utilize a digital
method of recording and storing data
and a method of readily retrieving that
data from the storage medium. Any pa-
rameters specified in appendix D of
this part that are available on the dig-
ital data bus must be recorded within
the ranges, accuracies, resolutions, and
sampling intervals specified.

(d) No person may operate under this

part an airplane that is manufactured
after October 11, 1991, unless it is
equipped with one or more approved
flight recorders that utilize a digital
method of recording and storing data
and a method of readily retrieving that
data from the storage medium. The pa-
rameters specified in appendix D of
this part must be recorded within the
ranges, accuracies, resolutions and
sampling intervals specified. For the
purpose of this section, ‘‘manufac-
tured’’ means the point in time at
which the airplane inspection accept-
ance records reflect that the airplane is
complete and meets the FAA-approved
type design data.

(e) Whenever a flight recorder re-

quired by this section is installed, it
must be operated continuously from
the instant the airplane begins the
takeoff roll until it has completed the
landing roll at an airport.

(f) Except as provided in paragraph

(g) of this section, and except for re-
corded data erased as authorized in
this paragraph, each certificate holder
shall keep the recorded data prescribed
in paragraph (a), (b), (c), or (d) of this
section, as applicable, until the air-
plane has been operated for at least 25
hours of the operating time specified in
§ 125.227(a) of this chapter. A total of 1

hour of recorded data may be erased for
the purpose of testing the flight re-
corder or the flight recorder system.
Any erasure made in accordance with
this paragraph must be of the oldest re-
corded data accumulated at the time of
testing. Except as provided in para-
graph (g) of this section, no record need
be kept more than 60 days.

(g) In the event of an accident or oc-

currence that requires immediate noti-
fication of the National Transportation
Safety Board under 49 CFR part 830 and
that results in termination of the
flight, the certificate holder shall re-
move the recording media from the air-
plane and keep the recorded data re-
quired by paragraph (a), (b), (c), or (d)
of this section, as applicable, for at
least 60 days or for a longer period
upon the request of the Board or the
Administrator.

(h) Each flight recorder required by

this section must be installed in ac-
cordance with the requirements of
§ 25.1459 of this chapter in effect on Au-
gust 31, 1977. The correlation required
by § 25.1459(c) of this chapter need be
established only on one airplane of any
group of airplanes.

(1) That are of the same type;
(2) On which the flight recorder mod-

els and their installations are the
same; and

(3) On which there are no differences

in the type design with respect to the
installation of the first pilot’s instru-
ments associated with the flight re-
corder. The most recent instrument
calibration, including the recording
medium from which this calibration is
derived, and the recorder correlation
must be retained by the certificate
holder.

(i) Each flight recorder required by

this section that records the data spec-
ified in paragraphs (a), (b), (c), or (d) of
this section must have an approved de-
vice to assist in locating that recorder
under water.

(j) After August 20, 2001, this section

applies only to the airplane models
listed in § 125.226(l)(2). All other air-
planes must comply with the require-
ments of § 125.226.

[Doc. No. 25530, 53 FR 26148, July 11, 1988; 53
FR 30906, Aug. 16, 1988; Amdt. 125–54, 73 FR
12568, Mar. 7, 2008]
