353

Federal Aviation Administration, DOT

§ 25.1397

the minimum intensity prescribed in
§ 25.1391 for the corresponding angles in
the horizontal plane.

(3)

Intensities in overlaps between adja-

cent signals. No intensity in any over-
lap between adjacent signals may ex-
ceed the values given in § 25.1395, except
that higher intensities in overlaps may
be used with main beam intensities
substantially greater than the minima
specified in §§ 25.1391 and 25.1393 if the
overlap intensities in relation to the
main beam intensities do not adversely
affect signal clarity. When the peak in-
tensity of the forward position lights is
more than 100 candles, the maximum
overlap intensities between them may
exceed the values given in § 25.1395 if
the overlap intensity in Area A is not
more than 10 percent of peak position
light intensity and the overlap inten-
sity in Area B is not greater than 2.5
percent of peak position light inten-
sity.

§ 25.1391

Minimum intensities in the

horizontal plane of forward and
rear position lights.

Each position light intensity must

equal or exceed the applicable values in
the following table:

Dihedral angle (light in-

cluded)

Angle from right

or left of longitu-

dinal axis, meas-

ured from dead

ahead

Intensity

(candles)

and (forward red and

green).

0

°

to 10

°

..............

10

°

to 20

°

............

20

°

to 110

°

..........

40
30

A (rear white) .....................

110

°

to 180

°

........

20

§ 25.1393

Minimum intensities in any

vertical plane of forward and rear
position lights.

Each position light intensity must

equal or exceed the applicable values in
the following table:

Angle above or below the horizontal plane

Intensity,

0

°

.........................................................................

1.00

0

°

to 5

°

................................................................

0.90

5

°

to 10

°

..............................................................

0.80

10

°

to 15

°

............................................................

0.70

15

°

to 20

°

............................................................

0.50

20

°

to 30

°

............................................................

0.30

30

°

to 40

°

............................................................

0.10

40

°

to 90

°

............................................................

0.05

§ 25.1395

Maximum intensities in over-

lapping beams of forward and rear
position lights.

No position light intensity may ex-

ceed the applicable values in the fol-
lowing table, except as provided in
§ 25.1389(b)(3).

Overlaps

Maximum intensity

Area A

(candles)

Area B

(candles)

Green in dihedral angle .............

10 1

Red in dihedral angle ................

10 1

Green in dihedral angle .............

5 1

Red in dihedral angle ................

5 1

Rear white in dihedral angle ......

5 1

Rear white in dihedral angle .....

5 1

Where—

(a) Area A includes all directions in

the adjacent dihedral angle that pass
through the light source and intersect
the common boundary plane at more
than 10 degrees but less than 20 de-
grees; and

(b) Area B includes all directions in

the adjacent dihedral angle that pass
through the light source and intersect
the common boundary plane at more
than 20 degrees.

§ 25.1397

Color specifications.

Each position light color must have

the applicable International Commis-
sion on Illumination chromaticity co-
ordinates as follows:

(a)

Aviation red—

is not greater than 0.335; and
is not greater than 0.002.

(b)

Aviation green—

is not greater than 0.440

¥

0.320

is not greater than y

¥

0.170; and

is not less than 0.390

¥

0.170

x

(c)

Aviation white—

x  is not less than 0.300 and not greater than

0.540;

is not less than x

¥

0.040; or

y

0

¥

0.010, which-

ever is the smaller; and

y  is not greater than x  + 0.020 nor

0.636

¥

0.400

x

Where

y

0

is the

coordinate of the Planckian

radiator for the value of

considered.

[Doc. No. 5066, 29 FR 18291, Dec. 24, 1964, as
amended by Amdt. 25–27, 36 FR 12972, July 10,
1971]
