(1) For jacking by the landing gear at

the maximum ramp weight of the air-
plane, the airplane structure must be
designed for a vertical load of 1.33
times the vertical static reaction at
each jacking point acting singly and in
combination with a horizontal load of
0.33 times the vertical static reaction
applied in any direction.

(2) For jacking by other airplane

structure at maximum approved jack-
ing weight:

(i) The airplane structure must be de-

signed for a vertical load of 1.33 times
the vertical reaction at each jacking
point acting singly and in combination
with a horizontal load of 0.33 times the
vertical static reaction applied in any
direction.

(ii) The jacking pads and local struc-

ture must be designed for a vertical
load of 2.0 times the vertical static re-
action at each jacking point, acting
singly and in combination with a hori-
zontal load of 0.33 times the vertical
static reaction applied in any direc-
tion.

(c) Tie-down. If tie-down points are

provided, the main tie-down points and
local structure must withstand the
limit loads resulting from a 65-knot
horizontal wind from any direction.

[Doc. No. 26129, 59 FR 22102, Apr. 28, 1994]

W

ATER

L

OADS



§ 25.521

General.

(a) Seaplanes must be designed for

the water loads developed during take-
off and landing, with the seaplane in
any attitude likely to occur in normal
operation, and at the appropriate for-
ward and sinking velocities under the
most severe sea conditions likely to be
encountered.

(b) Unless a more rational analysis of

the water loads is made, or the stand-
ards in ANC–3 are used, §§ 25.523
through 25.537 apply.

(c) The requirements of this section

and §§ 25.523 through 25.537 apply also to
amphibians.

§ 25.523

Design weights and center of

gravity positions.

(a)

Design weights. The water load re-

quirements must be met at each oper-
ating weight up to the design landing
weight except that, for the takeoff con-

dition prescribed in § 25.531, the design
water takeoff weight (the maximum
weight for water taxi and takeoff run)
must be used.

(b)

Center of gravity positions. The

critical centers of gravity within the
limits for which certification is re-
quested must be considered to reach
maximum design loads for each part of
the seaplane structure.

[Doc. No. 5066, 29 FR 18291, Dec. 24, 1964, as
amended by Amdt. 25–23, 35 FR 5673, Apr. 8,
1970]

§ 25.525

Application of loads.

(a) Unless otherwise prescribed, the

seaplane as a whole is assumed to be
subjected to the loads corresponding to
the load factors specified in § 25.527.

(b) In applying the loads resulting

from the load factors prescribed in
§ 25.527, the loads may be distributed
over the hull or main float bottom (in
order to avoid excessive local shear
loads and bending moments at the lo-
cation of water load application) using
pressures not less than those pre-
scribed in § 25.533(c).

(c) For twin float seaplanes, each

float must be treated as an equivalent
hull on a fictitious seaplane with a
weight equal to one-half the weight of
the twin float seaplane.

(d) Except in the takeoff condition of

§ 25.531, the aerodynamic lift on the
seaplane during the impact is assumed
to be

2

⁄

3

of the weight of the seaplane.

[Doc. No. 5066, 29 FR 18291, Dec. 24, 1964, as
amended by Doc. No. FAA–2022–1355, Amdt.
25–148, 87 FR 75710, Dec. 9, 2022; 88 FR 2813,
Jan. 18, 2023]

§ 25.527

Hull and main float load fac-

tors.

(a) Water reaction load factors

n

W



must be computed in the following
manner:

(1) For the step landing case

n

C V

W

w

S

=

⎛

⎝

⎞

⎠

1

0

2

2
3

1
3

Tan

β

(2) For the bow and stern landing

cases
