14 CFR Ch. I (1–1–24 Edition)

§ 33.78

T

ABLE

1—M

INIMUM

I

CE

S

LAB

D

IMENSIONS

B

ASED ON

E

NGINE

I

NLET

S

IZE



Engine Inlet Hilite area

(sq. inch)

Thickness

(inch)

Width
(inch)

Length

(inch)

0 .......................................................................................................................

0 .25 0

3.6

80 .....................................................................................................................

0 .25 6

3.6

300 ...................................................................................................................

0 .25 12 3.6

700 ...................................................................................................................

0 .25 12 4.8

2800 .................................................................................................................

0 .35 12 8.5

5000 .................................................................................................................

0 .43 12

11.0

7000 .................................................................................................................

0 .50 12

12.7

7900 .................................................................................................................

0 .50 12

13.4

9500 .................................................................................................................

0 .50 12

14.6

11300 ...............................................................................................................

0 .50 12

15.9

13300 ...............................................................................................................

0 .50 12

17.1

16500 ...............................................................................................................

0 .5 12

18.9

20000 ...............................................................................................................

0 .5 12

20.0

[Doc. No. 16919, 49 FR 6852, Feb. 23, 1984, as
amended by Amdt. 33–19, 63 FR 14798, Mar. 26,
1998; 63 FR 53278, Oct. 5, 1998; Amdt. 33–20, 65
FR 55856, Sept. 14, 2000; Amdt. 33–34, 79 FR
65537, Nov. 4, 2014]

§ 33.78

Rain and hail ingestion.

(a)

All engines. (1) The ingestion of

large hailstones (0.8 to 0.9 specific grav-
ity) at the maximum true air speed, up
to 15,000 feet (4,500 meters), associated
with a representative aircraft oper-
ating in rough air, with the engine at
maximum continuous power, may not
cause unacceptable mechanical damage
or unacceptable power or thrust loss
after the ingestion, or require the en-
gine to be shut down. One-half the
number of hailstones shall be aimed
randomly over the inlet face area and
the other half aimed at the critical
inlet face area. The hailstones shall be
ingested in a rapid sequence to simu-
late a hailstone encounter and the
number and size of the hailstones shall
be determined as follows:

(i) One 1-inch (25 millimeters) diame-

ter hailstone for engines with inlet
areas of not more than 100 square
inches (0.0645 square meters).

(ii) One 1-inch (25 millimeters) di-

ameter and one 2-inch (50 millimeters)
diameter hailstone for each 150 square
inches (0.0968 square meters) of inlet
area, or fraction thereof, for engines
with inlet areas of more than 100
square inches (0.0645 square meters).

(2) In addition to complying with

paragraph (a)(1) of this section and ex-
cept as provided in paragraph (b) of
this section, it must be shown that
each engine is capable of acceptable op-
eration throughout its specified oper-

ating envelope when subjected to sud-
den encounters with the certification
standard concentrations of rain and
hail, as defined in appendix B to this
part. Acceptable engine operation pre-
cludes flameout, run down, continued
or non-recoverable surge or stall, or
loss of acceleration and deceleration
capability, during any three minute
continuous period in rain and during
any 30 second continuous period in
hail. It must also be shown after the
ingestion that there is no unacceptable
mechanical damage, unacceptable
power or thrust loss, or other adverse
engine anomalies.

(b)

Engines for rotorcraft. As an alter-

native to the requirements specified in
paragraph (a)(2) of this section, for
rotorcraft turbine engines only, it
must be shown that each engine is ca-
pable of acceptable operation during
and after the ingestion of rain with an
overall ratio of water droplet flow to
airflow, by weight, with a uniform dis-
tribution at the inlet plane, of at least
four percent. Acceptable engine oper-
ation precludes flameout, run down,
continued or non-recoverable surge or
stall, or loss of acceleration and decel-
eration capability. It must also be
shown after the ingestion that there is
no unacceptable mechanical damage,
unacceptable power loss, or other ad-
verse engine anomalies. The rain inges-
tion must occur under the following
static ground level conditions:

(1) A normal stabilization period at

take-off power without rain ingestion,
followed immediately by the suddenly
commencing ingestion of rain for three
minutes at takeoff power, then

VerDate Sep<11>2014

09:06 Jun 28, 2024

Jkt 262046

PO 00000

Frm 00736

Fmt 8010

Sfmt 8010

Y:\SGML\262046.XXX

262046

jspears on DSK121TN23PROD with CFR

background image

727

Federal Aviation Administration, DOT

§ 33.83

(2) Continuation of the rain ingestion

during subsequent rapid deceleration
to minimum idle, then

(3) Continuation of the rain ingestion

during three minutes at minimum idle
power to be certified for flight oper-
ation, then

(4) Continuation of the rain ingestion

during subsequent rapid acceleration
to takeoff power.

(c)

Engines for supersonic airplanes. In

addition to complying with paragraphs
(a)(1) and (a)(2) of this section, a sepa-
rate test for supersonic airplane en-
gines only, shall be conducted with
three hailstones ingested at supersonic
cruise velocity. These hailstones shall
be aimed at the engine’s critical face
area, and their ingestion must not
cause unacceptable mechanical damage
or unacceptable power or thrust loss
after the ingestion or require the en-
gine to be shut down. The size of these
hailstones shall be determined from
the linear variation in diameter from 1-
inch (25 millimeters) at 35,000 feet
(10,500 meters) to

1

4

-inch (6 millime-

ters) at 60,000 feet (18,000 meters) using
the diameter corresponding to the low-
est expected supersonic cruise altitude.
Alternatively, three larger hailstones
may be ingested at subsonic velocities
such that the kinetic energy of these
larger hailstones is equivalent to the
applicable supersonic ingestion condi-
tions.

(d) For an engine that incorporates

or requires the use of a protection de-
vice, demonstration of the rain and
hail ingestion capabilities of the en-
gine, as required in paragraphs (a), (b),
and (c) of this section, may be waived
wholly or in part by the Administrator
if the applicant shows that:

(1) The subject rain and hail con-

stituents are of a size that will not
pass through the protection device;

(2) The protection device will with-

stand the impact of the subject rain
and hail constituents; and

(3) The subject of rain and hail con-

stituents, stopped by the protection de-
vice, will not obstruct the flow of in-
duction air into the engine, resulting
in damage, power or thrust loss, or
other adverse engine anomalies in ex-
cess of what would be accepted in para-
graphs (a), (b), and (c) of this section.

[Doc. No. 28652, 63 FR 14799, Mar. 26, 1998]

§ 33.79

Fuel burning thrust augmentor.

Each fuel burning thrust augmentor,

including the nozzle, must—

(a) Provide cutoff of the fuel burning

thrust augmentor;

(b) Permit on-off cycling;
(c) Be controllable within the in-

tended range of operation;

(d) Upon a failure or malfunction of

augmentor combustion, not cause the
engine to lose thrust other than that
provided by the augmentor; and

(e) Have controls that function com-

patibly with the other engine controls
and automatically shut off augmentor
fuel flow if the engine rotor speed drops
below the minimum rotational speed at
which the augmentor is intended to
function.

[Amdt. 33–6, 39 FR 35468, Oct. 1, 1974]

Subpart F—Block Tests; Turbine

Aircraft Engines

§ 33.81

Applicability.

This subpart prescribes the block

tests and inspections for turbine en-
gines.

[Doc. No. 3025, 29 FR 7453, June 10, 1964, as
amended by Amdt. 33–6, 39 FR 35468, Oct. 1,
1974]

§ 33.82

General.

Before each endurance test required

by this subpart, the adjustment setting
and functioning characteristic of each
component having an adjustment set-
ting and a functioning characteristic
that can be established independent of
installation on the engine must be es-
tablished and recorded.

[Amdt. 36–6, 39 FR 35468, Oct. 1, 1974]

§ 33.83

Vibration test.

(a) Each engine must undergo vibra-

tion surveys to establish that the vi-
bration characteristics of those compo-
nents that may be subject to mechani-
cally or aerodynamically induced vi-
bratory excitations are acceptable
throughout the declared flight enve-
lope. The engine surveys shall be based
upon an appropriate combination of ex-
perience, analysis, and component test
and shall address, as a minimum,
blades, vanes, rotor discs, spacers, and
rotor shafts.
