Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

§ 172.102

Special provisions.

(a)

General.

When column 7 of the

§ 172.101 table refers to a special provi-
sion for a hazardous material, the
meaning and requirements of that pro-
vision are as set forth in this section.
When a special provision specifies
packaging or packaging require-
ments—

(1) The special provision is in addi-

tion to the standard requirements for
all packagings prescribed in § 173.24 of
this subchapter and any other applica-
ble packaging requirements in subparts
A and B of part 173 of this subchapter;
and

(2) To the extent a special provision

imposes limitations or additional re-
quirements on the packaging provi-
sions set forth in column 8 of the
§ 172.101 table, packagings must con-
form to the requirements of the special
provision.

(b)

Description of codes for special pro-

visions.

Special provisions contain

packaging provisions, prohibitions, ex-
ceptions from requirements for par-
ticular quantities or forms of materials
and requirements or prohibitions appli-
cable to specific modes of transpor-
tation, as follows:

(1) A code consisting only of numbers

(for example, ‘‘11’’) is multi-modal in
application and may apply to bulk and
non-bulk packagings.

(2) A code containing the letter ‘‘A’’

refers to a special provision which ap-
plies only to transportation by air-
craft.

(3) A code containing the letter ‘‘B’’

refers to a special provision that ap-
plies only to bulk packaging require-
ments. Unless otherwise provided in
this subchapter, these special provi-
sions do not apply to UN, IM Specifica-
tion portable tanks or IBCs.

(4) A code containing the letters ‘‘IB’’

or ‘‘IP’’ refers to a special provision
that applies only to transportation in
IBCs.

(5) A code containing the letter ‘‘N’’

refers to a special provision which ap-
plies only to non-bulk packaging re-
quirements.

(6) A code containing the letter ‘‘R’’

refers to a special provision which ap-
plies only to transportation by rail.

(7) A code containing the letter ‘‘T’’

refers to a special provision which ap-

plies only to transportation in UN or
IM Specification portable tanks.

(8) A code containing the letters

‘‘TP’’ refers to a portable tank special
provision for UN or IM Specification
portable tanks that is in addition to
those provided by the portable tank in-
structions or the requirements in part
178 of this subchapter.

(9) A code containing the letter ‘‘W’’

refers to a special provision that ap-
plies only to transportation by water.

(c)

Tables of special provisions.

The fol-

lowing tables list, and set forth the re-
quirements of, the special provisions
referred to in column 7 of the § 172.101
table.

(1)

Numeric provisions.

These provi-

sions are multi-modal and apply to
bulk and non-bulk packagings:

Code/Special Provisions

1

This material is poisonous by inhalation

(see § 171.8 of this subchapter) in Hazard
Zone A (see § 173.116(a) or § 173.133(a) of this
subchapter), and must be described as an
inhalation hazard under the provisions of
this subchapter.

2

This material is poisonous by inhalation

(see § 171.8 of this subchapter) in Hazard
Zone B (see § 173.116(a) or § 173.133(a) of this
subchapter), and must be described as an
inhalation hazard under the provisions of
this subchapter.

3

This material is poisonous by inhalation

(see § 171.8 of this subchapter) in Hazard
Zone C (see § 173.116(a) of this subchapter),
and must be described as an inhalation
hazard under the provisions of this sub-
chapter.

4

This material is poisonous by inhalation

(see § 171.8 of this subchapter) in Hazard
Zone D (see § 173.116(a) of this subchapter),
and must be described as an inhalation
hazard under the provisions of this sub-
chapter.

5

If this material meets the definition for a

material poisonous by inhalation (see
§ 171.8 of this subchapter), a shipping name
must be selected which identifies the inha-
lation hazard, in Division 2.3 or Division
6.1, as appropriate.

6

This material is poisonous-by-inhalation

and must be described as an inhalation
hazard under the provisions of this sub-
chapter.

8

A hazardous substance that is not a haz-

ardous waste may be shipped under the
shipping description ‘‘Other regulated sub-
stances, liquid

or

solid, n.o.s.’’, as appro-

priate. In addition, for solid materials, spe-
cial provision B54 applies.

background image

354

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

9

Packaging for certain PCBs for disposal

and storage is prescribed by EPA in 40 CFR
761.60 and 761.65.

11

The hazardous material must be pack-

aged as either a liquid or a solid, as appro-
priate, depending on its physical form at 55

°

C (131

°

F) at atmospheric pressure.

12

In concentrations greater than 40 per-

cent, this material has strong oxidizing
properties and is capable of starting fires
in contact with combustible materials. If
appropriate, a package containing this ma-
terial must conform to the additional la-
beling requirements of § 172.402 of this sub-
chapter.

13

The words ‘‘Inhalation Hazard’’ shall be

entered on each shipping paper in associa-
tion with the shipping description, shall be
marked on each non-bulk package in asso-
ciation with the proper shipping name and
identification number, and shall be marked
on two opposing sides of each bulk pack-
age. Size of marking on bulk package must
conform to § 172.302(b) of this subchapter.
The requirements of §§ 172.203(m) and
172.505 of this subchapter do not apply.

14

Motor fuel antiknock mixtures are:

a. Mixtures of one or more organic lead

mixtures (such as tetraethyl lead,
triethylmethyl lead, diethyldimethyl
lead, ethyltrimethyl lead, and
tetramethyl lead) with one or more halo-
gen compounds (such as ethylene
dibromide and ethylene dichloride), hy-
drocarbon solvents or other equally effi-
cient stabilizers; or

b. tetraethyl lead.

15

This entry applies to ‘‘Chemical kits’’

and ‘‘First aid kits’’ containing one or
more compatible items of hazardous mate-
rials in boxes, cases,

etc.

that, for example,

are used for medical, analytical, diag-
nostic, testing, or repair purposes. Kits
that are carried on board transport vehi-
cles for first aid or operating purposes are
not subject to the requirements of this
subchapter.

16

This description applies to smokeless

powder and other solid propellants that are
used as powder for small arms and have
been classed as Division 1.3C, 1.4C and Divi-
sion 4.1 in accordance with § 173.56 of this
subchapter.

19

For domestic transportation only, the

identification number ‘‘UN1075’’ may be
used in place of the identification number
specified in column (4) of the § 172.101 table.
The identification number used must be
consistent on package markings, shipping
papers and emergency response informa-
tion.

21

This material must be stabilized by ap-

propriate means (e.g., addition of chemical
inhibitor, purging to remove oxygen) to
prevent dangerous polymerization (see
§ 173.21(f) of this subchapter).

22

If the hazardous material is in dispersion

in organic liquid, the organic liquid must
have a flash point above 50

°

C (122

°

F).

23

This material may be transported under

the provisions of Division 4.1 only if it is so
packed that the percentage of diluent will
not fall below that stated in the shipping
description at any time during transport.
Quantities of not more than 500 g per pack-
age with not less than 10 percent water by
mass may also be classed in Division 4.1,
provided a negative test result is obtained
when tested in accordance with test series
6(c) of the UN Manual of Tests and Criteria
(IBR, see § 171.7 of this subchapter).

24

Alcoholic beverages containing more

than 70 percent alcohol by volume must be
transported as materials in Packing Group
II. Alcoholic beverages containing more
than 24 percent but not more than 70 per-
cent alcohol by volume must be trans-
ported as materials in Packing Group III.

26

This entry does not include ammonium

permanganate, the transport of which is
prohibited except when approved by the
Associate Administrator.

28 The dihydrated sodium salt of

dichloroisocyanuric acid does not meet the
criteria for inclusion in Division 5.1 (Oxi-
dizer) and is not subject to the require-
ments of this subchapter unless meeting
the criteria for inclusion in another class
or division.

30

Sulfur is not subject to the requirements

of this subchapter if transported in a non-
bulk packaging or if formed to a specific
shape (for example, prills, granules, pel-
lets, pastilles, or flakes). A bulk packaging
containing sulfur is not subject to the
placarding requirements of subpart F of
this part, if it is marked with the appro-
priate identification number as required by
subpart D of this part. Molten sulfur must
be marked as required by § 172.325 of this
subchapter.

31

Materials which have undergone suffi-

cient heat treatment to render them non-
hazardous are not subject to the require-
ments of this subchapter.

32

Polymeric beads and molding compounds

may be made from polystyrene,
poly(methyl methacrylate) or other poly-
meric material.

33

Ammonium nitrites and mixtures of an

inorganic nitrite with an ammonium salt
are prohibited.

34

The commercial grade of calcium nitrate

fertilizer, when consisting mainly of a dou-
ble salt (calcium nitrate and ammonium
nitrate) containing not more than 10 per-
cent ammonium nitrate and at least 12 per-
cent water of crystallization, is not subject
to the requirements of this subchapter.

35

Antimony sulphides and oxides which do

not contain more than 0.5 percent of ar-
senic calculated on the total mass do not
meet the definition of Division 6.1.

background image

355

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

37

Unless it can be demonstrated by testing

that the sensitivity of the substance in its
frozen state is no greater than in its liquid
state, the substance must remain liquid
during normal transport conditions. It
must not freeze at temperatures above

¥

15

°

C (5

°

F).

38

If this material shows a violent effect in

laboratory tests involving heating under
confinement, the labeling requirements of
Special Provision 53 apply, and the mate-
rial must be packaged in accordance with
packing method OP6 in § 173.225 of this sub-
chapter. If the SADT of the technically
pure substance is higher than 75

°

C, the

technically pure substance and formula-
tions derived from it are not self-reactive
materials and, if not meeting any other
hazard class, are not subject to the re-
quirements of this subchapter.

39

This substance may be carried under pro-

visions other than those of Class 1 only if
it is so packed that the percentage of
water will not fall below that stated at any
time during transport. When phlegmatized
with water and inorganic inert material,
the content of urea nitrate must not ex-
ceed 75 percent by mass and the mixture
should not be capable of being detonated
by test 1(a)(i) or test 1(a)(ii) in the UN
Manual of Tests and Criteria (IBR, see
§ 171.7 of this subchapter).

40

Polyester resin kits consist of two com-

ponents: A base material (either Class 3 or
Division 4.1, Packing Group II or III) and
an activator (organic peroxide), each sepa-
rately packed in an inner packaging. The
organic peroxide must be type D, E, or F,
not requiring temperature control. The
components may be placed in the same
outer packaging provided they will not
interact dangerously in the event of leak-
age. The Packing Group assigned will be II
or III, according to the classification cri-
teria for either Class 3 or Division 4.1, as
appropriate, applied to the base material.
Additionally, unless otherwise excepted in
this subchapter, polyester resin kits must
be packaged in specification combination
packagings based on the performance level
of the base material contained within the
kit.

41

This material at the Packing Group II

hazard criteria level may be transported in
Large Packagings.

43

The membrane filters, including paper

separators and coating or backing mate-
rials, that are present in transport, must
not be able to propagate a detonation as
tested by one of the tests described in the
UN Manual of Tests and Criteria, Part I,
Test series 1(a) (IBR, see § 171.7 of this sub-
chapter). On the basis of the results of
suitable burning rate tests, and taking
into account the standard tests in the UN
Manual of Tests and Criteria, Part III, sub-
section 33.2.1 (IBR, see § 171.7 of this sub-

chapter), nitrocellulose membrane filters
in the form in which they are to be trans-
ported that do not meet the criteria for a
Division 4.1 material are not subject to the
requirements of this subchapter. Pack-
agings must be so constructed that explo-
sion is not possible by reason of increased
internal pressure. Nitrocellulose mem-
brane filters covered by this entry, each
with a mass not exceeding 0.5 g, are not
subject to the requirements of this sub-
chapter when contained individually in an
article or a sealed packet.

44

The formulation must be prepared so

that it remains homogenous and does not
separate during transport. Formulations
with low nitrocellulose contents and nei-
ther showing dangerous properties when
tested for their ability to detonate,
deflagrate or explode when heated under
defined confinement by the appropriate
test methods and criteria in the UN Man-
ual of Tests and Criteria (IBR, see § 171.7 of
this subchapter), nor classed as a Division
4.1 (flammable solid) when tested in ac-
cordance with the procedures specified in
§ 173.124 of this subchapter (chips, if nec-
essary, crushed and sieved to a particle
size of less than 1.25 mm), are not subject
to the requirements of this subchapter.

45

Temperature should be maintained be-

tween 18

°

C (64.4

°

F) and 40

°

C (104

°

F).

Tanks containing solidified methacrylic
acid must not be reheated during trans-
port.

46

This material must be packed in accord-

ance with packing method OP6 (see § 173.225
of this subchapter). During transport, it
must be protected from direct sunshine
and stored (or kept) in a cool and well-ven-
tilated place, away from all sources of
heat.

47

Mixtures of solids that are not subject to

this subchapter and flammable liquids may
be transported under this entry without
first applying the classification criteria of
Division 4.1, provided there is no free liquid
visible at the time the material is loaded
or at the time the packaging or transport
unit is closed. Except when the liquids are
fully absorbed in solid material contained
in sealed bags, for single packagings, each
packaging must correspond to a design
type that has passed a leakproofness test
at the Packing Group II level. Sealed pack-
ets and articles containing less than 10 mL
of a Class 3 liquid in Packing Group II or
III absorbed onto a solid material are not
subject to this subchapter provided there is
no free liquid in the packet or article.

48

Mixtures of solids that are not subject to

this subchapter and toxic liquids may be
transported under this entry without first
applying the classification criteria of Divi-
sion 6.1, provided there is no free liquid
visible at the time the material is loaded
or at the time the packaging or transport

background image

356

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

unit is closed. For single packagings, each
packaging must correspond to a design
type that has passed a leakproofness test
at the Packing Group II level. This entry
may not be used for solids containing a
Packing Group I liquid.

49

Mixtures of solids that are not subject to

this subchapter and corrosive liquids may
be transported under this entry without
first applying the classification criteria of
Class 8, provided there is no free liquid
visible at the time the material is loaded
or at the time the packaging or transport
unit is closed. For single packagings, each
packaging must correspond to a design
type that has passed a leakproofness test
at the Packing Group II level.

50

Cases, cartridge, empty with primer

which are made of metallic or plastic cas-
ings and meeting the classification criteria
of Division 1.4 are not regulated for domes-
tic transportation.

51

This description applies to items pre-

viously described as ‘‘Toy propellant de-
vices, Class C’’ and includes reloadable
kits. Model rocket motors containing 30
grams or less propellant are classed as Di-
vision 1.4S and items containing more than
30 grams of propellant but not more than
62.5 grams of propellant are classed as Di-
vision 1.4C.

52 This entry may only be used for sub-

stances that are too insensitive for accept-
ance into Class 1 (explosive) when tested in
accordance with Test Series 2 in the UN
Manual of Tests and Criteria, Part I (incor-
porated by reference; see § 171.7 of this sub-
chapter).

53

Packages of these materials must bear

the subsidiary risk label, ‘‘EXPLOSIVE’’,
and the subsidiary hazard class/division
must be entered in parentheses imme-
diately following the primary hazard class
in the shipping description, unless other-
wise provided in this subchapter or
through an approval issued by the Asso-
ciate Administrator, or the competent au-
thority of the country of origin. A copy of
the approval shall accompany the shipping
papers.

54

Maneb or maneb preparations not meet-

ing the definition of Division 4.3 or any
other hazard class are not subject to the
requirements of this subchapter when
transported by motor vehicle, rail car, or
aircraft.

55

This device must be approved in accord-

ance with § 173.56 of this subchapter by the
Associate Administrator.

56

A means to interrupt and prevent deto-

nation of the detonator from initiating the
detonating cord must be installed between
each electric detonator and the detonating
cord ends of the jet perforating guns before
the charged jet perforating guns are of-
fered for transportation.

57

Maneb

or

Maneb preparations stabilized

against self-heating need not be classified
in Division 4.2 when it can be dem-
onstrated by testing that a volume of 1 m

3



of substance does not self-ignite and that
the temperature at the center of the sam-
ple does not exceed 200

°

C, when the sample

is maintained at a temperature of not less
than 75

°

±

°

C for a period of 24 hours, in

accordance with procedures set forth for
testing self-heating materials in the UN
Manual of Tests and Criteria (IBR, see
§ 171.7 of this subchapter).

58

Aqueous solutions of Division 5.1 inor-

ganic solid nitrate substances are consid-
ered as not meeting the criteria of Division
5.1 if the concentration of the substances
in solution at the minimum temperature
encountered in transport is not greater
than 80% of the saturation limit.

59

Ferrocerium, stabilized against corro-

sion, with a minimum iron content of 10
percent is not subject to the requirements
of this subchapter.

61

A chemical oxygen generator is spent if

its means of ignition and all or a part of its
chemical contents have been expended.

62

Oxygen generators (see § 171.8 of this sub-

chapter) are not authorized for transpor-
tation under this entry.

64

The group of alkali metals includes lith-

ium, sodium, potassium, rubidium, and
caesium.

65

The group of alkaline earth metals in-

cludes magnesium, calcium, strontium,
and barium.

66

Formulations of these substances con-

taining not less than 30 percent non-vola-
tile, non-flammable phlegmatizer are not
subject to this subchapter.

70

Black powder that has been classed in ac-

cordance with the requirements of § 173.56
of this subchapter may be reclassed and of-
fered for domestic transportation as a Di-
vision 4.1 material if it is offered for trans-
portation and transported in accordance
with the limitations and packaging re-
quirements of § 173.170 of this subchapter.

74

During transport, this material must be

protected from direct sunshine and stored
or kept in a cool and well-ventilated place,
away from all sources of heat.

78

This entry may not be used to describe

compressed air which contains more than
23.5 percent oxygen. Compressed air con-
taining greater than 23.5 percent oxygen
must be shipped using the description
‘‘Compressed gas, oxidizing, n.o.s.,
UN3156.’’

79

This entry may not be used for mixtures

that meet the definition for oxidizing gas.

81

Polychlorinated biphenyl items, as de-

fined in 40 CFR 761.3, for which specifica-
tion packagings are impractical, may be
packaged in non-specification packagings
meeting the general packaging require-
ments of subparts A and B of part 173 of

background image

357

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

this subchapter. Alternatively, the item
itself may be used as a packaging if it
meets the general packaging requirements
of subparts A and B of part 173 of this sub-
chapter.

101

The name of the particular substance or

article must be specified.

102

The ends of the detonating cord must be

tied fast so that the explosive cannot es-
cape. The articles may be transported as in
Division 1.4 Compatibility Group D (1.4D) if
all of the conditions specified in § 173.63(a)
of this subchapter are met.

105

The word ‘‘Agents’’ may be used instead

of ‘‘Explosives’’ when approved by the As-
sociate Administrator.

106

The recognized name of the particular

explosive may be specified in addition to
the type.

107

The classification of the substance is ex-

pected to vary especially with the particle
size and packaging but the border lines
have not been experimentally determined;
appropriate classifications should be
verified following the test procedures in
§§ 173.57 and 173.58 of this subchapter.

108

Fireworks must be so constructed and

packaged that loose pyrotechnic composi-
tion will not be present in packages during
transportation.

109

Rocket motors must be nonpropulsive

in transportation unless approved in ac-
cordance with § 173.56 of this subchapter. A
rocket motor to be considered ‘‘nonpropul-
sive’’ must be capable of unrestrained
burning and must not appreciably move in
any direction when ignited by any means.

110

Fire extinguishers transported under

UN1044 and oxygen cylinders transported
for emergency use under UN1072 may in-
clude installed actuating cartridges (car-
tridges, power device of Division 1.4C or
1.4S), without changing the classification
of Division 2.2, provided the aggregate
quantity of deflagrating (propellant) explo-
sives does not exceed 3.2 grams per cyl-
inder. Oxygen cylinders with installed ac-
tuating cartridges as prepared for trans-
portation must have an effective means of
preventing inadvertent activation.

111

Explosive substances of Division 1.1

Compatibility Group A (1.1A) are forbidden
for transportation if dry or not desen-
sitized, unless incorporated in a device.

113

The sample must be given a tentative

approval by an agency or laboratory in ac-
cordance with § 173.56 of this subchapter.

114

Jet perforating guns, charged, oil well,

without detonator may be reclassed to Di-
vision 1.4 Compatibility Group D (1.4D) if
the following conditions are met:
a. The total weight of the explosive con-

tents of the shaped charges assembled in
the guns does not exceed 90.5 kg (200
pounds) per vehicle; and

b. The guns are packaged in accordance

with Packing Method US 1 as specified in
§ 173.62 of this subchapter.

115

Boosters with detonator, detonator as-

semblies and boosters with detonators in
which the total explosive charge per unit
does not exceed 25 g, and which will not
mass detonate and undergo only limited
propagation in the shipping package may
be assigned to 1.4B classification code.
Mass detonate means more than 90 percent
of the devices tested in a package explode
practically simultaneously. Limited propa-
gation means that if one booster near the
center of the package is exploded, the ag-
gregate weight of explosives, excluding ig-
nition and delay charges, in this and all
additional boosters in the outside pack-
aging that explode may not exceed 25 g.

116

Fuzes, detonating may be classed in Di-

vision 1.4 if the fuzes do not contain more
than 25 g of explosive per fuze and are
made and packaged so that they will not
cause functioning of other fuzes, explosives
or other explosive devices if one of the
fuzes detonates in a shipping packaging or
in adjacent packages.

117

If shipment of the explosive substance is

to take place at a time that freezing
weather is anticipated, the water con-
tained in the explosive substance must be
mixed with denatured alcohol so that
freezing will not occur.

118

This substance may not be transported

under the provisions of Division 4.1 unless
specifically authorized by the Associate
Administrator (see UN0143 or UN0150 as ap-
propriate).

119

This substance, when in quantities of

not more than 11.5 kg (25.3 pounds), with
not less than 10 percent water, by mass,
also may be classed as Division 4.1, pro-
vided a negative test result is obtained
when tested in accordance with test series
6(c) of the UN Manual of Tests and Criteria
(IBR, see § 171.7 of this subchapter).

120

The phlegmatized substance must be

significantly less sensitive than dry PETN.

121

This substance, when containing less al-

cohol, water or phlegmatizer than speci-
fied, may not be transported unless ap-
proved by the Associate Administrator.

123

Any explosives, blasting, type C con-

taining chlorates must be segregated from
explosives containing ammonium nitrate
or other ammonium salts.

125

Lactose or glucose or similar materials

may be used as a phlegmatizer provided
that the substance contains not less than
90%, by mass, of phlegmatizer. These mix-
tures may be classified in Division 4.1 when
tested in accordance with test series 6(c) of
the UN Manual of Tests and Criteria (IBR,
see § 171.7 of this subchapter) and approved
by the Associate Administrator. Testing
must be conducted on at least three pack-
ages as prepared for transport. Mixtures

background image

358

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

containing at least 98%, by mass, of
phlegmatizer are not subject to the re-
quirements of this subchapter. Packages
containing mixtures with not less than 90%
by mass, of phlegmatizer need not bear a
POISON subsidiary risk label.

127

Mixtures containing oxidizing and or-

ganic materials transported under this
entry may not meet the definition and cri-
teria of a Class 1 material. (See § 173.50 of
this subchapter.)

128

Regardless of the provisions of

§ 172.101(c)(12), aluminum smelting by-prod-
ucts and aluminum remelting by-products
described under this entry, meeting the
definition of Class 8, Packing Group II and
III may be classed as a Division 4.3 mate-
rial and transported under this entry. The
presence of a Class 8 hazard must be com-
municated as required by this part for sub-
sidiary hazards.

129

These materials may not be classified

and transported unless authorized by the
Associate Administrator on the basis of re-
sults from Series 2 Test and a Series 6(c)
Test from the UN Manual of Tests and Cri-
teria (IBR, see § 171.7 of this subchapter) on
packages as prepared for transport. The
packing group assignment and packaging
must be approved by the Associate Admin-
istrator for Hazardous Materials Safety on
the basis of the criteria in § 173.21 of this
subchapter and the package type used for
the Series 6(c) test.

130

‘‘Batteries, dry, sealed, n.o.s.,’’ com-

monly referred to as dry batteries, are her-
metically sealed and generally utilize met-
als (other than lead) and/or carbon as elec-
trodes. These batteries are typically used
for portable power applications. The re-
chargeable (and some non-rechargeable)
types have gelled alkaline electrolytes
(rather than acidic) making it difficult for
them to generate hydrogen or oxygen when
overcharged and therefore, differentiating
them from non-spillable batteries. Dry bat-
teries specifically covered by another
entry in the § 172.101 Table must be trans-
ported in accordance with the require-
ments applicable to that entry. For exam-
ple, nickel-metal hydride batteries trans-
ported by vessel in certain quantities are
covered by another entry (

see

Batteries,

nickel-metal hydride, UN3496). Dry bat-
teries not specifically covered by another
entry in the § 172.101 Table are covered by
this entry (

i.e.,

Batteries, dry, sealed,

n.o.s.) and are not subject to requirements
of this subchapter except for the following:
(a)

Incident reporting.

For transportation

by aircraft, a telephone report in accord-
ance with § 171.15(a) is required if a fire,
violent rupture, explosion or dangerous
evolution of heat (

i.e.,

an amount of heat

sufficient to be dangerous to packaging
or personal safety to include charring of
packaging, melting of packaging, scorch-

ing of packaging, or other evidence) oc-
curs as a direct result of a dry battery.
For all modes of transportation, a writ-
ten report submitted, retained, and up-
dated in accordance with § 171.16 is re-
quired if a fire, violent rupture, explosion
or dangerous evolution of heat occurs as
a direct result of a dry battery or bat-
tery-powered device.

(b)

Preparation for transport.

Batteries and

battery-powered device(s) containing
batteries must be prepared and packaged
for transport in a manner to prevent:

(1) A dangerous evolution of heat;
(2) Short circuits, including but not lim-

ited to the following methods:

(i) Packaging each battery or each battery-

powered device when practicable, in fully
enclosed inner packagings made of non-
conductive material;

(ii) Separating or packaging batteries in a

manner to prevent contact with other
batteries, devices or conductive mate-
rials (

e.g.,

metal) in the packagings; or

(iii) Ensuring exposed terminals or connec-

tors are protected with non-conductive
caps, non-conductive tape, or by other
appropriate means; and

(3) Damage to terminals. If not impact re-

sistant, the outer packaging should not
be used as the sole means of protecting
the battery terminals from damage or
short circuiting. Batteries must be se-
curely cushioned and packed to prevent
shifting which could loosen terminal
caps or reorient the terminals to produce
short circuits. Batteries contained in de-
vices must be securely installed. Ter-
minal protection methods include but
are not limited to the following:

(i) Securely attaching covers of sufficient

strength to protect the terminals;

(ii) Packaging the battery in a rigid plastic

packaging; or

(iii) Constructing the battery with termi-

nals that are recessed or otherwise pro-
tected so that the terminals will not be
subjected to damage if the package is
dropped.

(c)

Additional air transport requirements.

For

a battery whose voltage (electrical po-
tential) exceeds 9 volts—

(1) When contained in a device, the device

must be packaged in a manner that pre-
vents unintentional activation or must
have an independent means of preventing
unintentional activation (

e.g.,

packaging

restricts access to activation switch,
switch caps or locks, recessed switches,
trigger locks, temperature sensitive cir-
cuit breakers,

etc.

); and

(2) An indication of compliance with this

special provision must be provided by
marking each package with the words
‘‘not restricted’’ or by including the
words ‘‘not restricted’’ on a transport

background image

359

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

document such as an air waybill accom-
panying the shipment.

(d)

Used or spent battery exception.

Used or

spent dry batteries of both non-recharge-
able and rechargeable designs, with a
marked rating up to 9-volt that are com-
bined in the same package and trans-
ported by highway or rail for recycling,
reconditioning, or disposal are not sub-
ject to this special provision or any other
requirement of the HMR. Note that bat-
teries utilizing different chemistries (

i.e.,

those battery chemistries specifically
covered by another entry in the § 172.101
Table) as well as dry batteries with a
marked rating greater than 9-volt may
not be combined with used or spent bat-
teries in the same package. Note also
that this exception does not apply to bat-
teries that have been reconditioned for
reuse.

131

This material may not be offered for

transportation unless approved by the As-
sociate Administrator.

132

This description may only be used for

ammonium nitrate-based compound fer-
tilizers. They must be classified in accord-
ance with the procedure as set out in the
Manual of Tests and Criteria, part III, sec-
tion 39 (IBR,

see

§ 171.7 of this subchapter).

Fertilizers meeting the criteria for this
identification number are only subject to
the requirements of this subchapter when
offered for transportation and transported
by air or vessel.

134

This entry applies only to vehicles pow-

ered by wet batteries, sodium batteries,
lithium metal batteries or lithium ion bat-
teries, and equipment powered by wet bat-
teries or sodium batteries that are trans-
ported with these batteries installed. Lith-
ium batteries installed in a cargo trans-
port unit, designed only to provide power
external to the transport unit must use the
proper shipping name ‘‘Lithium batteries
installed in cargo transport unit’’ found in
the § 172.101 Hazardous Materials Table.
a. For the purpose of this special provision,

vehicles are self-propelled apparatus de-
signed to carry one or more persons or
goods. Examples of such vehicles are
electrically-powered cars, motorcycles,
scooters, three- and four-wheeled vehi-
cles or motorcycles, trucks, locomotives,
bicycles (pedal cycles with an electric
motor) and other vehicles of this type
(

e.g.,

self-balancing vehicles or vehicles

not equipped with at least one seating
position), lawn tractors, self-propelled
farming and construction equipment,
boats, aircraft, wheelchairs and other
mobility aids. This includes vehicles
transported in a packaging. In this case,
some parts of the vehicle may be de-
tached from its frame to fit into the
packaging.

b. Examples of equipment are lawnmowers,

cleaning machines, or model boats and
model aircraft. Equipment powered by
lithium metal batteries or lithium ion
batteries must be described using the en-
tries ‘‘Lithium metal batteries contained
in equipment’’ or ‘‘Lithium metal bat-
teries packed with equipment’’ or ‘‘Lith-
ium ion batteries contained in equip-
ment’’ or ‘‘Lithium ion batteries packed
with equipment,’’ as appropriate.

c. Self-propelled vehicles or equipment

that also contain an internal combustion
engine must be described using the en-
tries ‘‘Engine, internal combustion,
flammable gas powered’’ or ‘‘Engine, in-
ternal combustion, flammable liquid
powered’’ or ‘‘Vehicle, flammable gas
powered’’ or ‘‘Vehicle, flammable liquid
powered,’’ as appropriate. These entries
include hybrid electric vehicles powered
by both an internal combustion engine
and batteries. Additionally, self-pro-
pelled vehicles or equipment that con-
tain a fuel cell engine must be described
using the entries ‘‘Engine, fuel cell, flam-
mable gas powered’’ or ‘‘Engine, fuel cell,
flammable liquid powered’’ or ‘‘Vehicle,
fuel cell, flammable gas powered’’ or
‘‘Vehicle, fuel cell, flammable liquid
powered,’’ as appropriate. These entries
include hybrid electric vehicles powered
by a fuel cell engine, an internal combus-
tion engine, and batteries.

135

Internal combustion engines installed in

a vehicle must be described using ‘‘Vehicle,
flammable gas powered’’ or ‘‘Vehicle, flam-
mable liquid powered,’’ as appropriate. If a
vehicle is powered by a flammable liquid
and a flammable gas internal combustion
engine, it must be described using ‘‘Vehi-
cle, flammable gas powered.’’ This includes
hybrid electric vehicles powered by both an
internal combustion engine and wet, so-
dium or lithium batteries installed. If a
fuel cell engine is installed in a vehicle,
the vehicle must be described using ‘‘Vehi-
cle, fuel cell, flammable gas powered’’ or
‘‘Vehicle, fuel cell, flammable liquid pow-
ered,’’ as appropriate. This includes hybrid
electric vehicles powered by a fuel cell, an
internal combustion engine, and wet, so-
dium or lithium batteries installed. For
the purpose of this special provision, vehi-
cles are self-propelled apparatus designed
to carry one or more persons or goods. Ex-
amples of such vehicles are cars, motor-
cycles, trucks, locomotives, scooters,
three- and four-wheeled vehicles or motor-
cycles, lawn tractors, self-propelled farm-
ing and construction equipment, boats, and
aircraft. Furthermore, lithium batteries
installed in a cargo transport unit, de-
signed only to provide power external to
the transport unit must be described using
the proper shipping name ‘‘Lithium bat-
teries installed in cargo transport unit’’

background image

360

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

found in the § 172.101 Hazardous Materials
Table.

136

This entry applies only to articles, ma-

chinery, and apparatus containing haz-
ardous materials as an integral element of
the article, machinery, or apparatus. It
may not be used to describe articles, ma-
chinery, or apparatus for which a proper
shipping name exists in the § 172.101 Table.
Except when approved by the Associate
Administrator, these items may only con-
tain hazardous materials for which excep-
tions are referenced in Column (8) of the
§ 172.101 Table and are provided in part 173,
subparts D and G, of this subchapter. Haz-
ardous materials shipped under this entry
are excepted from the labeling require-
ments of this subchapter unless offered for
transportation or transported by aircraft
and are not subject to the placarding re-
quirements of subpart F of this part. Ori-
entation markings as described in
§ 172.312(a)(2) are required when liquid haz-
ardous materials may escape due to incor-
rect orientation. The article, machinery,
or apparatus, if unpackaged, or the pack-
aging in which it is contained shall be
marked ‘‘Dangerous goods in articles’’ or
‘‘Dangerous goods in machinery’’ or ‘‘Dan-
gerous goods in apparatus’’ as appropriate,
with the identification number UN3363. For
transportation by aircraft, articles, ma-
chinery, or apparatus, may not contain
any material forbidden for transportation
by passenger or cargo aircraft. The Asso-
ciate Administrator may except from the
requirements of this subchapter articles,
machinery, and apparatus provided:
a. It is shown that it does not pose a sig-

nificant risk in transportation;

b. The quantities of hazardous materials do

not exceed those specified in § 173.4a of
this subchapter; and

c. The equipment, and machinery or appa-

ratus articles conforms with § 173.222 of
this subchapter.

137

Cotton, dry; flax, dry; sisal, dry; and

tampico fiber, dry are not subject to the
requirements of this subchapter when they
are baled in accordance with ISO 8115,
‘‘Cotton Bales—Dimensions and Density’’
(IBR, see § 171.7 of this subchapter) to a
density of not less than 360 kg/m

3

(22.1 lb/

ft

3

) for cotton, 400 kg/m

3

(24.97 lb/ft

3

) for

flax, 620 kg/m

3

(38.71 lb/ft

3

) for sisal and 360

kg/m

3

(22.1 lb/ft

3

) for tampico fiber and

transported in a freight container or closed
transport vehicle.

138

This entry applies to lead compounds

which, when mixed in a ratio of 1:1,000 with
0.07 M (Molar concentration) hydrochloric
acid and stirred for one hour at a tempera-
ture of 23

°

±

°

C, exhibit a solubility of

more than 5%. Lead compounds which,
when mixed in a ratio of 1:1,000 with 0.07 M
(Molar concentration) hydrochloric acid
and stirred for one hour at a temperature

of 23

°

±

°

C, exhibit a solubility of 5% or

less are not subject to the requirements of
this subchapter unless they meet criteria
as another hazard class or division. Lead
compounds that have a solubility of 5% or
less in accordance with this special provi-
sion are not subject to the requirements of
this subchapter that pertain to Marine
Pollutants.

139

Use of the ‘‘special arrangement’’ proper

shipping names for international ship-
ments must be made under an IAEA Cer-
tificate of Competent Authority issued by
the Associate Administrator in accordance
with the requirements in § 173.471, § 173.472,
or § 173.473 of this subchapter. Use of these
proper shipping names for domestic ship-
ments may be made only under a DOT spe-
cial permit, as defined in, and in accord-
ance with the requirements of subpart B of
part 107 of this subchapter.

140

This material is regulated only when it

meets the defining criteria for a hazardous
substance or a marine pollutant. In addi-
tion, the column 5 reference is modified to
read ‘‘III’’ on those occasions when this
material is offered for transportation or
transported by highway or rail.

141

A toxin obtained from a plant, animal,

or bacterial source containing an infec-
tious substance, or a toxin contained in an
infectious substance, must be classed as
Division 6.2, described as an infectious sub-
stance, and assigned to UN 2814 or UN 2900,
as appropriate.

142

These hazardous materials may not be

classified and transported unless author-
ized by the Associate Administrator. The
Associate Administrator will base the au-
thorization on results from Series 2 tests
and a Series 6(c) test from the UN Manual
of Tests and Criteria (IBR, see § 171.7 of
this subchapter) on packages as prepared
for transport in accordance with the re-
quirements of this subchapter.

144

If transported as a residue in an under-

ground storage tank (UST), as defined in 40
CFR 280.12, that has been cleaned and
purged or rendered inert according to the
American Petroleum Institute (API)
Standard 1604 (IBR, see § 171.7 of this sub-
chapter), then the tank and this material
are not subject to any other requirements
of this subchapter. However, sediments re-
maining in the tank that meet the defini-
tion for a hazardous material are subject
to the applicable regulations of this sub-
chapter.

145

This entry applies to formulations that

neither detonate in the cavitated state nor
deflagrate in laboratory testing, show no
effect when heated under confinement, ex-
hibit no explosive power, and are ther-
mally stable (self-accelerating decomposi-
tion temperature (SADT) at 60

°

C (140

°

F)

or higher for a 50 kg (110.2 lbs.) package).
Formulations not meeting these criteria

background image

361

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

must be transported under the provisions
applicable to the appropriate entry in the
Organic Peroxide Table in § 173.225 of this
subchapter.

146

This description may be used for a ma-

terial that poses a hazard to the environ-
ment but does not meet the definition for
a hazardous waste or a hazardous sub-
stance, as defined in § 171.8 of this sub-
chapter, or any hazard class, as defined in
part 173 of this subchapter, if it is des-
ignated as environmentally hazardous by
another Competent Authority. This provi-
sion may be used for both domestic and
international shipments.

147

This entry applies to non-sensitized

emulsions, suspensions, and gels consisting
primarily of a mixture of ammonium ni-
trate and fuel, intended to produce a Type
E blasting explosive only after further
processing prior to use. The mixture for
emulsions typically has the following com-
position: 60–85% ammonium nitrate; 5–30%
water; 2–8% fuel; 0.5–4% emulsifier or
thickening agent; 0–10% soluble flame sup-
pressants; and trace additives. Other inor-
ganic nitrate salts may replace part of the
ammonium nitrate. The mixture for sus-
pensions and gels typically has the fol-
lowing composition: 60–85% ammonium ni-
trate; 0–5% sodium or potassium per-
chlorate; 0–17% hexamine nitrate or
monomethylamine nitrate; 5–30% water; 2–
15% fuel; 0.5–4% thickening agent; 0–10%
soluble flame suppressants; and trace addi-
tives. Other inorganic nitrate salts may re-
place part of the ammonium nitrate. These
substances must satisfy the criteria for
classification as an ammonium nitrate
emulsion of Test Series 8 of the UN Manual
of Tests and Criteria, Part I, Section 18
(IBR,

see

§ 171.7 of this subchapter), and

may not be classified and transported un-
less approved by the Associate Adminis-
trator.

148

For domestic transportation, this entry

directs to § 173.66 for:
a. The standards for transporting a single

bulk hazardous material for blasting by
cargo tank motor vehicles (CTMV); and

b. The standards for CTMVs capable of

transporting multiple hazardous mate-
rials for blasting in bulk and non-bulk
packagings (

i.e.,

a multipurpose bulk

truck (MBT)).

149

When transported as a limited quantity

or a consumer commodity, the maximum
net capacity specified in § 173.150(b)(2) of
this subchapter for inner packagings may
be increased to 5 L (1.3 gallons).

150

This description may only be used for

ammonium nitrate-based fertilizers. They
must be classified in accordance with the
procedure as set out in the Manual of Tests
and Criteria, part III, section 39 (IBR,

see

§ 171.7 of this subchapter).

151

If this material meets the definition of

a flammable liquid in § 173.120 of this sub-
chapter, a FLAMMABLE LIQUID label is
also required and the basic description on
the shipping paper must indicate the Class
3 subsidiary hazard.

155

Fish meal, fish scrap and krill meal may

not be transported if the temperature at
the time of loading either exceeds 35

°

C (95

°

F), or exceeds 5

°

C (41

°

F) above the ambi-

ent temperature, whichever is higher.

156

Asbestos that is immersed or fixed in a

natural or artificial binder material, such
as cement, plastic, asphalt, resins or min-
eral ore, or contained in manufactured
products is not subject to the requirements
of this subchapter.

157

When transported as a limited quantity

or a consumer commodity, the maximum
net capacity specified in § 173.151(b)(1)(i) of
this subchapter for inner packagings may
be increased to 5 kg (11 pounds).

159

This material must be protected from

direct sunshine and kept in a cool, well-
ventilated place away from sources of heat.

160

This entry applies to safety devices for

vehicles, vessels or aircraft,

e.g.

air bag in-

flators, air bag modules, seat-belt
pretensioners, and pyromechanical devices
containing Class 1 (explosive) materials or
materials of other hazard classes. These ar-
ticles must be tested in accordance with
Test series 6(c) of Part I of the UN Manual
of Tests and Criteria (incorporated by ref-
erence; see § 171.7 of this subchapter), with
no explosion of the device, no fragmenta-
tion of device casing or pressure vessel,
and no projection hazard or thermal effect
that would significantly hinder fire-fight-
ing or other emergency response efforts in
the immediate vicinity. If the air bag in-
flator unit satisfactorily passes the series
6(c) test, it is not necessary to repeat the
test on the air bag module. This entry does
not apply to life saving appliances de-
scribed in § 173.219 (UN2990 and UN3072).

162

This material may be transported under

the provisions of Division 4.1 only if it is
packed so that at no time during transport
will the percentage of diluent fall below
the percentage that is stated in the ship-
ping description.

163

Substances must satisfactorily pass

Test Series 8 of the UN Manual of Tests
and Criteria, Part I, Section 18 (IBR, see
§ 171.7 of this subchapter).

164

Substances must not be transported

under this entry unless approved by the
Associate Administrator on the basis of
the results of appropriate tests according
to Part I of the UN Manual of Tests and
Criteria (IBR, see § 171.7 of this sub-
chapter). The material must be packaged
so that the percentage of diluent does not
fall below that stated in the approval at
any time during transportation.

background image

362

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

165

These substances are susceptible to

exothermic decomposition at elevated tem-
peratures. Decomposition can be initiated
by heat, moisture or by impurities (e.g.,
powdered metals (iron, manganese, cobalt,
magnesium)). During the course of trans-
portation, these substances must be shaded
from direct sunlight and all sources of heat
and be placed in adequately ventilated
areas.

166

When transported in non-friable tablet

form, calcium hypochlorite, dry, may be
transported as a Packing Group III mate-
rial.

167

These storage systems must always be

considered as containing hydrogen. A
metal hydride storage system installed in
or intended to be installed in a vehicle or
equipment or in vehicle or equipment com-
ponents must be approved for transport by
the Associate Administrator. A copy of the
approval must accompany each shipment.

168

For lighters containing a Division 2.1

gas (

see

§ 171.8 of this subchapter), rep-

resentative samples of each new lighter de-
sign must be examined and successfully
tested as specified in § 173.308(b)(3). For cri-
teria in determining what is a new lighter
design,

see

§ 173.308(b)(1). For transpor-

tation of new lighter design samples for ex-
amination and testing,

see

§ 173.308(b)(2).

The examination and testing of each light-
er design must be performed by a person
authorized by the Associate Administrator
under the provisions of subpart E of part
107 of this chapter, as specified in
§ 173.308(a)(4). For continued use of approv-
als dated prior to January 1, 2012,

see

§ 173.308(b)(5).
For non-pressurized lighters containing a

Class 3 (flammable liquid) material, its
design, description, and packaging must
be approved by the Associate Adminis-
trator prior to being offered for transpor-
tation or transported in commerce. In
addition, a lighter design intended to
contain a non-pressurized Class 3 mate-
rial is excepted from the examination
and testing criteria specified in
§ 173.308(b)(3). An unused lighter or a
lighter that is cleaned of residue and
purged of vapors is not subject to the re-
quirements of this subchapter.

169

This entry applies to lighter refills (

see

§ 171.8 of this subchapter) that contain a
Division 2.1 (flammable) gas but do not
contain an ignition device. Lighter refills
offered for transportation under this entry
may not exceed 4 fluid ounces capacity
(7.22 cubic inches) or contain more than 65
grams of fuel. A lighter refill exceeding 4
fluid ounces capacity (7.22 cubic inches) or
containing more than 65 grams of fuel
must be classed as a Division 2.1 material,
described with the proper shipping name
appropriate for the material, and packaged
in the packaging specified in part 173 of

this subchapter for the flammable gas con-
tained therein. In addition, a container ex-
ceeding 4 fluid ounces volumetric capacity
(7.22 cubic inches) or containing more than
65 grams of fuel may not be connected or
manifolded to a lighter or similar device
and must also be described and packaged
according to the fuel contained therein.
For transportation by passenger-carrying
aircraft, the net mass of lighter refills may
not exceed 1 kg per package, and, for
cargo-only aircraft, the net mass of lighter
refills may not exceed 15 kg per package.
See § 173.306(h) of this subchapter.

170

Air must be eliminated from the vapor

space by nitrogen or other means.

171

This entry may only be used when the

material is transported in non-friable tab-
let form or for granular or powered mix-
tures that have been shown to meet the PG
III criteria in § 173.127.

172

This entry includes alcohol mixtures

containing up to 5% petroleum products.

173

For adhesives, printing inks, printing

ink-related materials, paints, paint-related
materials, and resin solutions which are
assigned to UN3082, and do not meet the
definition of another hazard class, metal or
plastic packaging for substances of pack-
ing groups II and III in quantities of 5 L
(1.3 gallons) or less per packaging are not
required to meet the UN performance
package testing when transported:
a. Except for transportation by aircraft, in

palletized loads, a pallet box or unit load
device (

e.g.

individual packaging placed

or stacked and secured by strapping,
shrink or stretch-wrapping or other suit-
able means to a pallet). For vessel trans-
port, the palletized loads, pallet boxes or
unit load devices must be firmly packed
and secured in closed cargo transport
units; or

b. Except for transportation by aircraft, as

an inner packaging of a combination
packaging with a maximum net mass of
40 kg (88 pounds). For transportation by
aircraft, as an inner packaging of a com-
bination packaging with a maximum
gross mass of 30 kg when packaged as a
limited quantity in accordance with
§ 173.27(f).

175

This substance must be stabilized when

in concentrations of not more than 99%.

176

This entry must be used for formalde-

hyde solutions containing methanol as a
stabilizer. Formaldehyde solutions not
containing methanol and not meeting the
Class 3 flammable liquid criteria must be
described using a different proper shipping
name.

177

Gasoline, or, ethanol and gasoline mix-

tures, for use in internal combustion en-
gines (

e.g.

, in automobiles, stationary en-

gines and other engines) must be assigned
to Packing Group II regardless of vari-
ations in volatility.

background image

363

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

181

When a package contains a combination

of lithium batteries contained in equip-
ment and lithium batteries packed with
equipment, the following requirements
apply:
a. The shipper must ensure that all appli-

cable requirements of § 173.185 of this sub-
chapter are met. The total mass of lith-
ium batteries contained in any package
must not exceed the quantity limits in
columns (9A) and (9B) for passenger air-
craft or cargo aircraft, as applicable;

b. Except as provided in § 173.185(c)(3) of

this subchapter, the package must be
marked ‘‘UN 3091 Lithium metal bat-
teries packed with equipment’’, or ‘‘UN
3481 Lithium ion batteries packed with
equipment,’’ as appropriate. If a package
contains both lithium metal batteries
and lithium ion batteries packed with
and contained in equipment, the package
must be marked as required for both bat-
tery types. However, button cell bat-
teries installed in equipment (including
circuit boards) need not be considered;
and

c. The shipping paper must indicate ‘‘UN

3091 Lithium metal batteries packed with
equipment’’ or ‘‘UN 3481 Lithium ion bat-
teries packed with equipment,’’ as appro-
priate. If a package contains both lith-
ium metal batteries and lithium ion bat-
teries packed with and contained in
equipment, then the shipping paper must
indicate both ‘‘UN 3091 Lithium metal
batteries packed with equipment’’ and
‘‘UN 3481 Lithium ion batteries packed
with equipment.’’

182

Equipment containing only lithium bat-

teries must be classified as either UN 3091
or UN 3481.

196

The nitrocellulose must meet the cri-

teria of the Bergmann-Junk test or methyl
violet paper test in the UN Manual of Tests
and Criteria, Appendix 10 (IBR,

see

§ 171.7 of

this subchapter). Test of type 3(c) is not re-
quired.

197

The nitrocellulose must meet the cri-

teria of the Bergmann-Junk test or methyl
violet paper test in the UN Manual of Tests
and Criteria, Appendix 10 (IBR,

see

§ 171.7 of

this subchapter).

198

Nitrocellulose solutions containing not

more than 20% nitrocellulose may be
transported as paint, perfumery products,
or printing ink, as applicable, provided the
nitrocellulose contains no more 12.6% ni-
trogen (by dry mass).

See

UN1210, UN1263,

UN1266, UN3066, UN3469, and UN3470.

200

Division 1.4G consumer fireworks may

be certified for transportation by a DOT-
approved Fireworks Certification Agency
in accordance with the provisions of § 173.65
of this subchapter.

237

‘‘Batteries, dry, containing potassium

hydroxide solid,

electric storage’’

must be

prepared and packaged in accordance with

the requirements of § 173.159(a) and (c). For
transportation by aircraft, the provisions
of § 173.159(b)(2) apply. This entry may only
be used for the transport of non-activated
batteries that contain dry potassium hy-
droxide and that are intended to be acti-
vated prior to use by the addition of an ap-
propriate amount of water to the indi-
vidual cells.

238

Neutron radiation detectors: Neutron

radiation detectors containing non-pres-
surized boron trifluoride gas in excess of 1
gram (0.035 ounces) and radiation detection
systems containing such neutron radiation
detectors as components may be trans-
ported by highway, rail, vessel, or cargo
aircraft in accordance with the following:
a. Each radiation detector must meet the

following conditions:

(1) The pressure in each neutron radiation

detector must not exceed 105 kPa abso-
lute at 20

°

C (68

°

F);

(2) The amount of gas must not exceed 13

grams (0.45 ounces) per detector; and

(3) Each neutron radiation detector must

be of welded metal construction with
brazed metal to ceramic feed through as-
semblies. These detectors must have a
minimum burst pressure of 1800 kPa as
demonstrated by design type qualifica-
tion testing; and

(4) Each detector must be tested to a 1

×

10

¥

10

cm

3

/s leaktightness standard before

filling.

b. Radiation detectors transported as indi-

vidual components must be transported
as follows:

(1) They must be packed in a sealed inter-

mediate plastic liner with sufficient ab-
sorbent or adsorbent material to absorb
or adsorb the entire gas contents.

(2) They must be packed in strong outer

packagings and the completed package
must be capable of withstanding a 1.8
meter (5.9 feet) drop without leakage of
gas contents from detectors.

(3) The total amount of gas from all detec-

tors per outer packaging must not exceed
52 grams (1.83 ounces).

c. Completed neutron radiation detection

systems containing detectors meeting
the conditions of paragraph a of this spe-
cial provision must be transported as fol-
lows:

(1) The detectors must be contained in a

strong sealed outer casing;

(2) The casing must contain include suffi-

cient absorbent or adsorbent material to
absorb or adsorb the entire gas contents;

(3) The completed system must be packed

in strong outer packagings capable of
withstanding a 1.8 meter (5.9 feet) drop
test without leakage unless a system’s
outer casing affords equivalent protec-
tion.

background image

364

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

d. Except for transportation by aircraft,

neutron radiation detectors and radi-
ation detection systems containing such
detectors transported in accordance with
paragraph a of this special provision are
not subject to the labeling and
placarding requirements of part 172 of
this subchapter.

e. When transported by highway, rail, ves-

sel, or as cargo on an aircraft, neutron
radiation detectors containing not more
than 1 gram of boron trifluoride, includ-
ing those with solder glass joints are not
subject to any other requirements of this
subchapter provided they meet the re-
quirements in paragraph a of this special
provision and are packed in accordance
with paragraph b of this special provi-
sion. Radiation detection systems con-
taining such detectors are not subject to
any other requirements of this sub-
chapter provided they are packed in ac-
cordance with paragraph c of this special
provision.

325

In the case of non-fissile or fissile-ex-

cepted uranium hexafluoride, the material
must be classified under UN 2978.

328

When lithium metal or lithium ion bat-

teries are contained in the fuel cell system,
the item must be described under this
entry and the appropriate entries for
‘‘Lithium metal batteries contained in
equipment’’ or ‘‘Lithium ion batteries con-
tained in equipment’’.

332

Magnesium nitrate hexahydrate is not

subject to the requirements of this sub-
chapter.

335

Mixtures of solids that are not subject

to this subchapter and environmentally
hazardous liquids or solids may be classi-
fied as ‘‘Environmentally hazardous sub-
stances, solid, n.o.s,’’ UN3077 and may be
transported under this entry, provided
there is no free liquid visible at the time
the material is loaded or at the time the
packaging or transport unit is closed. Each
transport unit must be leakproof when
used as bulk packaging.

336

The use of UN1H1 drums, UN3H1

jerricans, and UN6HA1 composite pack-
agings which meet the requirements of
part 178 of the HMR at the Packing Group
I or II performance level. These packagings
are not required to: (1.) meet the venting
requirements in § 173.24(g) or (2.) be marked
with the hydrostatic pressure test marking
specified in § 173.24a(b)(4). Shipment of
packages under this special provision must
be made by private or contract motor car-
rier. Transportation of these packages also
requires the door of each van trailer to be
marked with ‘‘Warning trailer may contain
chemical vapor. Do not enter until vapors
have dissipated.’’ The driver of the trans-
port vehicle and the consignee(s) must be
trained not to enter the transport vehicle
until the ammonia vapors have dissipated,

and the emergency response information
on the shipping paper must indicate that
the vehicle contains ammonia vapors. This
training must be documented in training
records required by § 172.704(d). Transport
vehicles must be vented to prevent accu-
mulation of vapors at a poisonous or flam-
mable concentration.

337

Authorizes the use of regulated waste

containers manufactured prior to October
1, 2006 to be marked with the alternative
shipping name of Regulated medical waste,
UN3291 and arrows that deviate as pre-
scribed in § 172.312(a)(2) in that they may be
black or white.

338

Life Saving appliances, self-inflating

transported by motor vehicle only between
an U.S. Coast Guard approved inflatable
life raft servicing facility and a vessel are
only subject to the following requirements:
a. Prior to repacking into the life-saving

appliance, an installed inflation cylinder
must successfully meet and pass all in-
spection and test criteria and standards
of the raft manufacturer and the vessel
Flag State requirements for cylinders in-
stalled as part of life-saving appliances,
self-inflating (UN2990) used on marine
vessels. Additionally, each cylinder must
be visually inspected in accordance with
CGA pamphlet, CGA C–6 (incorporated by
reference, see § 171.7). A current copy of
CGA pamphlet, CGA C–6 must be avail-
able at the facility servicing the life-sav-
ing appliance.

b. An installed inflation cylinder that re-

quires recharging must be filled in ac-
cordance with § 173.301(l).

c. Every installed inflation cylinder, as as-

sociated equipment of the life-saving ap-
pliance, must be packed within the pro-
tective packaging of the life raft and the
life raft itself must otherwise be in com-
pliance with § 173.219.

d. The serial number for each cylinder

must be recorded as part of the life-sav-
ing appliance service record by the U.S.
Coast Guard-approved servicing facility.

340

This entry applies only to the vessel

transportation of nickel-metal hydride
batteries as cargo. Nickel-metal hydride
button cells or nickel-metal hydride cells
or batteries packed with or contained in
battery-powered devices transported by
vessel are not subject to the requirements
of this special provision.

See

‘‘Batteries,

dry, sealed, n.o.s.’’ in the § 172.101 Haz-
ardous Materials Table (HMT) of this part
for transportation requirements for nickel-
metal hydride batteries transported by
other modes and for nickel-metal hydride
button cells or nickel-metal hydride cells
or batteries packed with or contained in
battery-powered devices transported by
vessel. Nickel-metal hydride batteries sub-
ject to this special provision are subject
only to the following requirements: (1) The

background image

365

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

batteries must be prepared and packaged
for transport in a manner to prevent a dan-
gerous evolution of heat, short circuits,
and damage to terminals; and are subject
to the incident reporting in accordance
with § 171.16 of this subchapter if a fire, vio-
lent rupture, explosion or dangerous evo-
lution of heat (

i.e.,

an amount of heat suffi-

cient to be dangerous to packaging or per-
sonal safety to include charring of pack-
aging, melting of packaging, scorching of
packaging, or other evidence) occurs as a
direct result of a nickel metal hydride bat-
tery; and (2) when loaded in a cargo trans-
port unit in a total quantity of 100 kg gross
mass or more, the shipping paper require-
ments of Subpart C of this part, the mani-
fest requirements of § 176.30 of this sub-
chapter, and the vessel stowage require-
ments assigned to this entry in Column
(10) of the § 172.101 Hazardous Materials
Table.

342 Glass inner packagings (such as ampoules

or capsules) intended only for use in steri-
lization devices, when containing less than
30 mL of ethylene oxide per inner pack-
aging with not more than 300 mL per outer
packaging, may be transported in accord-
ance with § 173.4a of this subchapter, irre-
spective of the restriction of § 173.4a(b) and
the indication of ‘‘forbidden’’ in columns
(9A) and (9B) of the § 172.101 table provided
that:
a. After filling, each glass inner packaging

must be determined to be leak-tight by
placing the glass inner packaging in a
hot water bath at a temperature and for
a period of time sufficient to ensure that
an internal pressure equal to the vapor
pressure of ethylene oxide at 55

°

C is

achieved. Any glass inner packaging
showing evidence of leakage, distortion
or other defect under this test must not
be transported under the terms of this
special provision;

b. In addition to the packaging required in

§ 173.4a, each glass inner packaging must
be placed in a sealed plastic bag compat-
ible with ethylene oxide and capable of
containing the contents in the event of
breakage or leakage of the glass inner
packaging; and

c. Each glass inner packaging is protected

by a means of preventing puncture of the
plastic bag (

e.g.,

sleeves or cushioning) in

the event of damage to the packaging
(

e.g.,

by crushing).

343

A bulk packaging that emits hydrogen

sulfide in sufficient concentration that va-
pors evolved from the sour crude oil can
present an inhalation hazard must be
marked as specified in § 172.327.

345

‘‘Nitrogen, refrigerated liquid (

cryogenic

liquid

), UN1977’’ transported in open cryo-

genic receptacles with a maximum capac-
ity of 1 L are not subject to the require-
ments of this subchapter. The receptacles

must be constructed with glass double
walls having the space between the walls
vacuum insulated and each receptacle
must be transported in an outer packaging
with sufficient cushioning and absorbent
materials to protect the receptacle from
damage.

346

‘‘Nitrogen, refrigerated liquid (

cryogenic

liquid

), UN1977’’ transported in accordance

with the requirements for open cryogenic
receptacles in § 173.320 and this special pro-
vision are not subject to any other require-
ments of this subchapter. The receptacle
must contain no hazardous materials other
than the liquid nitrogen which must be
fully absorbed in a porous material in the
receptacle.

347

Effective July 1, 2011, for transportation

by aircraft, this entry may only be used if
the results of Test series 6(d) of Part I of
the UN Manual of Tests and Criteria (IBR,

see

§ 171.7 of this subchapter) have dem-

onstrated that any hazardous effects from
accidental functioning are confined to
within the package. Effective January 1,
2012, for transportation by vessel, this
entry may only be used if the results of
Test Series 6(d) of Part I of the UN Manual
of Tests and Criteria (IBR,

see

§ 171.7 of this

subchapter) have demonstrated that any
hazardous effects from accidental func-
tioning are confined to within the package.
Effective January 1, 2014, for transpor-
tation domestically by highway or rail,
this entry may only be used if the results
of Test Series 6(d) of Part I of the UN Man-
ual of Tests and Criteria (IBR,

see

§ 171.7 of

this subchapter) have demonstrated that
any hazardous effects from accidental
functioning are confined to within the
package. Testing must be performed or
witnessed by a person who is approved by
the Associate Administrator (

see

§ 173.56(b)

of this subchapter). All successfully con-
ducted tests or reassignment to another
compatibility group require the issuance of
a new or revised approval by the Associate
Administrator prior to transportation on
or after the dates specified for each author-
ized mode of transport in this special pro-
vision.

349

Mixtures of hypochlorite with an ammo-

nium salt are forbidden for transport. A
hypochlorite solution, UN1791, is a Class 8
corrosive material.

350

Ammonium bromate, ammonium bro-

mate aqueous solutions, and mixtures of a
bromate with an ammonium salt are for-
bidden for transport.

351

Ammonium chlorate, ammonium chlo-

rate aqueous solutions, and mixtures of a
chlorate with an ammonium salt are for-
bidden for transport.

352

Ammonium chlorite, ammonium chlo-

rite aqueous solutions, and mixtures of a
chlorite with an ammonium salt are for-
bidden for transport.

background image

366

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

353

Ammonium permanganate, ammonium

permanganate aqueous solutions, and mix-
tures of a permanganate with an ammo-
nium salt are forbidden for transport.

357

A bulk packaging that emits hydrogen

sulfide in sufficient concentration that va-
pors evolved from the crude oil can present
an inhalation hazard must be marked as
specified in § 172.327 of this part.

360

Vehicles powered only by lithium bat-

teries must be described using ‘‘UN3171,
Battery-powered vehicle.’’ Lithium bat-
teries installed in a cargo transport unit,
designed only to provide power external to
the transport unit, must be described using
‘‘UN3536, Lithium batteries installed in a
cargo transport unit.’’

361

Capacitors with an energy storage ca-

pacity of 0.3 Wh or less are not subject to
the requirements of this subchapter. En-
ergy storage capacity means the energy
held by a capacitor, as calculated using the
nominal voltage and capacitance. This
entry does not apply to capacitors that by
design maintain a terminal voltage (e.g.,
asymmetrical capacitors.)

362

This entry applies to liquids, pastes or

powders, pressurized with a propellant that
meets the definition of a gas in § 173.115. A
chemical under pressure packaged in an
aerosol dispenser must be transported
under UN1950. The chemical under pressure
must be classed based on the hazard char-
acteristics of the components in the pro-
pellant; the liquid; or the solid. The fol-
lowing provisions also apply:
a. If one of the components, which can be

a pure substance or a mixture, is classed
as flammable, the chemical under pres-
sure must be classed as flammable in Di-
vision 2.1. Flammable components are
flammable liquids and liquid mixtures,
flammable solids and solid mixtures or
flammable gases and gas mixtures meet-
ing the following criteria:

(1) A flammable liquid is a liquid having a

flashpoint of not more than 93

°

C (200

°

F);

(2) A flammable solid is a solid that meets

the criteria in § 173.124 of this subchapter;
or

(3) A flammable gas is a gas that meets the

criteria in § 173.115 of this subchapter.

b. Gases of Division 2.3 and gases with a

subsidiary risk of 5.1 must not be used as
a propellant in a chemical under pres-
sure.

c. Where the liquid or solid components are

classed as Division 6.1, Packing Group II
or III, or Class 8, Packing Group II or III,
the chemical under pressure must be as-
signed a subsidiary risk of Division 6.1 or
Class 8 and the appropriate identification
number must be assigned. Components
classed as Division 6.1, Packing Group I,
or Class 8, Packing Group I, must not be
offered for transportation and trans-
ported under this description.

d. A chemical under pressure with compo-

nents meeting the properties of: Class 1
(explosives); Class 3 (liquid desensitized
explosives); Division 4.1 (self-reactive
substances and solid desensitized explo-
sives); Division 4.2 (substances liable to
spontaneous combustion); Division 4.3
(substances which, in contact with
water, emit flammable gases or toxic
gases); Division 5.1 (oxidizing sub-
stances); Division 5.2 (organic peroxides);
Division 6.2 (Infectious substances); or,
Class 7 (Radioactive material), must not
be offered for transportation under this
description.

e. A description to which special provision

170 or TP7 is assigned in Column 7 of the
§ 172.101 Hazardous Materials Table, and
therefore requires air to be eliminated
from the package vapor space by nitro-
gen or other means, must not be offered
for transportation under this description.

f. Chemicals under pressure containing

components forbidden for transport on
both passenger and cargo aircraft in Col-
umns (9A) and (9B) of the § 172.101 Haz-
ardous Materials Table must not be
transported by air.

365

For manufactured instruments and arti-

cles containing mercury, see UN3506.

367

For the purposes of documentation and

package marking:
a. The proper shipping name ‘‘Paint re-

lated material’’ may be used for consign-
ments of packages containing ‘‘Paint’’
and ‘‘Paint related material’’ in the same
package;

b. The proper shipping name ‘‘Paint re-

lated material, corrosive, flammable’’
may be used for consignments of pack-
ages containing ‘‘Paint, corrosive, flam-
mable’’ and ‘‘Paint related material, cor-
rosive, flammable’’ in the same package;

c. The proper shipping name ‘‘Paint related

material, flammable, corrosive’’ may be
used for consignments of packages con-
taining ‘‘Paint, flammable, corrosive’’
and ‘‘Paint related material, flammable,
corrosive’’ in the same package; and

d. The proper shipping name ‘‘Printing ink

related material’’ may be used for con-
signments of packages containing
‘‘Printing ink’’ and ‘‘Printing ink related
material’’ in the same package.

368

In the case of non-fissile or fissile-ex-

cepted uranium hexafluoride, the material
must be classified under UN3507 or UN2978.

369

In the case of non-fissile or fissile-ex-

cepted uranium hexafluoride, the material
must be classified under UN 2978. Uranium
hexafluoride may be classified under this
entry only if the conditions of
§§ 173.420(a)(4) and (6) and (d) and 173.421(b)
and (d) of this subchapter, and, for fissile-
excepted material, the conditions of
§ 173.453 of this subchapter are met. In addi-
tion to the provisions applicable to the

background image

367

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

transport of Division 6.1 substances, the
provisions of §§ 173.421(c) and 173.443(a) of
this subchapter apply. In addition, pack-
ages shall be legibly and durably marked
with an identification of the consignor, the
consignee, or both. No Class 7 label is re-
quired to be displayed. The consignor shall
be in possession of a copy of each applica-
ble certificate when packages include
fissile material excepted by competent au-
thority approval. When a consignment is
undeliverable, the consignment shall be
placed in a safe location and the appro-
priate competent authority shall be in-
formed as soon as possible and a request
made for instructions on further action. If
it is evident that a package of radioactive
material, or conveyance carrying
unpackaged radioactive material, is leak-
ing, or if it is suspected that the package,
or conveyance carrying unpackaged mate-
rial, may have leaked, the requirements of
§ 173.443(e) of this subchapter apply.

370

This entry also applies to ammonium

nitrate with not more than 0.2% combus-
tible substances, including any organic
substance calculated as carbon, to the ex-
clusion of any added substance, that gives
a positive result when tested in accordance
with Test Series 2 of the UN Manual of
Tests and Criteria, Part I (IBR; see § 171.7
of this subchapter).

See also

UN1942 in the

§ 172.101 Hazardous Materials Table. This
entry may not be used for ammonium ni-
trate for which a proper shipping name al-
ready exists in the § 172.101 Hazardous Ma-
terials Table, including ammonium nitrate
mixed with fuel oil or any other commer-
cial grade of ammonium nitrate (

e.g.,

am-

monium nitrate fertilizer).

371

a. This entry also applies to articles not

conforming to the requirements of
§§ 173.302, 173.304, or 173.306 of this sub-
chapter, containing a small pressure recep-
tacle with a release device. Such articles
must comply with the following require-
ments:
(1) The water capacity of the pressure re-

ceptacle must not exceed 0.5 L and the
working pressure must not exceed 25 bar
at 15

°

C (59

°

F);

(2) The minimum burst pressure of the

pressure receptacle must be at least four
times the pressure of the gas at 15

°

C (59

°

F);

(3) Each article must be manufactured in

such a way that unintentional firing or
release is avoided under normal condi-
tions of handling, packing, transport and
use. This may be fulfilled by an addi-
tional locking device linked to the acti-
vator;

(4) Each article must be manufactured in

such a way as to prevent hazardous pro-
jections of the pressure receptacle or
parts of the pressure receptacle;

(5) Each pressure receptacle must be manu-

factured from material which will not
fragment upon rupture;

(6) The design type of the article must be

subjected to a fire test. For this test, the
provisions of paragraphs 16.6.1.2 except
letter g, 16.6.1.3.1 to 16.6.1.3.6, 16.6.1.3.7(b)
and 16.6.1.3.8 of the UN Manual of Tests
and Criteria must be applied. It must be
demonstrated that the article relieves its
pressure by means of a fire degradable
seal or other pressure relief device, in
such a way that the pressure receptacle
will not fragment and that the article or
fragments of the article do not rocket
more than 10 meters; and

(7) The design type of the article must be

subjected to the following test. A stimu-
lating mechanism must be used to ini-
tiate one article in the middle of the
packaging. There must be no hazardous
effects outside the package such as dis-
ruption of the package, metal fragments
or a receptacle which passes through the
packaging.

b. The manufacturer must produce tech-

nical documentation of the design type,
manufacture as well as the tests and
their results. The manufacturer must
apply procedures to ensure that articles
produced in series are made of good qual-
ity, conform to the design type and are
able to meet the requirements in (a). The
manufacturer must provide such infor-
mation to a representative of the Depart-
ment upon request.

372

This entry applies to asymmetric ca-

pacitors with an energy storage capacity
greater than 0.3 Wh. Capacitors with an en-
ergy storage capacity of 0.3 Wh or less are
not subject to the requirements of this
subchapter.
Energy storage capacity means the energy

stored in a capacitor, as calculated ac-
cording to the following equation,

Wh = 1/2C

N

(U

R

2

¥

U

L

2

×

(1/3600)

Using the nominal capacitance (C

N

), rated

voltage (U

R

) and the rated lower limit

voltage (U

L

).

Nickel-carbon asymmetric capacitors con-

taining Class 8 alkaline electrolytes
must be transported as UN2795, Bat-
teries, wet, filled with alkali, electric
storage.

379

When offered for transport by highway,

rail, or cargo vessel, anhydrous ammonia
adsorbed or absorbed on a solid contained
in ammonia dispensing systems or recep-
tacles intended to form part of such sys-
tems is not subject to the requirements of
this subchapter if the following conditions
in this provision are met. In addition to
meeting the conditions in this provision,
transport on cargo aircraft only may be
authorized with prior approval of the Asso-
ciate Administrator.

background image

368

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

a. The adsorption or absorption presents

the following properties:

(1) The pressure at a temperature of 20

°

(68

°

F) in the receptacle is less than 0.6

bar (60 kPa);

(2) The pressure at a temperature of 35

°

(95

°

F) in the receptacle is less than 1 bar

(100 kPa);

(3) The pressure at a temperature of 85

°

(185

°

F) in the receptacle is less than 12

bar (1200 kPa).

b. The adsorbent or absorbent material

shall not meet the definition or criteria
for inclusion in Classes 1 to 8;

c. The maximum contents of a receptacle

shall be 10 kg of ammonia; and

d. Receptacles containing adsorbed or ab-

sorbed ammonia shall meet the following
conditions:

(1) Receptacles shall be made of a material

compatible with ammonia as specified in
ISO 11114–1:2012(E) and ISO 11114–1:2012/
Amd 1:2017(E) (IBR,

see

§ 171.7 of this sub-

chapter);

(2) Receptacles and their means of closure

shall be hermetically sealed and able to
contain the generated ammonia;

(3) Each receptacle shall be able to with-

stand the pressure generated at 85

°

C (185

°

F) with a volumetric expansion no

greater than 0.1%;

(4) Each receptacle shall be fitted with a

device that allows for gas evacuation
once pressure exceeds 15 bar (1500 kPa)
without violent rupture, explosion or
projection; and

(5) Each receptacle shall be able to with-

stand a pressure of 20 bar (2000 kPa) with-
out leakage when the pressure relief de-
vice is deactivated.

e. When offered for transport in an ammo-

nia dispenser, the receptacles shall be
connected to the dispenser in such a way
that the assembly is guaranteed to have
the same strength as a single receptacle.

f. The properties of mechanical strength

mentioned in this special provision shall
be tested using a prototype of a recep-
tacle and/or dispenser filled to nominal
capacity, by increasing the temperature
until the specified pressures are reached.

g. The test results shall be documented,

shall be traceable, and shall be made
available to a representative of the De-
partment upon request.

380

For transportation by private carrier in

a motor carrier only, this material is not
subject to the segregation requirements of
§ 177.848(d) of this subchapter under the fol-
lowing conditions:
a. The material is packaged in a DOT Spec-

ification 4BW240 cylinder, or in a DOT–51
portable tank.

b. The material may only be loaded with

Class 3, Class 8, and Division 4.1 mate-
rials in Packing Group II or III.

c. The motor carrier must maintain a sat-

isfactory safety rating as prescribed in 49
CFR part 385.

381

For railroad flagging kits, see § 173.184

(c) of this subchapter.

382

Packages containing toy plastic or

paper caps for toy pistols described as
‘‘UN0349, Articles, explosive, n.o.s. (Toy
caps), 1.4S’’ or ‘‘NA0337, Toy caps, 1.4S’’ are
not subject to the subpart E (labeling) re-
quirements of this part when offered for
transportation by motor vehicle, rail
freight, cargo vessel, and cargo aircraft
and, notwithstanding the packing method
assigned in § 173.62 of this subchapter, in
conformance with the following condi-
tions:
a. The toy plastic or paper caps must be in

the form of sheets, strips, rolls, or indi-
vidual caps;

b. The caps must not contain more than an

average of twenty-five hundredths of a
grain of explosive composition per cap;

c. The caps must be packed inside pack-

agings constructed of cardboard not less
than 0.013-inch in thickness, metal not
less than 0.008-inch in thickness, non-
combustible plastic not less than 0.015-
inch in thickness, or a composite blister
package consisting of cardboard not less
than 0.013-inch in thickness and non-
combustible plastic not less than 0.005-
inch in thickness that completely en-
closes the caps;

d. The minimum dimensions of each side

and each end of the cardboard packaging
must be 1/8th inch in height or more;

e. The number of caps inside each pack-

aging must be limited so that not more
than 10 grains of explosives composition
may be packed into one cubic inch of
space, and not more than 17.5 grains of
the explosive composition of toy caps
may be packed in any inner packaging;

f. Inner packagings must be packed in

outer packagings meeting PG II perform-
ance criteria;

g. Toy caps may be packed with non-explo-

sive or non-flammable articles provided
the outer packagings are marked as pre-
scribed in this paragraph;

h. Toy paper caps of any kind must not be

packed in the same packaging with fire-
works;

i. The outside of each package must be

plainly marked ‘‘ARTICLES, EXPLO-
SIVES, N.O.S. (TOY CAPS)—HANDLE
CAREFULLY’’ OR ‘‘TOY CAPS—HAN-
DLE CAREFULLY’’; and

j. Explosives shipped in conformance with

this paragraph must have been examined
in accordance with § 173.56 of this sub-
chapter and approved by the Associate
Administrator.

383

For transportation by motor vehicle,

substances meeting the conditions for high
viscosity flammable liquids as prescribed

background image

369

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

in § 173.121(b)(1)(i), (b)(1)(ii), and (b)(1)(iv) of
this subchapter, may be reassigned to
Packing Group III under the following con-
ditions:
a. Packaging must be UN standard metal

drums attached with heavy duty steel
strapping to a pallet; and

b. The capacity of each drum must not ex-

ceed 220 L (58 gallons).

384

For green graphite electrodes and

shapes that are large single component
solid objects not subject to shifting, trans-
port in open rail flat cars, open bed motor
vehicles, and intermodal containers is also
authorized. The objects must be secured to
the flat car, motor vehicle, intermodal
container, or unitized by steel banding to
wooden runners or pallets and the units se-
cured to the flat car, motor vehicle, or
freight container to prevent shifting, in-
cluding relative motion between the ob-
jects, under conditions normally incident
to transportation. Stacking is permitted
two or more levels high to achieve max-
imum allowable utilization of the des-
ignated vehicle, rail car weight, or inter-
modal freight container weight or vessel
hold volume.

385

Notwithstanding the provisions of

§ 177.834(l) of this subchapter, cargo heaters
may be used when weather conditions are
such that the freezing of a wetted explosive
material is likely. Shipments must be
made by private, leased or contract carrier
vehicles under exclusive use of the offeror.
Cargo heaters must be reverse refrigera-
tion (heat pump) units. Shipments made in
accordance with this Special provision are
excepted from the requirements of
§ 173.60(b)(4) of this subchapter.

386

When transported by private motor car-

rier only, the following corrosive liquids
may be packaged in polyethylene bottles
with a capacity no greater than 3.785 L
(one gallon), further packed inside an
open-top, heavy wall, high density poly-
ethylene box (

i.e.,

crate) in a manner that

the polyethylene bottles are not subjected
to any superimposed weight, and the boxes
must be reasonably secured against shift-
ing within the transport vehicle and loaded
so as to minimize the possibility of coming
in contact with other lading:

Compounds, cleaning liquid, NA1760, PG II

or III;

Corrosive liquid, acidic, inorganic, n.o.s.,

UN3264, PG II;

Corrosive liquid, acidic, organic, n.o.s.,

UN3265, PG III;

Corrosive liquid, basic, inorganic, n.o.s.,

UN3266, PG II;

Hypochlorite solutions, UN1791, PG III;
Hydrochloric acid solution, UN1789, PG II;

and

Sulfuric acid, UN2796, PG II.

a. No more than four bottles, securely

closed with threaded caps, may be
packed in each box.

b. Each empty bottle must have a min-

imum weight of not less than 140 grams
and a minimum wall thickness of not
less than 0.020 inch (0.508 mm).

c. The completed package must meet the

Packing Group II performance level, as
applicable for combination packagings
with a plastic box outer packaging, in ac-
cordance with subpart M of part 178 of
this subchapter.

(i) Tests must be performed on each type

and size of bottle, for each manufac-
turing location. Samples taken at ran-
dom must withstand the prescribed tests
without breakage or leakage.

(ii) One bottle for every two hours of pro-

duction, or for every 2,500 bottles pro-
duced, must be tested by dropping a bot-
tle filled to 98 percent capacity with
water from a height of 1.2 meters (3.9
feet) onto solid concrete directly on the
closure.

(iii) A copy of the test results must be kept

on file at each facility where packagings
are offered for transportation, and must
be made available to a representative of
the Department upon request.

(iv) The name or symbol of the bottle pro-

ducer, and the month and year of manu-
facture, must be marked by embossing,
ink-jet printing of permanent ink, or
other permanent means on the face or
bottom of each bottle, in letters and
numbers at least 6 mm (0.2 inch) high.
Symbols, if used, must be registered with
the Associate Administrator.

(v) The box must be constructed from high-

density polyethylene in the density
range 0.950–0.962, and be capable of hold-
ing liquid when in the upright position.

387

When materials are stabilized by tem-

perature control, the provisions of
§ 173.21(f) of this subchapter apply. When
chemical stabilization is employed, the
person offering the material for transport
shall ensure that the level of stabilization
is sufficient to prevent the material as
packaged from dangerous polymerization
at 50

°

C(122

°

F). If chemical stabilization

becomes ineffective at lower temperatures
within the anticipated duration of trans-
port, temperature control is required and
is forbidden by aircraft. In making this de-
termination factors to be taken into con-
sideration include, but are not limited to,
the capacity and geometry of the pack-
aging and the effect of any insulation
present, the temperature of the material
when offered for transport, the duration of
the journey, and the ambient temperature
conditions typically encountered in the
journey (considering also the season of

background image

370

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

year), the effectiveness and other prop-
erties of the stabilizer employed, applica-
ble operational controls imposed by regu-
lation (

e.g.,

requirements to protect from

sources of heat, including other cargo car-
ried at a temperature above ambient) and
any other relevant factors. The provisions
of this special provision will be effective
until January 2, 2023, unless we terminate
them earlier or extend them beyond that
date by notice of a final rule in the F

ED

-

ERAL

R

EGISTER

388

a. Lithium batteries containing both

primary lithium metal cells and recharge-
able lithium ion cells that are not designed
to be externally charged, must meet the
following conditions:
i. The rechargeable lithium ion cells can

only be charged from the primary lith-
ium metal cells;

ii. Overcharge of the rechargeable lithium

ion cells is precluded by design;

iii. The battery has been tested as a pri-

mary lithium battery; and

iv. Component cells of the battery must be

of a type proved to meet the respective
testing requirements of the Manual of
Tests and Criteria, part III, subsection
38.3 (IBR, see § 171.7 of this subchapter).

b. Lithium batteries conforming to para-

graph a. of this special provision must be
assigned to UN Nos. 3090 or 3091, as ap-
propriate. When such batteries are trans-
ported in accordance with § 173.185(c), the
total lithium content of all lithium
metal cells contained in the battery
must not exceed 1.5 g and the total ca-
pacity of all lithium ion cells contained
in the battery must not exceed 10 Wh.

389

This entry only applies to lithium ion

batteries or lithium metal batteries in-
stalled in a cargo transport unit and de-
signed only to provide power external to
the cargo transport unit. The lithium bat-
teries must meet the requirements of
§ 173.185(a) and contain the necessary sys-
tems to prevent overcharge and over dis-
charge between the batteries. The bat-
teries must be securely attached to the in-
terior structure of the cargo transport unit
(

e.g.,

by means of placement in racks, cabi-

nets, etc.) in such a manner as to prevent
short circuits, accidental operation, and
significant movement relative to the cargo
transport unit under the shocks, loadings,
and vibrations normally incident to trans-
port. Hazardous materials necessary for
the safe and proper operation of the cargo
transport unit (

e.g.,

fire extinguishing sys-

tems and air conditioning systems), must
be properly secured to or installed in the
cargo transport unit and are not otherwise
subject to this subchapter. Hazardous ma-
terials not necessary for the safe and prop-
er operation of the cargo transport unit
must not be transported within the cargo
transport unit. The batteries inside the

cargo transport unit are not subject to
marking or labelling requirements of part
172 subparts D and E of this subchapter.
The cargo transport unit shall display the
UN number in a manner in accordance
with § 172.332 of this subchapter and be
placarded on two opposing sides. For trans-
portation by aircraft, cargo transport
units may only be offered for transpor-
tation and transported under conditions
approved by the Associate Administrator.

391

Except for articles being transported by

motor vehicle as a material of trade in ac-
cordance with § 173.6 of this subchapter, ar-
ticles containing hazardous materials of
Division 2.3, or Division 4.2, or Division 4.3,
or Division 5.1, or Division 5.2, or Division
6.1 (substances with an inhalation toxicity
of Packing Group I) and articles con-
taining more than one of the following haz-
ards: (1) Gases of Class 2; (2) Liquid desen-
sitized explosives of Class 3; or (3) Self-re-
active substances and solid desensitized ex-
plosives of Division 4.1, may only be of-
fered for transportation and transported
under conditions approved by the Asso-
ciate Administrator.

420

This entry does not apply to manufac-

tured articles (such as table tennis balls).

421

This entry will no longer be effective on

January 2, 2023, unless we terminate it ear-
lier or extend it beyond that date by notice
of a final rule in the F

EDERAL

R

EGISTER

422

When labelling is required, the label to

be used must be the label shown in § 172.447.
When a placard is displayed, the placard
must be the placard shown in § 172.560.

430

This entry shall only be used for solid

medical waste of Category A transported
for disposal.

440

When this material is transported by

tank car, the offeror must ensure each
tank car is remotely monitored for pres-
sure and location. Additionally, the offeror
must notify the carrier if the tank pres-
sure rise exceeds 3 psig over any 24-hour
period.

441

For marine pollutants transported

under ‘‘UN3077, Environmentally haz-
ardous substance, solid, n.o.s.’’ or ‘‘UN3082,
Environmentally hazardous substance, liq-
uid, n.o.s.’’ and for purposes of shipping
paper and package marking requirements,
the technical name used in association
with the basic description may be a proper
shipping name listed in the § 172.101 Haz-
ardous Material Table; provided that the
name chosen is not also an entry that in-
cludes ‘‘n.o.s.’’ as a part of the name or one
that has a ‘‘G’’ in column (1) of the table.

(2)

‘‘A’’ codes.

These provisions apply

only to transportation by aircraft:

Code/Special Provisions

A1

Single packagings are not permitted on

passenger aircraft.

background image

371

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

A2

Single packagings are not permitted on

aircraft.

A3

For combination packagings, if glass

inner packagings (including ampoules) are
used, they must be packed with absorbent
material in tightly closed rigid and leak-
proof receptacles before packing in outer
packagings.

A4

Liquids having an inhalation toxicity of

Packing Group I are not permitted on air-
craft.

A5

Solids having an inhalation toxicity of

Packing Group I are not permitted on pas-
senger aircraft and may not exceed a max-
imum net quantity per package of 15 kg (33
pounds) on cargo aircraft.

A6

For combination packagings, if plastic

inner packagings are used, they must be
packed in tightly closed metal receptacles
before packing in outer packagings.

A7

Steel packagings must be corrosion-re-

sistant or have protection against corro-
sion.

A8

For combination packagings, if glass

inner packagings (including ampoules) are
used, they must be packed with cushioning
material in tightly closed metal recep-
tacles before packing in outer packagings.

A9

For combination packagings, if plastic

bags are used, they must be packed in
tightly closed metal receptacles before
packing in outer packagings.

A10

When aluminum or aluminum alloy

construction materials are used, they must
be resistant to corrosion.

A11

For combination packagings, when

metal inner packagings are permitted,
only specification cylinders constructed of
metals which are compatible with the haz-
ardous material may be used.

A13

Bulk packagings are not authorized for

transportation by aircraft.

A14

This material is not authorized to be

transported as a limited quantity or con-
sumer commodity in accordance with
§ 173.306 of this subchapter when trans-
ported aboard an aircraft.

A19

Combination packagings consisting of

outer fiber drums or plywood drums, with
inner plastic packagings, are not author-
ized for transportation by aircraft.

A20

Plastic bags as inner receptacles of

combination packagings are not authorized
for transportation by aircraft.

A29

Combination packagings consisting of

outer expanded plastic boxes with inner
plastic bags are not authorized for trans-
portation by aircraft.

A30

Ammonium permanganate is not au-

thorized for transportation on aircraft.

A34

Aerosols containing a corrosive liquid

in Packing Group II charged with a gas are
not permitted for transportation by air-
craft.

A35

This includes any material which is not

covered by any of the other classes but
which has an anesthetic, narcotic, noxious

or other similar properties such that, in
the event of spillage or leakage on an air-
craft, extreme annoyance or discomfort
could be caused to crew members so as to
prevent the correct performance of as-
signed duties.

A37

This entry applies only to a material

meeting the definition in § 171.8 of this sub-
chapter for self-defense spray.

A51

For aircraft batteries, irrespective of

the quantity limitations specified in Col-
umn (9A) of the § 172.101 Table or § 175.75(c),
wet cell batteries, UN2794 or UN2795, up to
a limit of 100 kg net mass per package may
be transported aboard passenger aircraft.
Transport in accordance with this special
provision must be noted on the shipping
paper.

A53

Refrigerating machines and refrig-

erating machine components are not sub-
ject to the requirements of this subchapter
when containing less than 12 kg (26.4
pounds) of a non-flammable gas or when
containing 12 L (3 gallons) or less of ammo-
nia solution (UN2672) (see § 173.307 of this
subchapter).

A54

Irrespective of the quantity limits in

Column 9B of the § 172.101 table, a lithium
battery, including a lithium battery
packed with, or contained in, equipment
that otherwise meets the applicable re-
quirements of § 173.185, may have a mass
exceeding 35 kg if approved by the Asso-
ciate Administrator prior to shipment.

A56

Radioactive material with a subsidiary

hazard of Division 4.2, Packing Group I,
must be transported in Type B packages
when offered for transportation by air-
craft. Where the subsidiary hazard mate-
rial is ‘‘Forbidden’’ in column (9A) or (9B)
of the § 172.101 Table, the radioactive mate-
rial may only be offered for transportation
and transported by aircraft under condi-
tions approved by the Associate Adminis-
trator.

A60

Sterilization devices, when containing

less than 30 mL per inner packaging with
not more than 150 mL per outer packaging,
may be transported in accordance with the
provisions in § 173.4a, irrespective of
§ 173.4a(b), provided such packagings were
first subjected to comparative fire testing.
Comparative fire testing between a pack-
age as prepared for transport (including
the substance to be transported) and an
identical package filled with water must
show that the maximum temperature
measured inside the packages during test-
ing does not differ by more than 200

°

C (392

°

F). Packagings may include a vent to per-

mit the slow escape of gas (

i.e.

not more

than 0.1 mL/hour per 30 mL inner pack-
aging at 20

°

C (68

°

F) produced from grad-

ual decomposition. The requirements of
§§ 173.24(g)(1) and 173.27(c) do not apply.

A61 a. When used for purposes such as steri-

lization, inner packagings of peroxyacetic

background image

372

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

acid, stabilized, classified as UN 3107 Or-
ganic peroxide type E, liquid or UN 3109 Or-
ganic peroxide type F, liquid may be fitted
with a vent consisting of hydrophobic
membrane, provided:
(1) Each inner packaging contains not

more than 70 mL;

(2) The inner packaging is designed so that

the vent is not immersed in liquid in any
orientation;

(3) Each inner packaging is enclosed in an

intermediate rigid plastic packaging
with a small opening to permit release of
gas and contains a buffer that neutral-
izes the contents of the inner packaging
in the event of leakage;

(4) Intermediate packagings are packed in

a fiberboard box (4G) outer packaging;

(5) Each outer packaging contains not

more than 1.4 L of liquid; and

(6) The rate of oxygen release from the

outer packaging does not exceed 15 mL
per hour.

b. Such packages must be transported on

cargo aircraft only. The requirements of
§§ 173.24(g)(1) and 173.27(c) do not apply.

A82

The quantity limits in columns (9A)

and (9B) do not apply to human or animal
body parts, whole organs or whole bodies
known to contain or suspected of con-
taining an infectious substance.

A100

Lithium ion cells and batteries must

be offered for transport at a state of charge
not exceeding 30 percent of their rated ca-
pacity. Lithium ion cells and batteries at a
state of charge greater than 30 percent of
their rated capacity may only be trans-
ported under conditions approved by the
Associate Administrator in accordance
with the requirements in 49 CFR part 107,
subpart H. Guidance and methodology for
determining the rated capacity can be
found in sub-section 38.3.2.3 of the UN Man-
ual of Tests and Criteria (IBR,

see

§ 171.7 of

this subchapter).

A101

In addition to the applicable require-

ments of § 173.185, the quantity of lithium
metal in the batteries contained in any
piece of equipment must not exceed 12 g
per cell and 500 g per battery.

A105

a. This entry applies to machinery or

apparatus containing hazardous materials
as a residue or as an integral element of
the machinery or apparatus. It must not be
used for machinery or apparatus for which
a proper shipping name already exists in
the § 172.101 Table.
b. Where the quantity of hazardous mate-

rials contained as an integral element in
machinery or apparatus exceeds the lim-
its permitted by § 173.222(c)(2), and the
hazardous materials meet the provisions
of § 173.222(c), the machinery or appa-
ratus may be transported by aircraft
only with the prior approval of the Asso-
ciate Administrator.

A112

Notwithstanding the quantity limits

shown in Column (9A) and (9B) for this
entry, the following IBCs are authorized
for transportation aboard passenger and
cargo-only aircraft. Each IBC may not ex-
ceed a maximum net quantity of 1,000 kg:
a. Metal: 11A, 11B, 11N, 21A, 21B and 21N
b. Rigid plastics: 11H1, 11H2, 21H1 and 21H2
c. Composite with plastic inner receptacle:

11HZ1, 11HZ2, 21HZ1 and 21HZ2

d. Fiberboard: 11G
e. Wooden: 11C, 11D and 11F (with inner lin-

ers)

f. Flexible: 13H2, 13H3, 13H4, 13H5, 13L2,

13L3, 13L4, 13M1 and 13M2 (flexible IBCs
must be sift-proof and water resistant or
must be fitted with a sift-proof and water
resistant liner).

A189

Except where the defining criteria of

another class or division are met, con-
centrations of formaldehyde solution:
a. With less than 25 percent but not less

than 10 percent formaldehyde, must be
described as UN3334, Aviation regulated
liquid, n.o.s.; and

b. With less than 10 percent formaldehyde,

are not subject to this subchapter.

A191

Notwithstanding the Division 6.1 sub-

sidiary risk for this description, the toxic
subsidiary risk label and the requirement
to indicate the subsidiary risk on the ship-
ping paper are not required for manufac-
tured articles containing less than 5 kg (11
pounds) of mercury.

A200

These articles must be transported as

cargo and may not be carried aboard an
aircraft by passengers or crewmembers in
carry-on baggage, checked baggage, or on
their person unless specifically authorized
in § 175.10.

A210

This substance is forbidden for trans-

port by air. It may be transported on cargo
aircraft only with the prior approval of the
Associate Administrator.

A212

‘‘UN 2031, Nitric acid

, other than red

fuming, with more than 20% and less than
65% nitric acid’’

intended for use in steri-

lization devices only, may be transported
on passenger aircraft irrespective of the in-
dication of ‘‘forbidden’’ in columns (9A) of
the § 172.101 table provided that:
a. Each inner packaging contains not more

than 30 mL;

b. Each inner packaging is contained in a

sealed leak-proof intermediate packaging
with sufficient absorbent material capa-
ble of containing the contents of the
inner packaging;

c. Intermediate packagings are securely

packed in an outer packaging of a type
permitted by § 173.158(g) of this sub-
chapter which meet the requirements of
part 178 of this subchapter at the Pack-
ing Group I performance level;

d. The maximum quantity of nitric acid in

the package does not exceed 300 mL; and

background image

373

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

e. Transport in accordance with this spe-

cial provision must be noted on the ship-
ping paper.

(3)

‘‘B’’ codes.

These provisions apply

only to bulk packagings. Except as
otherwise provided in this subchapter,
these special provisions do not apply to
UN portable tanks or IBCs:

Code/Special Provisions

B1

If the material has a flash point at or

above 38

°

C (100

°

F) and below 93

°

C (200

°

F),

then the bulk packaging requirements of
§ 173.241 of this subchapter are applicable.
If the material has a flash point of less
than 38

°

C (100

°

F), then the bulk packaging

requirements of § 173.242 of this subchapter
are applicable.

B2

MC 300, MC 301, MC 302, MC 303, MC 305,

and MC 306 and DOT 406 cargo tanks are
not authorized.

B3

MC 300, MC 301, MC 302, MC 303, MC 305,

and MC 306 and DOT 406 cargo tanks and
DOT 57 portable tanks are not authorized.

B4

MC 300, MC 301, MC 302, MC 303, MC 305,

and MC 306 and DOT 406 cargo tanks are
not authorized.

B5

Only ammonium nitrate solutions with

35 percent or less water that will remain
completely in solution under all conditions
of transport at a maximum lading tem-
perature of 116

°

C (240

°

F) are authorized

for transport in the following bulk pack-
agings: MC 307, MC 312, DOT 407 and DOT
412 cargo tanks with at least 172 kPa (25
psig) design pressure. The packaging shall
be designed for a working temperature of
at least 121

°

C (250

°

F). Only Specifications

MC 304, MC 307 or DOT 407 cargo tank
motor vehicles are authorized for transpor-
tation by vessel.

B6

Packagings shall be made of steel.

B7

Safety relief devices are not authorized

on multi-unit tank car tanks. Openings for
safety relief devices on multi-unit tank car
tanks shall be plugged or blank flanged.

B8

Packagings shall be made of nickel,

stainless steel, or steel with nickel, stain-
less steel, lead or other suitable corrosion
resistant metallic lining.

B9

Bottom outlets are not authorized.

B10

MC 300, MC 301, MC 302, MC 303, MC 305,

and MC 306 and DOT 406 cargo tanks, and
DOT 57 portable tanks are not authorized.

B11

Tank car tanks must have a test pres-

sure of at least 2,068.5 kPa (300 psig). Cargo
and portable tanks must have a design
pressure of at least 1,207 kPa (175 psig).

B13

A nonspecification cargo tank motor

vehicle authorized in § 173.247 of this sub-
chapter must be at least equivalent in de-
sign and in construction to a DOT 406
cargo tank or MC 306 cargo tank (if con-
structed before August 31, 1995), except as
follows:

a. Packagings equivalent to MC 306 cargo

tanks are excepted from the certifi-
cation, venting, and emergency flow re-
quirements of the MC 306 specification.

b. Packagings equivalent to DOT 406 cargo

tanks are excepted from §§ 178.345–7(d)(5),
circumferential reinforcements; 178.345–
10, pressure relief; 178.345–11, outlets;
178.345–14, marking, and 178.345–15, cer-
tification.

c. Packagings are excepted from the design

stress limits at elevated temperatures, as
described in Section VIII of the ASME
Code (IBR, see § 171.7 of this subchapter).
However, the design stress limits may
not exceed 25 percent of the stress for 0
temper at the maximum design tempera-
ture of the cargo tank, as specified in the
Aluminum Association’s ‘‘Aluminum
Standards and Data’’ (IBR, see § 171.7 of
this subchapter).

B14

Each bulk packaging, except a tank car

or a multi-unit-tank car tank, must be in-
sulated with an insulating material so that
the overall thermal conductance at 15.5

°

(60

°

F) is no more than 1.5333 kilojoules per

hour per square meter per degree Celsius
(0.075 Btu per hour per square foot per de-
gree Fahrenheit) temperature differential.
Insulating materials must not promote
corrosion to steel when wet.

B15

Packagings must be protected with

non-metallic linings impervious to the lad-
ing or have a suitable corrosion allowance.

B16

The lading must be completely covered

with nitrogen, inert gas or other inert ma-
terials.

B18

Open steel hoppers or bins are author-

ized.

B23

Tanks must be made of steel that is

rubber lined or unlined. Unlined tanks
must be passivated before being placed in
service. If unlined tanks are washed out
with water, they must be repassivated
prior to return to service. Lading in un-
lined tanks must be inhibited so that the
corrosive effect on steel is not greater than
that of hydrofluoric acid of 65 percent con-
centration.

B25

Packagings must be made from monel

or nickel or monel-lined or nickel-lined
steel.

B26

Tanks must be insulated. Insulation

must be at least 100 mm (3.9 inches) except
that the insulation thickness may be re-
duced to 51 mm (2 inches) over the exterior
heater coils. Interior heating coils are not
authorized. The packaging may not be
loaded with a material outside of the pack-
aging’s design temperature range. In addi-
tion, the material also must be covered
with an inert gas or the container must be
filled with water to the tank’s capacity.
After unloading, the residual material also
must be covered with an inert gas or the
container must be filled with water to the
tank’s capacity.

background image

374

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

B27

Tanks must have a service pressure of

1,034 kPa (150 psig). Tank car tanks must
have a test pressure rating of 1,379 kPa (200
psig). Lading must be blanketed at all
times with a dry inert gas at a pressure not
to exceed 103 kPa (15 psig).

B28

Packagings must be made of stainless

steel.

B30

MC 312, MC 330, MC 331 and DOT 412

cargo tanks and DOT 51 portable tanks
must be made of stainless steel, except
that steel other than stainless steel may
be used in accordance with the provisions
of § 173.24b(b) of this subchapter. Thickness
of stainless steel for tank shell and heads
for cargo tanks and portable tanks must be
the greater of 7.62 mm (0.300 inch) or the
thickness required for a tank with a design
pressure at least equal to 1.5 times the
vapor pressure of the lading at 46

°

C (115

°

F). In addition, MC 312 and DOT 412 cargo

tank motor vehicles must:
a. Be ASME Code (U) stamped for 100% ra-

diography of all pressure-retaining welds;

b. Have accident damage protection which

conforms with § 178.345–8 of this sub-
chapter;

c. Have a MAWP or design pressure of at

least 87 psig: and

d. Have a bolted manway cover.

B32

MC 312, MC 330, MC 331, DOT 412 cargo

tanks and DOT 51 portable tanks must be
made of stainless steel, except that steel
other than stainless steel may be used in
accordance with the provisions of
§ 173.24b(b) of this subchapter. Thickness of
stainless steel for tank shell and heads for
cargo tanks and portable tanks must be
the greater of 6.35 mm (0.250 inch) or the
thickness required for a tank with a design
pressure at least equal to 1.3 times the
vapor pressure of the lading at 46

°

C (115

°

F). In addition, MC 312 and DOT 412 cargo

tank motor vehicles must:

a. Be ASME Code (U) stamped for 100% radi-

ography of all pressure-retaining welds;

b. Have accident damage protection which

conforms with § 178.345–8 of this sub-
chapter;

c. Have a MAWP or design pressure of at

least 87 psig; and

d. Have a bolted manway cover.
B33

MC 300, MC 301, MC 302, MC 303, MC 305,

MC 306, and DOT 406 cargo tanks equipped
with a 1 psig normal vent used to transport
gasoline must conform to Table I of this
Special Provision. Based on the volatility
class determined by using ASTM D 439 and
the Reid vapor pressure (RVP) of the par-
ticular gasoline, the maximum lading pres-
sure and maximum ambient temperature
permitted during the loading of gasoline
may not exceed that listed in Table I.

T

ABLE

I—M

AXIMUM

A

MBIENT

T

EMPERATURE

—

G

ASOLINE



ASTM D439 volatility class

Maximum lading and
ambient temperature

(see note 1)

A ........................................................

131

°

(RVP

≤

9.0 psia)

B ........................................................

124

°

(RVP

≤

10.0 psia)

C ........................................................

116

°

(RVP

≤

11.5 psia)

D ........................................................

107

°

(RVP

≤

13.5 psia)

E ........................................................

100

°

(RVP

≤

15.0 psia)

N

OTE

1: Based on maximum lading pressure of 1 psig at

top of cargo tank.

B35

Tank cars containing hydrogen cyanide

may be alternatively marked
‘‘Hydrocyanic acid, liquefied’’ if otherwise
conforming to marking requirements in
subpart D of this part. Tank cars marked
‘‘HYDROCYANIC ACID’’ prior to October
1, 1991 do not need to be remarked.

B42

Tank cars constructed before March 16,

2009, must have a test pressure of 34.47 Bar
(500 psig) or greater and conform to Class
105J. Each tank car must have a reclosing
pressure relief device having a start-to-dis-
charge pressure of 10.34 Bar (150 psig). The
tank car specification may be marked to
indicate a test pressure of 13.79 Bar (200
psig).

B44

All parts of valves and safety relief de-

vices in contact with lading must be of a
material which will not cause formation of
acetylides.

B45

Each tank must have a reclosing com-

bination pressure relief device equipped
with stainless steel or platinum rupture
discs approved by the AAR Tank Car Com-
mittee.

B46

The detachable protective housing for

the loading and unloading valves of multi-
unit tank car tanks must withstand tank
test pressure and must be approved by the
Associate Administrator.

B47

Each tank may have a reclosing pres-

sure relief device having a start-to-dis-
charge pressure setting of 310 kPa (45 psig).

B48

Portable tanks in sodium metal service

may be visually inspected at least once
every 5 years instead of being retested
hydrostatically. Date of the visual inspec-
tion must be stenciled on the tank near
the other required markings.

B49

Tanks equipped with interior heater

coils are not authorized. Single unit tank
car tanks must have a reclosing pressure
relief device having a start-to-discharge
pressure set at no more than 1551 kPa (225
psig).

B52

Notwithstanding the provisions of

§ 173.24b of this subchapter, non-reclosing
pressure relief devices are authorized on
DOT 57 portable tanks.

background image

375

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

B53

Packagings must be made of either alu-

minum or steel.

B54

Open-top, sift-proof rail cars are also

authorized.

B55

Water-tight, sift-proof, closed-top,

metal-covered hopper cars, equipped with a
venting arrangement (including flame ar-
restors) approved by the Associate Admin-
istrator are also authorized.

B56

Water-tight, sift-proof, closed-top,

metal-covered hopper cars are also author-
ized if the particle size of the hazardous
material is not less than 149 microns.

B57

Class 115A tank car tanks used to trans-

port chloroprene must be equipped with a
non-reclosing pressure relief device of a di-
ameter not less than 305 mm (12 inches)
with a maximum rupture disc pressure of
310 kPa (45 psig).

B59

Water-tight, sift-proof, closed-top,

metal-covered hopper cars are also author-
ized provided that the lading is covered
with a nitrogen blanket.

B61

Written procedures covering details of

tank car appurtenances, dome fittings,
safety devices, and marking, loading, han-
dling, inspection, and testing practices
must be approved by the Associate Admin-
istrator before any single unit tank car
tank is offered for transportation.

B65

Tank cars constructed before March 16,

2009, must have a test pressure of 34.47 Bar
(500 psig) or greater and conform to Class
105A. Each tank car must have a reclosing
pressure relief device having a start-to-dis-
charge pressure of 15.51 Bar (225 psig). The
tank car specification may be marked to
indicate a test pressure of 20.68 Bar (300
psig).

B66

Each tank must be equipped with gas

tight valve protection caps. Outage must
be sufficient to prevent tanks from becom-
ing liquid full at 55

°

C (130

°

F). Specifica-

tion 110A500W tanks must be stainless
steel.

B67

All valves and fittings must be pro-

tected by a securely attached cover made
of metal not subject to deterioration by
the lading, and all valve openings, except
safety valve, must be fitted with screw
plugs or caps to prevent leakage in the
event of valve failure.

B68

Sodium must be in a molten condition

when loaded and allowed to solidify before
shipment. Outage must be at least 5 per-
cent at 98

°

C (208

°

F). Bulk packagings

must have exterior heating coils fusion
welded to the tank shell which have been
properly stress relieved. The only tank car
tanks authorized are Class DOT 105 tank
cars having a test pressure of 2,069 kPa (300
psig) or greater.

B69

Dry sodium cyanide or potassium cya-

nide may be shipped in the following sift-
proof and weather-resistant packagings:
metal covered hopper cars, covered motor

vehicles, portable tanks, or non-specifica-
tion bins.

B70

If DOT 103ANW tank car tank is used:

All cast metal in contact with the lading
must have 96.7 percent nickel content; and
the lading must be anhydrous and free
from any impurities.

B76

Tank cars constructed before March 16,

2009, must have a test pressure of 20.68 Bar
(300 psig) or greater and conform to Class
105S, 112J, 114J or 120S. Each tank car
must have a reclosing pressure relief de-
vice having a start-to-discharge pressure of
10.34 Bar (150 psig). The tank car specifica-
tion may be marked to indicate a test pres-
sure of 13.79 Bar (200 psig).

B77

Other packaging are authorized when

approved by the Associate Administrator.

B78

Tank cars must have a test pressure of

4.14 Bar (60 psig) or greater and conform to
Class 103, 104, 105, 109, 111, 112, 114 or 120.
Heater pipes must be of welded construc-
tion designed for a test pressure of 500 psig.
A 25 mm (1 inch) woven lining of asbestos
or other approved material must be placed
between the bolster slabbing and the bot-
tom of the tank. If a tank car tank is
equipped with a non-reclosing pressure re-
lief device, the rupture disc must be per-
forated with a 3.2 mm (0.13 inch) diameter
hole. If a tank car tank is equipped with a
reclosing pressure relief valve, the tank
must also be equipped with a vacuum relief
valve.

B80

Each cargo tank must have a minimum

design pressure of 276 kPa (40 psig).

B81

Venting and pressure relief devices for

tank car tanks and cargo tanks must be
approved by the Associate Administrator.

B82

Cargo tanks and portable tanks are not

authorized.

B83

Bottom outlets are prohibited on tank

car tanks transporting sulfuric acid in con-
centrations over 65.25 percent.

B84

Packagings must be protected with

non-metallic linings impervious to the lad-
ing or have a suitable corrosion allowance
for sulfuric acid or spent sulfuric acid in
concentration up to 65.25 percent.

B85

Cargo tanks must be marked with the

name of the lading in accordance with the
requirements of § 172.302(b).

B90

Steel tanks conforming or equivalent

to ASME specifications which contain
solid or semisolid residual motor fuel anti-
knock mixture (including rust, scale, or
other contaminants) may be shipped by
rail freight or highway. The tank must
have been designed and constructed to be
capable of withstanding full vacuum. All
openings must be closed with gasketed
blank flanges or vapor tight threaded clo-
sures.

B115

Rail cars, highway trailers, roll-on/

roll-off bins, or other non-specification
bulk packagings are authorized. Pack-
agings must be sift-proof, prevent liquid

background image

376

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

water from reaching the hazardous mate-
rial, and be provided with sufficient vent-
ing to preclude dangerous accumulation of
flammable, corrosive, or toxic gaseous
emissions such as methane, hydrogen, and
ammonia. The material must be loaded
dry.

B116

The use of non specification, sift-proof

dump or hopper type vehicles, and sift-
proof roll-on/roll-off bulk bins, which must
be covered by a tarpaulin, metal cover, or
equivalent means is authorized for the
transportation of spent bleaching earth by
motor vehicle. The material is also be sub-
ject to operational controls which include
not exceeding a temperature of 55C (130F)
at the time it is offered or during transpor-
tation, not exceeding a transportation
time of 24 hours, and drivers transporting
spent bleaching earth must be trained in
the properties and hazards of the spent
bleaching earth. This training must be doc-
umented in training records required by
§ 172.704(d).

B120

The use of flexible bulk containers

conforming to the requirements in subpart
R and subpart S of part 178 of this sub-
chapter is permitted.

B130

When transported by motor vehicle,

used diatomaceous earth filter material is
not subject to any other requirements of
this subchapter except for the shipping
paper requirements of subpart C of part 172
of this subchapter; emergency response in-
formation as required by § 172.602(a)(2)
through (a)(7) of this subchapter; and the
marking requirements of § 172.302 of this
subchapter, if the following requirements
are met:
a. Packagings are non-DOT specification

sift-proof motor vehicles or sift-proof
roll-on/roll-off bulk bins, which are cov-
ered by a tarpaulin or other equivalent
means.

b. The temperature of the material at the

time it is offered for transport and dur-
ing transportation may not exceed 55

°

(130

°

F).

c. The time between offering the material

for transportation at the point of origin,
and unloading the material at the des-
tination does not exceed 48 hours.

d. In addition to the training requirements

prescribed in §§ 172.700 through 172.704,
each driver must be trained regarding
the properties and hazards of diatoma-
ceous earth filter material, precautions
to ensure safe transport of the material,
and actions to be taken in the event of
an emergency during transportation, or a
substantial delay in transit.

B131

When transported by highway, rail, or

cargo vessel, waste Paint and Paint related
material (UN1263; PG II and PG III), when
in plastic or metal inner packagings of not
more than 26.5 L (7 gallons), are excepted
from the marking requirements in

§ 172.301(a) and (c) and the labeling require-
ments in § 172.400(a), when further packed
in the following specification and non-
specification bulk outer packagings and
under the following conditions:
a. Primary receptacles must conform to

the general packaging requirements of
subpart B of part 173 of this subchapter
and may not leak. If they do leak, they
must be overpacked in packagings con-
forming to the specification require-
ments of part 178 of this subchapter or in
salvage packagings conforming to the re-
quirements in § 173.12 of this subchapter.

b. Primary receptacles must be further

packed in non-specification bulk outer
packagings such as cubic yard boxes,
plastic rigid-wall bulk containers, dump
trailers, and roll-off containers. Bulk
outer packagings must be liquid tight
through design or by the use of lining
materials.

c. Primary receptacles may also be further

packed in specification bulk outer pack-
agings. Authorized specification bulk
outer packagings are UN11G fiberboard
intermediate bulk containers (IBC) and
UN13H4 woven plastic, coated and with
liner flexible intermediate bulk con-
tainers (FIBCs) meeting the Packing
Group II performance level and lined
with a plastic liner of at least 6 mil
thickness.

d. All inner packagings placed inside bulk

outer packagings must be blocked and
braced to prevent shifting during trans-
portation that could cause the container
to open or fall over. Specification IBCs
and FIBCs are to be secured to a pallet.

B132

Except for transportation by aircraft,

UN2813, Water reactive solid, n.o.s. (con-
tains magnesium, magnesium nitrides) in
PG II or III may be packaged in sift-proof
bulk packagings that prevent liquid from
reaching the hazardous material with suffi-
cient venting to preclude dangerous accu-
mulation of flammable, corrosive or toxic
gaseous emissions such as methane, hydro-
gen and ammonia.

B133

Hydrochloric acid concentration not

exceeding 38%, in Packing Group II, is au-
thorized to be packaged in UN31H1 or
UN31HH1 intermediate bulk containers
when loaded in accordance with the re-
quirements of § 173.35(h) of this subchapter.

B134

For Large Packagings offered for

transport by vessel, flexible or fibre inner
packagings shall be sift-proof and water-
resistant or shall be fitted with a sift-proof
and water-resistant liner.

B135

For Large Packagings offered for

transport by vessel, flexible or fibre inner
packagings shall be hermetically sealed.

B136

Non-specification closed bulk bins are

authorized.

background image

377

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

(4)

IB Codes and IP Codes.

These pro-

visions apply only to transportation in
IBCs and Large Packagings. Table 1 au-
thorizes IBCs for specific proper ship-
ping names through the use of IB Codes
assigned in the § 172.101 table of this
subchapter. Table 2 defines IP Codes on
the use of IBCs that are assigned to
specific commodities in the § 172.101
Table of this subchapter. Table 3 au-
thorizes Large Packagings for specific
proper shipping names through the use
of IB Codes assigned in the § 172.101
table of this subchapter. Large Pack-
agings are authorized for the Packing
Group III entries of specific proper
shipping names when either special

provision IB3 or IB8 is assigned to that
entry in the § 172.101 Table. When no IB
code is assigned in the § 172.101 Table
for a specific proper shipping name, or
in § 173.185 or § 173.225(e) Organic Per-
oxide Table for Type F organic perox-
ides, use of an IBC or Large Packaging
for the material may be authorized
when approved by the Associate Ad-
ministrator. The letter ‘‘Z’’ shown in
the marking code for composite IBCs
must be replaced with a capital code
letter designation found in
§ 178.702(a)(2) of this subchapter to
specify the material used for the other
packaging. Tables 1, 2, and 3 follow:

T

ABLE

1—IB C

ODES

(IBC C

ODES

IBC code

Authorized IBCs

IB1 .............................

Authorized IBCs: Metal (31A, 31B and 31N).
Additional Requirement: Only liquids with a vapor pressure less than or equal to 110 kPa at 50

°

C (1.1

bar at 122

°

F), or 130 kPa at 55

°

C (1.3 bar at 131

°

F) are authorized.

IB2 .............................

Authorized IBCs: Metal (31A, 31B and 31N); Rigid plastics (31H1 and 31H2); Composite (31HZ1).
Additional Requirement: Only liquids with a vapor pressure less than or equal to 110 kPa at 50

°

C (1.1

bar at 122

°

F), or 130 kPa at 55

°

C (1.3 bar at 131

°

F) are authorized.

IB3 .............................

Authorized IBCs: Metal (31A, 31B and 31N); Rigid plastics (31H1 and 31H2); Composite (31HZ1 and

31HA2, 31HB2, 31HN2, 31HD2 and 31HH2).

Additional Requirement: Only liquids with a vapor pressure less than or equal to 110 kPa at 50

°

C (1.1

bar at 122

°

F), or 130 kPa at 55

°

C (1.3 bar at 131

°

F) are authorized, except for UN2672 (also see

special provision IP8 in Table 2 for UN2672).

IB4 .............................

Authorized IBCs: Metal (11A, 11B, 11N, 21A, 21B, 21N, 31A, 31B and 31N).

IB5 .............................

Authorized IBCs: Metal (11A, 11B, 11N, 21A, 21B, 21N, 31A, 31B and 31N); Rigid plastics (11H1,

11H2, 21H1, 21H2, 31H1 and 31H2); Composite (11HZ1, 21HZ1 and 31HZ1).

IB6 .............................

Authorized IBCs: Metal (11A, 11B, 11N, 21A, 21B, 21N, 31A, 31B and 31N); Rigid plastics (11H1,

11H2, 21H1, 21H2, 31H1 and 31H2); Composite (11HZ1, 11HZ2, 21HZ1, 21HZ2 and 31HZ1).

Additional Requirement: Composite IBCs 11HZ2 and 21HZ2 may not be used when the hazardous ma-

terials being transported may become liquid during transport.

IB7 .............................

Authorized IBCs: Metal (11A, 11B, 11N, 21A, 21B, 21N, 31A, 31B and 31N); Rigid plastics (11H1,

11H2, 21H1, 21H2, 31H1 and 31H2); Composite (11HZ1, 11HZ2, 21HZ1, 21HZ2 and 31HZ1); Wood-
en (11C, 11D and 11F).

Additional Requirement: Liners of wooden IBCs must be sift-proof.

IB8 .............................

Authorized IBCs: Metal (11A, 11B, 11N, 21A, 21B, 21N, 31A, 31B and 31N); Rigid plastics (11H1,

11H2, 21H1, 21H2, 31H1 and 31H2 ); Composite (11HZ1, 11HZ2, 21HZ1, 21HZ2 and 31HZ1); Fiber-
board (11G); Wooden (11C, 11D and 11F); Flexible (13H1, 13H2, 13H3, 13H4, 13H5, 13L1, 13L2,
13L3, 13L4, 13M1 or 13M2).

IB9 .............................

IBCs are only authorized if approved by the Associate Administrator.

T

ABLE

2—IP C

ODES



IP code

IP1 .............................

IBCs must be packed in closed freight containers or a closed transport vehicle.

IP2 .............................

When IBCs other than metal or rigid plastics IBCs are used, they must be offered for transportation in a

closed freight container or a closed transport vehicle.

IP3 .............................

Flexible IBCs must be sift-proof and water-resistant or must be fitted with a sift-proof and water-resist-

ant liner.

IP4 .............................

Flexible, fiberboard or wooden IBCs must be sift-proof and water-resistant or be fitted with a sift-proof

and water-resistant liner.

IP5 .............................

IBCs must have a device to allow venting. The inlet to the venting device must be located in the vapor

space of the IBC under maximum filling conditions.

IP6 .............................

Non-specification bulk bins are authorized.

IP7 .............................

For UN identification numbers 1327, 1363, 1364, 1365, 1386, 1408, 1841, 2211, 2217, 2793 and 3314,

IBCs are not required to meet the IBC performance tests specified in part 178, subpart N, of this sub-
chapter.

IP8 .............................

Ammonia solutions may be transported in rigid or composite plastic IBCs (31H1, 31H2 and 31HZ1) that

have successfully passed, without leakage or permanent deformation, the hydrostatic test specified in
§ 178.814 of this subchapter at a test pressure that is not less than 1.5 times the vapor pressure of
the contents at 55

°

C (131

°

F).

background image

378

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

T

ABLE

2—IP C

ODES

—Continued

IP code

IP13 ...........................

Transportation by vessel in IBCs is prohibited.

IP14 ...........................

Air must be eliminated from the vapor space by nitrogen or other means.

IP15 ...........................

For UN2031 with more than 55% nitric acid, rigid plastic IBCs and composite IBCs with a rigid plastic

inner receptacle are authorized for two years from the date of IBC manufacture.

IP16 ...........................

IBCs of type 31A and 31N are only authorized if approved by the Associate Administrator.

IP19 ...........................

For UN identification numbers 3531, 3532, 3533, and 3534, IBCs must be designed and constructed to

permit the release of gas or vapor to prevent a build-up of pressure that could rupture the IBCs in the
event of loss of stabilization.

IP20 ...........................

Dry sodium cyanide or potassium cyanide is also permitted in siftproof, water-resistant, fiberboard IBCs

when transported in closed freight containers or transport vehicles.

IP21 ...........................

When transported by vessel, flexible, fiberboard or wooden IBCs must be sift-proof and water-resistant

or be fitted with a sift-proof and water-resistant liner.

T

ABLE

3—IB C

ODES



[Large packaging authorizations]

IB3

Authorized Large Packagings (LIQUIDS)

(PG III materials only)

2



Inner packagings:

Large outer packagings:

Glass

10 liter ....

steel (50A).

Plastics

30 liter

aluminum (50B).

Metal

40 liter ....

metal other than steel or aluminum (50N).

rigid plastics (50H).
natural wood (50C).
plywood (50D).
reconstituted wood (50F).
rigid fiberboard (50G).

IB8

Authorized Large Packagings (SOLIDS)

(PG III materials only)

2



Inner packagings:

Large outer packagings:

Glass

10 kg ...........................................................

steel (50A).

Plastics

50 kg .......................................................

aluminum (50B).

Metal

50 kg ...........................................................

metal other than steel or aluminum (50N).

Paper

50 kg ..........................................................

flexible plastics (51H).

1



Fiber

50 kg ............................................................

rigid plastics (50H).
natural wood (50C).
plywood (50D).
reconstituted wood (50F).
rigid fiberboard (50G).

1

Flexible plastic (51H) Large Packagings are only authorized for use with flexible inner packagings.

2

Except when authorized under Special Provision 41.

(5)

‘‘N’’ codes.

These provisions apply

only to non-bulk packagings:

Code/Special Provisions

N3

Glass inner packagings are permitted in

combination or composite packagings only
if the hazardous material is free from
hydrofluoric acid.

N4

For combination or composite pack-

agings, glass inner packagings, other than
ampoules, are not permitted.

N5

Glass materials of construction are not

authorized for any part of a packaging
which is normally in contact with the haz-
ardous material.

N6

Battery fluid packaged with electric

storage batteries, wet or dry, must con-
form to the packaging provisions of
§ 173.159 (g) or (h) of this subchapter.

N7

The hazard class or division number of

the material must be marked on the pack-

age in accordance with § 172.302 of this sub-
chapter. However, the hazard label cor-
responding to the hazard class or division
may be substituted for the marking.

N8

Nitroglycerin solution in alcohol may be

transported under this entry only when the
solution is packed in metal cans of not
more than 1 L capacity each, overpacked
in a wooden box containing not more than
5 L. Metal cans must be completely sur-
rounded with absorbent cushioning mate-
rial. Wooden boxes must be completely
lined with a suitable material impervious
to water and nitroglycerin.

N11

This material is excepted for the speci-

fication packaging requirements of this
subchapter if the material is packaged in
strong, tight non-bulk packaging meeting
the requirements of subparts A and B of
part 173 of this subchapter.

N12

Plastic packagings are not authorized.

background image

379

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

N20

A 5M1 multi-wall paper bag is author-

ized if transported in a closed transport ve-
hicle.

N25

Steel single packagings are not author-

ized.

N32

Aluminum materials of construction

are not authorized for single packagings.

N33

Aluminum drums are not authorized.

N34

Aluminum construction materials are

not authorized for any part of a packaging
which is normally in contact with the haz-
ardous material.

N36

Aluminum or aluminum alloy construc-

tion materials are permitted only for halo-
genated hydrocarbons that will not react
with aluminum.

N37

This material may be shipped in an in-

tegrally-lined fiber drum (1G) which meets
the general packaging requirements of sub-
part B of part 173 of this subchapter, the
requirements of part 178 of this subchapter
at the packing group assigned for the ma-
terial and to any other special provisions
of column 7 of the § 172.101 table.

N40

This material is not authorized in the

following packagings:
a. A combination packaging consisting of a

4G fiberboard box with inner receptacles
of glass or earthenware;

b. A single packaging of a 4C2 sift-proof,

natural wood box; or

c. A composite packaging 6PG2 (glass, por-

celain or stoneware receptacles within a
fiberboard box).

N41

Metal construction materials are not

authorized for any part of a packaging
which is normally in contact with the haz-
ardous material.

N42

1A1 drums made of carbon steel with

thickness of body and heads of not less
than 1.3 mm (0.050 inch) and with a corro-
sion-resistant phenolic lining are author-
ized for stabilized benzyl chloride if tested
and certified to the Packing Group I per-
formance level at a specific gravity of not
less than 1.8.

N43

Metal drums are permitted as single

packagings only if constructed of nickel or
monel.

N45

Copper cartridges are authorized as

inner packagings if the hazardous material
is not in dispersion.

N65

Outage must be sufficient to prevent

cylinders or spheres from becoming liquid
full at 55

°

C (130

°

F). The vacant space (out-

age) may be charged with a nonflammable
nonliquefied compressed gas if the pressure
in the cylinder or sphere at 55

°

C (130

°

F)

does not exceed 125 percent of the marked
service pressure.

N73

Packagings consisting of outer wooden

or fiberboard boxes with inner glass, metal
or other strong containers; metal or fiber
drums; kegs or barrels; or strong metal
cans are authorized and need not conform
to the requirements of part 178 of this sub-
chapter.

N74

Packages consisting of tightly closed

inner containers of glass, earthenware,
metal or polyethylene, capacity not over
0.5 kg (1.1 pounds) securely cushioned and
packed in outer wooden barrels or wooden
or fiberboard boxes, not over 15 kg (33
pounds) net weight, are authorized and
need not conform to the requirements of
part 178 of this subchapter.

N75

Packages consisting of tightly closed

inner packagings of glass, earthenware or
metal, securely cushioned and packed in
outer wooden barrels or wooden or fiber-
board boxes, capacity not over 2.5 kg (5.5
pounds) net weight, are authorized and
need not conform to the requirements of
part 178 of this subchapter.

N76

For materials of not more than 25 per-

cent active ingredient by weight, packages
consisting of inner metal packagings not
greater than 250 mL (8 ounces) capacity
each, packed in strong outer packagings
together with sufficient absorbent mate-
rial to completely absorb the liquid con-
tents are authorized and need not conform
to the requirements of part 178 of this sub-
chapter.

N77

For materials of not more than two

percent active ingredients by weight, pack-
agings need not conform to the require-
ments of part 178 of this subchapter, if liq-
uid contents are absorbed in an inert mate-
rial.

N78

Packages consisting of inner glass,

earthenware, or polyethylene or other non-
fragile plastic bottles or jars not over 0.5
kg (1.1 pounds) capacity each, or metal
cans not over five pounds capacity each,
packed in outer wooden boxes, barrels or
kegs, or fiberboard boxes are authorized
and need not conform to the requirements
of part 178 of this subchapter. Net weight
of contents in fiberboard boxes may not ex-
ceed 29 kg (64 pounds). Net weight of con-
tents in wooden boxes, barrels or kegs may
not exceed 45 kg (99 pounds).

N79

Packages consisting of tightly closed

metal inner packagings not over 0.5 kg (1.1
pounds) capacity each, packed in outer
wooden or fiberboard boxes, or wooden bar-
rels, are authorized and need not conform
to the requirements of part 178 of this sub-
chapter. Net weight of contents may not
exceed 15 kg (33 pounds).

N80

Packages consisting of one inner metal

can, not over 2.5 kg (5.5 pounds) capacity,
packed in an outer wooden or fiberboard
box, or a wooden barrel, are authorized and
need not conform to the requirements of
part 178 of this subchapter.

N82

See § 173.115 of this subchapter for clas-

sification criteria for flammable aerosols.

N83

This material may not be transported

in quantities of more than 11.5 kg (25.4 lbs)
per package.

N84

The maximum quantity per package is

500 g (1.1 lbs.).

background image

380

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

N85

Packagings certified at the Packing

Group I performance level may not be
used.

N86

UN pressure receptacles made of alu-

minum alloy are not authorized.

N87

The use of copper valves on UN pressure

receptacles is prohibited.

N88

Any metal part of a UN pressure recep-

tacle in contact with the contents may not
contain more than 65% copper, with a tol-
erance of 1%.

N89

When steel UN pressure receptacles are

used, only those bearing the ‘‘H’’ mark are
authorized.

N90

Metal packagings are not authorized.

Packagings of other material with a small
amount of metal, for example metal clo-
sures or other metal fittings such as those
mentioned in part 178 of this subchapter,
are not considered metal packagings.
Packagings of other material constructed
with a small amount of metal must be de-
signed such that the hazardous material
does not contact the metal.

N91

The use of a non specification sift-

proof, non-bulk, metal can with or without
lid, or a non specification sift-proof, non-
bulk fiber drum, with or without lid is au-
thorized when transporting coal tar pitch
compounds by motor vehicle or rail
freight. The fiber drum must to be fab-
ricated with a three ply wall, as a min-
imum. The coal tar pitch compound must
be in a solid mass during transportation.

N92

Notwithstanding the provisions of

§ 173.24(g) of this subchapter, packagings
shall be designed and constructed to per-
mit the release of gas or vapor to prevent
a build-up of pressure that could rupture
the packagings in the event of loss of sta-
bilization.

N95

UN1075, Liquefied petroleum gas and

UN1978, Propane authorized for transport
in DOT 4BA240 cylinders is not subject to
the UN identification number and proper
shipping name marking or the label re-
quirements of this part subject to the fol-
lowing conditions:
a. The cylinder must be transported in a

closed motor vehicle displaying FLAM-
MABLE GAS placards in accordance with
subpart F of part 172 of this subchapter.

b. Shipping papers at all times must reflect

a correct current accounting of all cyl-
inders both full and expended.

c. The cylinders are collected and trans-

ported by a private or a contract carrier
for reconditioning, reuse or disposal.

(6)

‘‘R’’ codes.

These provisions apply

only to transportation by rail.

R1

A person who offers for transpor-

tation tank cars containing sulfur,
molten or residue of sulfur, molten
may reference the Sulfur Institute’s,
‘‘Molten Sulphur Rail Tank Car Guid-
ance document’’ (see § 171.7 of this sub-
chapter) to identify tank cars that may
pose a risk in transportation due to the
accumulation of formed, solid sulfur on
the outside of the tank.

(7)

‘‘T’’ codes.

(i) These provisions

apply to the transportation of haz-
ardous materials in UN portable tanks.
Portable tank instructions specify the
requirements applicable to a portable
tank when used for the transportation
of a specific hazardous material. These
requirements must be met in addition
to the design and construction speci-
fications in part 178 of this subchapter.
Portable tank instructions T1 through
T22 specify the applicable minimum
test pressure, the minimum shell
thickness (in reference steel), bottom
opening requirements and pressure re-
lief requirements. Liquefied com-
pressed gases are assigned to portable
tank instruction T50. Refrigerated liq-
uefied gases that are authorized to be
transported in portable tanks are spec-
ified in tank instruction T75.

(ii) The following table specifies the

portable tank requirements applicable
to ‘‘T’’ Codes T1 through T22. Column 1
specifies the ‘‘T’’ Code. Column 2 speci-
fies the minimum test pressure, in bar
(1 bar = 14.5 psig), at which the periodic
hydrostatic testing required by § 180.605
of this subchapter must be conducted.
Column 3 specifies the section ref-
erence for minimum shell thickness or,
alternatively, the minimum shell
thickness value. Column 4 specifies the
applicability of § 178.275(g)(3) of this
subchapter for the pressure relief de-
vices. When the word ‘‘Normal’’ is indi-
cated, § 178.275(g)(3) of this subchapter
does not apply. Column 5 references ap-
plicable requirements for bottom open-
ings in part 178 of this subchapter.
‘‘Prohibited’’ means bottom openings
are prohibited, and ‘‘Prohibited for liq-
uids’’ means bottom openings are au-
thorized for solid material only. The
table follows:

background image

381

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

T

ABLE OF

P

ORTABLE

T

ANK

T C

ODES

T1–T22

[Portable tank codes T1–T22 apply to liquid and solid hazardous materials of Classes 3 through 9 which are transported in

portable tanks.]

Portable tank

instruction

(1)

Minimum test

pressure

(bar)

(2)

Minimum shell thickness

(in mm-reference steel)

(See § 178.274(d))

(3)

Pressure-relief requirements

(See § 178.275(g))

(4)

Bottom opening

requirements

(See § 178.275(d))

(5)

T1 ..................

1 .5

§ 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(2)

T2 ..................

1 .5

§ 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(3)

T3 ..................

2 .65  § 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(2)

T4 ..................

2 .65  § 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(3)

T5 ..................

2 .65  § 178.274(d)(2)

§ 178.275(g)(3) .................................

Prohibited

T6 ..................

§ 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(2)

T7 ..................

§ 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(3)

T8 ..................

§ 178.274(d)(2)

Normal ..............................................

Prohibited

T9 ..................

6 mm

Normal ..............................................

Prohibited for liquids.

T10 ................

6 mm

§ 178.275(g)(3) .................................

Prohibited

T11 ................

§ 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(3)

T12 ................

§ 178.274(d)(2)

§ 178.275(g)(3) .................................

§ 178.275(d)(3)

T13 ................

6 mm

Normal ..............................................

Prohibited

T14 ................

6 mm

§ 178.275(g)(3) .................................

Prohibited

T15 ................

10

§ 178.274(d)(2)

Normal ..............................................

§ 178.275(d)(3)

T16 ................

10

§ 178.274(d)(2)

§ 178.275(g)(3) .................................

§ 178.275(d)(3)

T17 ................

10

6 mm

Normal ..............................................

§ 178.275(d)(3)

T18 ................

10

6 mm

§ 178.275(g)(3) .................................

§ 178.275(d)(3)

T19 ................

10

6 mm

§ 178.275(g)(3) .................................

Prohibited

T20 ................

10

8 mm

§ 178.275(g)(3) .................................

Prohibited

T21 ................

10

10 mm

Normal ..............................................

Prohibited for liquids.

§ 178.275(d)(2).

T22 ................

10

10 mm

§ 178.275(g)(3) .................................

Prohibited

(iii) T50

When portable tank in-

struction T50 is indicated in Column (7)
of the § 172.101 Hazardous Materials
Table, the applicable liquefied com-
pressed gas and chemical under pres-
sure descriptions are authorized to be
transported in portable tanks in ac-
cordance with the requirements of
§ 173.313 of this subchapter.

(iv)

T75.

When portable tank instruc-

tion T75 is referenced in Column (7) of
the § 172.101 Table, the applicable re-
frigerated liquefied gases are author-
ized to be transported in portable
tanks in accordance with the require-
ments of § 178.277 of this subchapter.

(v)

UN and IM portable tank codes/spe-

cial provisions.

When a specific portable

tank instruction is specified by a ‘‘T’’
Code in Column (7) of the § 172.101 Table
for a specific hazardous material, a
specification portable tank conforming
to an alternative tank instruction may
be used if:

(A) The alternative portable tank has

a higher or equivalent test pressure
(for example, 4 bar when 2.65 bar is
specified);

(B) The alternative portable tank has

greater or equivalent wall thickness
(for example, 10 mm when 6 mm is
specified);

(C) The alternative portable tank has

a pressure relief device as specified in
the ‘‘T’’ Code. If a frangible disc is re-
quired in series with the reclosing pres-
sure relief device for the specified port-
able tank, the alternative portable
tank must be fitted with a frangible
disc in series with the reclosing pres-
sure relief device; and

(D) With regard to bottom openings—
(

1

) When two effective means are

specified, the alternative portable tank
is fitted with bottom openings having
two or three effective means of closure
or no bottom openings; or

(

2

) When three effective means are

specified, the portable tank has no bot-
tom openings or three effective means
of closure; or

(

3

) When no bottom openings are au-

thorized, the alternative portable tank
must not have bottom openings.

(vi) Except when an organic peroxide

is authorized under § 173.225(g), if a haz-
ardous material is not assigned a port-
able tank ‘‘T’’ Code, the hazardous ma-
terial may not be transported in a
portable tank unless approved by the
Associate Administrator.

background image

382

49 CFR Ch. I (10–1–23 Edition)

§ 172.102

(8)

‘‘TP’’ codes.

(i) These provisions

apply to the transportation of haz-
ardous materials in IM and UN Speci-
fication portable tanks. Portable tank
special provisions are assigned to cer-
tain hazardous materials to specify re-
quirements that are in addition to
those provided by the portable tank in-
structions or the requirements in part
178 of this subchapter. Portable tank
special provisions are designated with
the abbreviation TP (tank provision)
and are assigned to specific hazardous
materials in Column (7) of the § 172.101
Table.

(ii) The following is a list of the port-

able tank special provisions:

Code/Special Provisions

TP1

The maximum degree of filling must

not exceed the degree of filling determined
by the following:

Degree of filling

=

+

(

)







97

1

α

t

t

r

f

.

Where:
t

r

is the maximum mean bulk temperature

during transport, and t

f

is the tempera-

ture in degrees celsius of the liquid dur-
ing filling.

TP2

a. The maximum degree of filling

must not exceed the degree of filling deter-
mined by the following:

Degree of filling

=

+

(

)







95

1

α

t

t

r

f

.

Where:
t

r

is the maximum mean bulk temperature

during transport,

t

f

is the temperature in degrees celsius of the

liquid during filling, and

is the mean coefficient of cubical expan-

sion of the liquid between the mean tem-
perature of the liquid during filling (t

f

and the maximum mean bulk tempera-
ture during transportation (t

r

) both in

degrees celsius.

b. For liquids transported under ambient

conditions

may be calculated using the for-

mula:

α =

d

d

d

15

50

50

35

Where:
d

15

and d

50

are the densities (in units of mass

per unit volume) of the liquid at 15

°

C (59

°

F) and 50

°

C (122

°

F), respectively.

TP3

The maximum degree of filling (in %)

for solids transported above their melting
points and for elevated temperature liquids
shall be determined by the following:

Degree of filling = 95

d

d

r

f







.

Where: d

f

and d

r

are the mean densities of the

liquid at the mean temperature of the liquid
during filling and the maximum mean bulk
temperature during transport respectively.

TP4

The maximum degree of filling for

portable tanks must not exceed 90%.

TP5

For a portable tank used for the

transport of flammable refrigerated liquefied
gases or refrigerated liquefied oxygen, the
maximum rate at which the portable tank
may be filled must not exceed the liquid flow
capacity of the primary pressure relief sys-
tem rated at a pressure not exceeding 120
percent of the portable tank’s design pres-
sure. For portable tanks used for the trans-
port of refrigerated liquefied helium and re-
frigerated liquefied atmospheric gas (except
oxygen), the maximum rate at which the
tank is filled must not exceed the liquid flow
capacity of the pressure relief device rated
at 130 percent of the portable tank’s design
pressure. Except for a portable tank con-
taining refrigerated liquefied helium, a port-
able tank shall have an outage of at least
two percent below the inlet of the pressure
relief device or pressure control valve, under
conditions of incipient opening, with the
portable tank in a level attitude. No outage
is required for helium.

TP6

The tank must be equipped with a

pressure release device which prevent a tank
from bursting under fire engulfment condi-
tions (the conditions prescribed in CGA pam-
phlet S–1.2 (see § 171.7 of this subchapter) or
alternative conditions approved by the Asso-
ciate Administrator may be used to consider
the fire engulfment condition), taking into
account the properties of the hazardous ma-
terial to be transported.

TP7

The vapor space must be purged of

air by nitrogen or other means.

TP8

A portable tank having a minimum

test pressure of 1.5 bar (150 kPa) may be used
when the flash point of the hazardous mate-
rial transported is greater than 0

°

C (32

°

F).

TP9

A hazardous material assigned to

special provision TP9 in Column (7) of the
§ 172.101 Table may only be transported in a
portable tank if approved by the Associate
Administrator.

TP10

A lead lining, not less than 5 mm

thick, which shall be tested annually, or an-
other suitable lining material approved by
the competent authority, is required. A port-
able tank may be offered for transport after
the date of expiry of the last lining inspec-
tion for a period not to exceed three months
for purposes of performing the next required

background image

383

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.102

test or inspection, after emptying but before
cleaning.

TP12

This material is considered highly

corrosive to steel.

TP13

Self-contained breathing apparatus

must be provided when this hazardous mate-
rial is transported by sea.

TP16

The portable tank must be pro-

tected against over and under pressurization
which may be experienced during transpor-
tation. The means of protection must be ap-
proved by the approval agency designated to
approve the portable tank in accordance
with the procedures in part 107, subpart E, of
this subchapter. The pressure relief device
must be preceded by a frangible disk in ac-
cordance with the requirements in
§ 178.275(g)(3) of this subchapter to prevent
crystallization of the product in the pressure
relief device.

TP17

Only inorganic non-combustible ma-

terials may be used for thermal insulation of
the tank.

TP18

The temperature of this material

must be maintained between 18

°

C (64.4

°

F)

and 40

°

C (104

°

F) while in transportation.

Portable tanks containing solidified meth-
acrylic acid must not be reheated during
transportation.

TP19

The calculated wall thickness must

be increased by 3 mm at the time of con-
struction. Wall thickness must be verified
ultrasonically at intervals midway between
periodic hydraulic tests (every 2.5 years).
The portable tank must not be used if the
wall thickness is less than that prescribed by
the applicable T code in Column (7) of the
Table for this material.

TP20

This hazardous material must only

be transported in insulated tanks under a ni-
trogen blanket.

TP21

The wall thickness must not be less

than 8 mm. Portable tanks must be hydrau-
lically tested and internally inspected at in-
tervals not exceeding 2.5 years.

TP22

Lubricants for portable tank fit-

tings (for example, gaskets, shut-off valves,
flanges) must be oxygen compatible.

TP24

The portable tank may be fitted

with a device to prevent the build up of ex-
cess pressure due to the slow decomposition
of the hazardous material being transported.
The device must be in the vapor space when
the tank is filled under maximum filling
conditions. This device must also prevent an
unacceptable amount of leakage of liquid in
the case of overturning.

TP25

Sulphur trioxide 99.95% pure and

above may be transported in tanks without
an inhibitor provided that it is maintained
at a temperature equal to or above 32.5

°

(90.5

°

F).

TP26

The heating device must be exterior

to the shell. For UN 3176, this requirement
only applies when the hazardous material re-
acts dangerously with water.

TP27

A portable tank having a minimum

test pressure of 4 bar (400 kPa) may be used
provided the calculated test pressure is 4 bar
or less based on the MAWP of the hazardous
material, as defined in § 178.275 of this sub-
chapter, where the test pressure is 1.5 times
the MAWP.

TP28

A portable tank having a minimum

test pressure of 2.65 bar (265 kPa) may be
used provided the calculated test pressure is
2.65 bar or less based on the MAWP of the
hazardous material, as defined in § 178.275 of
this subchapter, where the test pressure is
1.5 times the MAWP.

TP29

A portable tank having a minimum

test pressure of 1.5 bar (150.0 kPa) may be
used provided the calculated test pressure is
1.5 bar or less based on the MAWP of the haz-
ardous materials, as defined in § 178.275 of
this subchapter, where the test pressure is
1.5 times the MAWP.

TP30

This hazardous material may only

be transported in insulated tanks.

TP31

This hazardous material may only

be transported in tanks in the solid state.

TP32

Portable tanks may be used subject

to the following conditions:

a. Each portable tank constructed of metal

must be fitted with a pressure-relief device
consisting of a reclosing spring loaded type,
a frangible disc or a fusible element. The set
to discharge for the spring loaded pressure
relief device and the burst pressure for the
frangible disc, as applicable, must not be
greater than 2.65 bar for portable tanks with
minimum test pressures greater than 4 bar;

b. The suitability for transport in tanks

must be demonstrated using test 8(d) in Test
Series 8 (see UN Manual of Tests and Cri-
teria, Part 1, Sub-section 18.7) (IBR, see
§ 171.7 of this subchapter) or an alternative
means approved by the Associate Adminis-
trator.

TP33

The portable tank instruction as-

signed for this substance applies for granular
and powdered solids and for solids which are
filled and discharged at temperatures above
their melting point which are cooled and
transported as a solid mass. Solid substances
transported or offered for transport above
their melting point are authorized for trans-
portation in portable tanks conforming to
the provisions of portable tank instruction
T4 for solid substances of packing group III
or T7 for solid substances of packing group
II, unless a tank with more stringent re-
quirements for minimum shell thickness,
maximum allowable working pressure, pres-
sure-relief devices or bottom outlets are as-
signed in which case the more stringent tank
instruction and special provisions shall
apply. Filling limits must be in accordance
with portable tank special provision TP3.
Solids meeting the definition of an elevated
temperature material must be transported in
accordance with the applicable requirements
of this subchapter.

background image

384

49 CFR Ch. I (10–1–23 Edition)

§ 172.102, Nt.

TP36

For material assigned this portable

tank special provision, portable tanks used
to transport such material may be equipped
with fusible elements in the vapor space of
the portable tank.

TP37

IM portable tanks are only author-

ized for the shipment of hydrogen peroxide
solutions in water containing 72% or less hy-
drogen peroxide by weight. Pressure relief
devices shall be designed to prevent the
entry of foreign matter, the leakage of liquid
and the development of any dangerous excess
pressure. In addition, the portable tank must
be designed so that internal surfaces may be
effectively cleaned and passivated. Each
tank must be equipped with pressure relief
devices conforming to the following require-
ments:

Concentration of hydrogen per peroxide solution

Total

1



52% or less ..............................................................

11

Over 52%, but not greater than 60% ......................

22

Over 60%, but not greater than 72% ......................

32

1

Total venting capacity in standard cubic feet hour

(S.C.F.H.) per pound of hydrogen peroxide solution.

TP38

Each portable tank must be insu-

lated with an insulating material so that the
overall thermal conductance at 15.5

°

C (60

°

F)

is no more than 1.5333 kilojoules per hour per
square meter per degree Celsius (0.075 Btu
per hour per square foot per degree Fahr-
enheit) temperature differential. Insulating
materials may not promote corrosion to
steel when wet.

TP39

[Reserved]

TP40

The portable tank must not be

transported when connected with spray ap-
plication equipment.

TP41

[Reserved]

TP44

Each portable tank must be made of

stainless steel, except that steel other than
stainless steel may be used in accordance
with the provisions of § 173.24b(b) of this sub-
chapter. Thickness of stainless steel for tank
shell and heads must be the greater of 7.62
mm (0.300 inch) or the thickness required for
a portable tank with a design pressure at
least equal to 1.5 times the vapor pressure of
the hazardous material at 46

°

C (115

°

F).

TP45

Each portable tank must be made of

stainless steel, except that steel other than
stainless steel may be used in accordance
with the provisions of 173.24b(b) of this sub-
chapter. Thickness of stainless steel for port-
able tank shells and heads must be the great-
er of 6.35 mm (0.250 inch) or the thickness re-
quired for a portable tank with a design pres-
sure at least equal to 1.3 times the vapor
pressure of the hazardous material at 46

°

(115

°

F).

TP46

Portable tanks in sodium metal

service are not required to be
hydrostatically retested.

TP47

The 2.5 year internal examination

may be waived or substituted by other test
methods or inspection procedures specified

by the competent authority or its authorized
body, provided that the portable tank is
dedicated to the transport of the
organometallic substances to which this
tank special provision is assigned. However
this examination is required when the condi-
tions of § 180.605(f) are met.

(9)

‘‘W’’ codes.

These provisions apply

only to transportation by water:

Code/Special Provisions

W1 This substance in a non friable prill or

granule form is not subject to the require-
ments of this subchapter when tested in
accordance with the UN Manual of Test
and Criteria (IBR,

see

§ 171.7 of this sub-

chapter) and is found to not meet the defi-
nition or criteria for inclusion in Division
5.1.

W7

Vessel stowage category for uranyl ni-

trate hexahydrate solution is ‘‘D’’ as de-
fined in § 172.101(k)(4).

W8

Vessel stowage category for pyrophoric

thorium metal or pyrophoric uranium
metal is ‘‘D’’ as defined in § 172.101(k)(4).

W9

When offered for transportation by

water, the following Specification pack-
agings are not authorized unless approved
by the Associate Administrator: woven
plastic bags, plastic film bags, textile bags,
paper bags, IBCs and bulk packagings.

W10

When offered for transportation by ves-

sel, the use of Large Packagings (see § 171.8
of this subchapter) is prohibited.

W31

Non-bulk packagings must be hermeti-

cally sealed.

W40

Non-bulk bags are not allowed.

W41

When offered for transportation by

water, this material must be packaged in
bales and be securely and tightly bound
with rope, wire or similar means.

W100

Non-bulk flexible, fibreboard or wood-

en packagings must be sift-proof and
water-resistant or must be fitted with a
sift-proof and water-resistant liner.

[Amdt. 172–123, 55 FR 52582, Dec. 21, 1990]

E

DITORIAL

N

OTE

: For F

EDERAL

R

EGISTER

ci-

tations affecting § 172.102, see the List of CFR
Sections Affected, which appears in the
Finding Aids section of the printed volume
and at

www.govinfo.gov.

E

FFECTIVE

D

ATE

N

OTE

: At 88 FR 60375,

Sept. 1, 2023, in § 172.102, paragraph (c)(1) was
amended by adding special provision 439, ef-
fective Oct. 31, 2023. For the convenience of
the user, the added text is set forth as fol-
lows:

§ 172.102

Special provisions.

* * * * *

(c) * * *
(1) * * *

background image

385

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.201

439 UN1972 is not authorized for transpor-

tation by rail tank car until either issuance
of a final rule concluding the rulemaking ac-
tion proceeding under RIN 2137–AF54, or
June 30, 2025, whichever occurs first. For in-
formation and the status of RIN 2137–AF54,
please refer to the Office of Management and
Budget’s Office of Information and Regu-
latory Affairs at

www.reginfo.gov.

* * * * *

Subpart C—Shipping Papers

§ 172.200

Applicability.

(a)

Description of hazardous materials

required.

Except as otherwise provided

in this subpart, each person who offers
a hazardous material for transpor-
tation shall describe the hazardous ma-
terial on the shipping paper in the
manner required by this subpart.

(b) This subpart does not apply to

any material, other than a hazardous
substance, hazardous waste or marine
pollutant, that is—

(1) Identified by the letter ‘‘A’’ in col-

umn 1 of the § 172.101 table, except
when the material is offered or in-
tended for transportation by air; or

(2) Identified by the letter ‘‘W’’ in

column 1 of the § 172.101 table, except
when the material is offered or in-
tended for transportation by water; or

(3) A limited quantity package unless

the material is offered for transpor-
tation by aircraft or vessel.

(4) Category B infectious substances

prepared in accordance with § 173.199.

[Amdt. 172–29A, 41 FR 40677, Sept. 20, 1976, as
amended by Amdt. 172–58, 45 FR 34697, May
22, 1980; Amdt. 172–74, 47 FR 43065, Sept. 30,
1982; Amdt. 172–112, 53 FR 17160, May 13, 1988;
Amdt. 172–127, 57 FR 52938, Nov. 5, 1992; 71 FR
32258, June 2, 2006; 76 FR 3365, Jan. 19, 2011; 78
FR 1112, Jan. 7, 2013; 87 FR 79772, Dec. 27,
2022]

§ 172.201

Preparation and retention of

shipping papers.

(a)

Contents.

When a description of

hazardous material is required to be in-
cluded on a shipping paper, that de-
scription must conform to the fol-
lowing requirements:

(1) When a hazardous material and a

material not subject to the require-
ments of this subchapter are described
on the same shipping paper, the haz-
ardous material description entries re-

quired by § 172.202 and those additional
entries that may be required by
§ 172.203:

(i) Must be entered first, or
(ii) Must be entered in a color that

clearly contrasts with any description
on the shipping paper of a material not
subject to the requirements of this sub-
chapter, except that a description on a
reproduction of a shipping paper may
be highlighted, rather than printed, in
a contrasting color (the provisions of
this paragraph apply only to the basic
description required by § 172.202(a)(1),
(2), (3), and (4)), or

(iii) Must be identified by the entry

of an ‘‘X’’ placed before the basic ship-
ping description required by § 172.202 in
a column captioned ‘‘HM.’’ (The ‘‘X’’
may be replaced by ‘‘RQ,’’ if appro-
priate.)

(2) The required shipping description

on a shipping paper and all copies of
the shipping paper used for transpor-
tation purposes must be legible and
printed (manually or mechanically) in
English.

(3) Unless it is specifically authorized

or required in this subchapter, the re-
quired shipping description may not
contain any code or abbreviation.

(4) A shipping paper may contain ad-

ditional information concerning the
material provided the information is
not inconsistent with the required de-
scription. Unless otherwise permitted
or required by this subpart, additional
information must be placed after the
basic description required by
§ 172.202(a).

(5)

Electronic shipping papers.

For

transportation by rail, a rail carrier
may accept shipping paper information
either telephonically (i.e., voice com-
munications and facsimiles) or elec-
tronically (EDI) from an offeror of a
hazardous materials shipment in ac-
cordance with the provisions in para-
graphs (a)(5)(i)–(a)(5)(iv) of this section.
See § 171.8 for the EDI definition.

(i) When the information applicable

to the consignment is provided under
this requirement the information must
be available to the offeror and carrier
at all times during transport, and the
carrier must have and maintain a
printed copy of this information until
delivery of the hazardous materials on
the shipping paper is complete. When a
