416
49 CFR Ch. I (10–1–23 Edition)
§ 172.336
displayed on an orange panel unless it
is displayed in proximity to the
placard.
(g) No person shall add any color,
number, letter, symbol, or word other
than as specified in this subchapter, to
any identification number marking
display which is required or authorized
by this subchapter.
[Amdt. 172–101, 45 FR 74667, Nov. 10, 1980, as
amended by Amdt. 172–104, 51 FR 23078, June
25, 1986; Amdt. 172–110, 52 FR 29528, Aug. 10,
1987; Amdt. 172–123, 55 FR 52593, Dec. 21, 1990;
56 FR 66255, Dec. 20, 1991; Amdt. 172–127, 59
FR 49133, Sept. 26, 1994]
§ 172.336
Identification numbers; spe-
cial provisions.
(a) When not required or prohibited
by this subpart, identification numbers
may be displayed on a transport vehi-
cle or a freight container in the man-
ner prescribed by this subpart.
(b) Identification numbers, when re-
quired, must be displayed on either or-
ange panels (see § 172.332(b)) or on a
plain white square-on-point display
configuration having the same outside
dimensions as a placard. In addition,
for materials in hazard classes for
which placards are specified and identi-
fication number displays are required,
but for which identification numbers
may not be displayed on the placards
authorized for the material (see
§ 172.334(a)), identification numbers
must be displayed on orange panels or
on the plain white square-on-point dis-
play configuration in association with
the required placards. An identifica-
tion number displayed on a white
square-on-point display configuration
is not considered to be a placard.
(1) The 100 mm (3.9 inch) by 215 mm
(8.5 inches) area containing the identi-
fication number shall be located as pre-
scribed by § 172.332 (c)(1) and (c)(2) and
may be outlined with a solid or dotted
line border.
(2) [Reserved]
(c) Identification Numbers are not re-
quired:
Packaging:
When:
Then the alter-
native marking re-
quirement is:
On the ends of
portable tanks,
cargo tanks, or
tank cars.
They have more
than one com-
partment and
hazardous mate-
rials with dif-
ferent identifica-
tion numbers
are being trans-
ported therein.
The identification
numbers on the
sides of the tank
are displayed in
the same se-
quence as the
compartments
containing the
materials they
identify.
On cargo tanks .....
They contain only
gasoline.
The tank is
marked ‘‘Gaso-
line’’ on each
side and rear in
letters no less
than 50 mm (2
inches) high, or
is placarded in
accordance with
§ 172.542(c).
On cargo tanks .....
They contain only
fuel oil.
The cargo tank is
marked ‘‘Fuel
Oil’’ on each
side and rear in
letters no less
than 50 mm (2
inches) high, or
is placarded in
accordance with
§ 172.544(c).
On one end of
nurse tanks if
that end con-
tains valves, fit-
tings, regulators
or gauges when
those appur-
tenances pre-
vent the mark-
ings and placard
from being prop-
erly placed and
visible.
They meet the
provisions of
§ 173.315(m) of
this subchapter.
N/A.
On cargo tanks, in-
cluding compart-
mented cargo
tanks, or tank
cars.
They contain more
than one petro-
leum distillate
fuel.
The identification
number for the
liquid petroleum
distillate fuel
having the low-
est flash point is
displayed. If the
cargo tank also
contains gaso-
line and alcohol
fuel blends con-
sisting of more
than 10% eth-
anol the identi-
fication number
‘‘3475’’ or
‘‘1987,’’ as ap-
propriate, must
also be dis-
played.
(d) When a bulk packaging is labeled
instead of placarded in accordance with
§ 172.514(c) of this subchapter, identi-
fication number markings may be dis-
played on the package in accordance
417
Pipeline and Haz. Matls. Safety Admin., DOT
§ 172.400
with the marking requirements of
§ 172.301(a)(1) of this subchapter.
[Amdt. 172–101, 45 FR 74667, Nov. 10, 1980, as
amended by Amdt. 172–74, 47 FR 40365, Sept.
30, 1982; Amdt. 172–109, 52 FR 13038, Apr. 20,
1987; Amdt. 172–110, 52 FR 29528, Aug. 10, 1987;
Amdt. 172–123, 55 FR 52593, Dec. 21, 1990; 56
FR 66255, Dec. 20, 1991; 65 FR 50459, Aug. 18,
2000; 73 FR 4716, Jan. 28, 2008; 76 FR 43527,
July 20, 2011; 78 FR 14714, Mar. 7, 2013; 78 FR
65478, Oct. 31, 2013]
§ 172.338
Replacement of identification
numbers.
If more than one of the identification
number markings on placards, orange
panels, or white square-on-point dis-
play configurations that are required
to be displayed are lost, damaged or de-
stroyed during transportation, the car-
rier shall replace all the missing or
damaged identification numbers as
soon as practicable. However, in such a
case, the numbers may be entered by
hand on the appropriate placard, or-
ange panel or white square-on-point
display configuration providing the
correct identification numbers are en-
tered legibly using an indelible mark-
ing material. When entered by hand,
the identification numbers must be lo-
cated in the white display area speci-
fied in § 172.332. This section does not
preclude required compliance with the
placarding requirements of subpart F
of this subchapter.
[Amdt. 172–110, 52 FR 29528, Aug. 10, 1987]
Subpart E—Labeling
§ 172.400
General labeling require-
ments.
(a) Except as specified in § 172.400a,
each person who offers for transpor-
tation or transports a hazardous mate-
rial in any of the following packages or
containment devices, shall label the
package or containment device with la-
bels specified for the material in the
§ 172.101 table and in this subpart:
(1) A non-bulk package;
(2) A bulk packaging, other than a
cargo tank, portable tank, or tank car,
with a volumetric capacity of less than
18 m
3
(640 cubic feet), unless placarded
in accordance with subpart F of this
part;
(3) A portable tank of less than 3785 L
(1000 gallons) capacity, unless plac-
arded in accordance with subpart F of
this part;
(4) A DOT Specification 106 or 110
multi-unit tank car tank, unless plac-
arded in accordance with subpart F of
this part; and
(5) An overpack, freight container or
unit load device, of less than 18 m
3
(640
cubic feet), which contains a package
for which labels are required, unless
placarded or marked in accordance
with § 172.512 of this part.
(b) Labeling is required for a haz-
ardous material which meets one or
more hazard class definitions, in ac-
cordance with column 6 of the § 172.101
table and the following table:
T
ABLE
1
TO
P
ARAGRAPH
(b)
Hazard class or division
Label name
Label de-
sign
or section
reference
1.1 ....................................................................................
EXPLOSIVES 1.1 ............................................................
172.411
1.2 ....................................................................................
EXPLOSIVES 1.2 ............................................................
172.411
1.3 ....................................................................................
EXPLOSIVES 1.3 ............................................................
172.411
1.4 ....................................................................................
EXPLOSIVES 1.4 ............................................................
172.411
1.5 ....................................................................................
EXPLOSIVES 1.5 ............................................................
172.411
1.6 ....................................................................................
EXPLOSIVES 1.6 ............................................................
172.411
2.1 ....................................................................................
FLAMMABLE GAS ..........................................................
172.417
2.2 ....................................................................................
NON–FLAMMABLE GAS ................................................
172.415
2.3 ....................................................................................
POISON GAS ..................................................................
172.416
3 Flammable Liquid (Combustible liquid) ........................
FLAMMABLE LIQUID (none) ..........................................
172.419
4.1 ....................................................................................
FLAMMABLE SOLID .......................................................
172.420
4.2 ....................................................................................
SPONTANEOUSLY COMBUSTIBLE ..............................
172.422
4.3 ....................................................................................
DANGEROUS WHEN WET ............................................
172.423
5.1 ....................................................................................
OXIDIZER ........................................................................
172.426
5.2 ....................................................................................
ORGANIC PEROXIDE ....................................................
172.427
6.1 (material poisonous by inhalation (see § 171.8 of
this subchapter)).
POISON INHALATION HAZARD ....................................
172.429
6.1 (other than a material poisonous by inhalation) .......
POISON ...........................................................................
172.430
6.1 (inhalation hazard, Zone A or B) ..............................
POISON INHALATION HAZARD ....................................
172.429
