409

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.403

S

UBSIDIARY

H

AZARD

L

ABELS

—Continued

Subsidiary hazard

level (packing

group)

Subsidiary Hazard (Class or Division)

3  4.1 4.2 4.3 5.1 6.1  8

II ..........................

X X X X X X X

III .........................

*  X X X X X X

X—Required for all modes.
*—Required for all modes, except for a material with a flash

point at or above 38

°

C (100

°

F) transported by rail or high-

way.

**—Reserved
***—Impossible as subsidiary hazard.

(b)

Display of hazard class on labels.

The appropriate hazard class or divi-
sion number must be displayed in the
lower corner of a primary hazard label
and a subsidiary hazard label.

(c)

Cargo Aircraft Only label. Each per-

son who offers for transportation or
transports by aircraft a package con-
taining a hazardous material which is
authorized on cargo aircraft only shall
label the package with a CARGO AIR-
CRAFT ONLY label specified in
§ 172.448 of this subpart.

(d)

Class 7 (Radioactive) Materials. Ex-

cept as otherwise provided in this para-
graph, each package containing a Class
7 material that also meets the defini-
tion of one or more additional hazard
classes must be labeled as a Class 7 ma-
terial as required by § 172.403 and for
each additional hazard.

(1) A subsidiary label is not required

for a package containing material that
satisfies all of the criteria in § 173.4,
§ 173.4a, or § 173.4b applicable to the sub-
sidiary hazard class.

(2) Each package or overpack con-

taining fissile material, other than
fissile-excepted material (see § 173.453
of this subchapter) must bear two
FISSILE labels, affixed to opposite
sides of the package or overpack, which
conforms to the figure shown in
§ 172.441; such labels, where applicable,
must be affixed adjacent to the labels
for radioactive materials.

(e)

Class 1 (explosive) Materials. In ad-

dition to the label specified in column
6 of the § 172.101 table, each package of
Class 1 material that also meets the
definition for:

(1) Division 6.1, Packing Groups I or

II, shall be labeled POISON or POISON
INHALATION HAZARD, as appro-
priate.

(2) Class 7, shall be labeled in accord-

ance with § 172.403 of this subpart.

(f)

Division 2.2 materials. In addition

to the label specified in column 6 of the
§ 172.101 table, each package of Division
2.2 material that also meets the defini-
tion for an oxidizing gas (see § 171.8 of
this subchapter) must be labeled OXI-
DIZER.

(g)

Division 2.3 materials. In addition

to the label specified in column 6 of the
§ 172.101 table, each package of Division
2.3 material that also meets the defini-
tion for:

(1) Division 2.1, must be labeled

Flammable Gas;

(2) Division 5.1, must be labeled Oxi-

dizer; and

(3) Class 8, must be labeled Corrosive.

[Amdt. 172–123, 55 FR 52594, Dec. 21, 1990, as
amended at 56 FR 66255, Dec. 20, 1991; Amdt.
172–139, 59 FR 67490, Dec. 29, 1994; Amdt. 172–
140, 60 FR 26805, May 18, 1995; Amdt. 172–149,
61 FR 27173, May 30, 1996; 62 FR 39405, July 22,
1997; 66 FR 33425, June 21, 2001; 69 FR 3668,
Jan. 26, 2004; 74 FR 2252, Jan. 14, 2009; 76 FR
56314, Sept. 13, 2011; 79 FR 40609, July 11, 2014]

§ 172.403

Class 7 (radioactive) mate-

rial.

(a) Unless excepted from labeling by

§§ 173.421 through 173.427 of this sub-
chapter, each package of radioactive
material must be labeled as provided in
this section.

(b) The proper label to affix to a

package of Class 7 (radioactive) mate-
rial is based on the radiation level at
the surface of the package and the
transport index. The proper category of
label must be determined in accord-
ance with paragraph (c) of this section.
The label to be applied must be the
highest category required for any of
the two determining conditions for the
package. RADIOACTIVE WHITE-I is
the lowest category and RADIO-
ACTIVE YELLOW-III is the highest.
For example, a package with a trans-
port index of 0.8 and a maximum sur-
face radiation level of 0.6 millisievert
(60 millirems) per hour must bear a
RADIOACTIVE YELLOW-III label.

(c) Category of label to be applied to

Class 7 (radioactive) materials pack-
ages:

VerDate Sep<11>2014

11:45 Oct 30, 2019

Jkt 247227

PO 00000

Frm 00419

Fmt 8010

Sfmt 8010

Q:\49\49V2.TXT

PC31

kpayne on VMOFRWIN702 with $$_JOB

background image

410

49 CFR Ch. I (10–1–19 Edition)

§ 172.403

Transport index

Maximum radiation level at any point

on the external surface

Label category

1



0

2

....................................................................

Less than or equal to 0.005 mSv/h (0.5

mrem/h).

WHITE-I.

More than 0 but not more than 1 ..................

Greater than 0.005 mSv/h (0.5 mrem/h)

but less than or equal to 0.5 mSv/h
(50 mrem/h).

YELLOW-II.

More than 1 but not more than 10 ................

Greater  than  0.5  mSv/h  (50  mrem/h)

but less than or equal to 2 mSv/h
(200 mrem/h).

YELLOW-III.

More than 10 ..................................................

Greater than 2 mSv/h (200 mrem/h)

but less than or equal to 10 mSv/h
(1,000 mrem/h).

YELLOW-III (Must be shipped under

exclusive use provisions; see
173.441(b) of this subchapter).

1

Any package containing a ‘‘highway route controlled quantity’’ (§ 173.403 of this subchapter) must be labelled as RADIO-

ACTIVE YELLOW-III.

2

If the measured TI is not greater than 0.05, the value may be considered to be zero.

(d)

EMPTY label. See § 173.428(e) of

this subchapter for EMPTY labeling re-
quirements.

(e)

FISSILE label. For packages re-

quired in § 172.402 to bear a FISSILE
label, each such label must be com-
pleted with the criticality safety index
(CSI) assigned in the NRC or DOE
package design approval, or in the cer-
tificate of approval for special arrange-
ment or the certificate of approval for
the package design issued by the Com-
petent Authority for import and export
shipments. For overpacks and freight
containers required in § 172.402 to bear
a FISSILE label, the CSI on the label
must be the sum of the CSIs for all of
the packages contained in the over-
pack or freight container.

(f) Each package required by this sec-

tion to be labeled with a RADIO-
ACTIVE label must have two of these
labels, affixed to opposite sides of the
package. (See § 172.406(e)(3) for freight
container label requirements).

(g) The following applicable items of

information must be entered in the
blank spaces on the RADIOACTIVE
label by legible printing (manual or
mechanical), using a durable weather
resistant means of marking:

(1)

Contents.  Except for LSA-1 mate-

rial, the names of the radionuclides as
taken from the listing of radionuclides
in § 173.435 of this subchapter (symbols
which conform to established radiation
protection terminology are authorized,
i.e.

99

Mo,

60

Co, etc.). For mixtures of

radionuclides, with consideration of
space available on the label, the radio-
nuclides that must be shown must be
determined in accordance with
§ 173.433(g) of this subchapter. For LSA-
I material, the term ‘‘LSA-I’’ may be

used in place of the names of the radio-
nuclides.

(2)

Activity. The maximum activity of

the radioactive contents in the pack-
age during transport must be expressed
in appropriate SI units (

e.g., Becquerels

(Bq), Terabecquerels (TBq)). The activ-
ity may also be stated in appropriate
customary units (

e.g.,  Curies (Ci),

milliCuries (mCi), microCuries (uCi))
in parentheses following the SI units.
Abbreviations are authorized. Except
for plutonium-239 and plutonium-241,
the weight in grams or kilograms of
fissile radionuclides (or the mass of
each fissile nuclide for mixtures when
appropriate) may be inserted instead of
activity units. For plutonium-239 and
plutonium-241, the weight in grams of
fissile radionuclides (or the mass of
each fissile nuclide for mixtures when
appropriate) may be inserted in addi-
tion to the activity units.

(3)

Transport index. (see § 173.403 of

this subchapter.)

(h) When one or more packages of

Class 7 (radioactive) material are
placed within an overpack, the over-
pack must be labeled as prescribed in
this section, except as follows:

(1) The ‘‘contents’’ entry on the label

may state ‘‘mixed’’ in place of the
names of the radionuclides unless each
inside package contains the same
radionuclide(s).

(2) The ‘‘activity’’ entry on the label

must be determined by adding together
the number of becquerels of the Class 7
(radioactive) materials packages con-
tained therein.

(3) For an overpack, the transport

index (TI) must be determined by add-
ing together the transport indices of
the Class 7 (radioactive) materials

VerDate Sep<11>2014

11:45 Oct 30, 2019

Jkt 247227

PO 00000

Frm 00420

Fmt 8010

Sfmt 8010

Q:\49\49V2.TXT

PC31

kpayne on VMOFRWIN702 with $$_JOB

background image

411

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.405

packages contained therein, except
that for a rigid overpack, the transport
index (TI) may alternatively be deter-
mined by direct measurement as pre-
scribed in § 173.403 of this subchapter
under the definition for ‘‘transport
index,’’ taken by the person initially
offering the packages contained within
the overpack for shipment.

(4) The category of Class 7 label for

the overpack must be determined from
the table in § 172.403(c) using the TI de-
rived according to paragraph (h)(3) of
this section, and the maximum radi-
ation level on the surface of the over-
pack.

(5) The category of the Class 7 label

of the overpack, and not that of any of
the packages contained therein, must
be used in accordance with Table 1 of
§ 172.504(e) to determine when the
transport vehicle must be placarded.

(6) For fissile material, the criti-

cality safety index which must be en-
tered on the overpack FISSILE label is
the sum of the criticality safety indi-
ces of the individual packages in the
overpack, as stated in the certificate of
approval for the package design issued
by the NRC or the U.S. Competent Au-
thority.

[Amdt. 172–29, 41 FR 15996, Apr. 15, 1976]

E

DITORIAL

N

OTE

: For F

EDERAL

R

EGISTER

ci-

tations affecting § 172.403, see the List of CFR
Sections Affected, which appears in the
Finding Aids section of the printed volume
and at

www.govinfo.gov.

§ 172.404

Labels for mixed and consoli-

dated packaging.

(a)

Mixed packaging. When compatible

hazardous materials having different
hazard classes are packed within the
same packaging, or within the same
outside container or overpack as de-
scribed in § 173.25, the packaging, out-
side container or overpack must be la-
beled as required for each class of haz-
ardous material contained therein.

(b)

Consolidated packaging. When two

or more packages containing compat-
ible hazardous materials are placed
within the same outside container or
overpack, the outside container or
overpack must be labeled as required
for each class of hazardous material
contained therein, unless labels rep-
resentative of each hazardous material

in the outside container or overpack
are visible.

(c)

Consolidation bins used by a single

motor carrier. Notwithstanding the pro-
visions of paragraph (b) of this section,
labeling of a consolidation bin is not
required under the following condi-
tions:

(1) The consolidation bin must be re-

usable, made of materials such as plas-
tic, wood, or metal and must have a ca-
pacity of 64 cubic feet or less;

(2) Hazardous material packages

placed in the consolidation bin must be
properly labeled in accordance with
this subpart;

(3) Packages must be compatible as

specified in § 177.848 of this subchapter;

(4) Packages may only be placed

within the consolidation bin and the
bin be loaded on a motor vehicle by an
employee of a single motor carrier;

(5) Packages must be secured within

the consolidation bin by other pack-
ages or by other suitable means in such
a manner as to prevent shifting of, or
significant relative motion between,
the packages that would likely com-
promise the integrity of any package;

(6) The consolidation bin must be

clearly and legibly marked on a tag or
fixed display device with an indication
of each hazard class or division con-
tained within the bin;

(7) The consolidation bin must be

properly blocked and braced within the
transport vehicle; and

(8) Consolidation bins may only be

transported by a single motor carrier,
or on railcars transporting such vehi-
cles.

[76 FR 43527, July 20, 2011]

§ 172.405

Authorized label modifica-

tions.

(a) For Classes 1, 2, 3, 4, 5, 6, and 8,

text indicating a hazard (for example
FLAMMABLE LIQUID) is not required
on a primary or subsidiary label.

(b) For a package containing Oxygen,

compressed, or Oxygen, refrigerated
liquid, the OXIDIZER label specified in
§ 172.426 of this subpart, modified to dis-
play the word ‘‘OXYGEN’’ instead of
‘‘OXIDIZER’’, and the class number
‘‘2’’ instead of ‘‘5.1’’, may be used in
place of the NON-FLAMMABLE GAS
and OXIDIZER labels. Notwithstanding
the provisions of paragraph (a) of this

VerDate Sep<11>2014

11:45 Oct 30, 2019

Jkt 247227

PO 00000

Frm 00421

Fmt 8010

Sfmt 8010

Q:\49\49V2.TXT

PC31

kpayne on VMOFRWIN702 with $$_JOB
