416

49 CFR Ch. I (10–1–19 Edition)

§ 172.415

(f) The EXPLOSIVE subsidiary label

must comply with § 172.407.

[Amdt. 172–123, 56 FR 66256, Dec. 20, 1991, as
amended by Amdt. 172–139, 59 FR 67490, Dec.
29, 1994; 66 FR 33425, June 21, 2001; 68 FR
45031, July 31, 2003]

§ 172.415

NON-FLAMMABLE GAS

label.

(a) Except for size and color, the

NON-FLAMMABLE GAS label must be
as follows:

(b) In addition to complying with

§ 172.407, the background color on the
NON-FLAMMABLE GAS label must be
green.

[Amdt. 172–123, 56 FR 66256, Dec. 20, 1991]

§ 172.416

POISON GAS label.

(a) Except for size and color, the POI-

SON GAS label must be as follows:

(b) In addition to complying with

§ 172.407, the background on the POI-
SON GAS label and the symbol must be
white. The background of the upper di-
amond must be black and the lower
point of the upper diamond must be 14
mm (0.54 inches) above the horizontal
center line.

[62 FR 39405, July 22, 1997]

§ 172.417

FLAMMABLE GAS label.

(a) Except for size and color, the

FLAMMABLE GAS label must be as
follows:
