49 CFR Ch. I (10–1–19 Edition)

§ 172.415

(f) The EXPLOSIVE subsidiary label

must comply with § 172.407.

[Amdt. 172–123, 56 FR 66256, Dec. 20, 1991, as
amended by Amdt. 172–139, 59 FR 67490, Dec.
29, 1994; 66 FR 33425, June 21, 2001; 68 FR
45031, July 31, 2003]

§ 172.415

NON-FLAMMABLE GAS

label.

(a) Except for size and color, the

NON-FLAMMABLE GAS label must be
as follows:

(b) In addition to complying with

§ 172.407, the background color on the
NON-FLAMMABLE GAS label must be
green.

[Amdt. 172–123, 56 FR 66256, Dec. 20, 1991]

§ 172.416

POISON GAS label.

(a) Except for size and color, the POI-

SON GAS label must be as follows:

(b) In addition to complying with

§ 172.407, the background on the POI-
SON GAS label and the symbol must be
white. The background of the upper di-
amond must be black and the lower
point of the upper diamond must be 14
mm (0.54 inches) above the horizontal
center line.

[62 FR 39405, July 22, 1997]

§ 172.417

FLAMMABLE GAS label.

(a) Except for size and color, the

FLAMMABLE GAS label must be as
follows:

VerDate Sep<11>2014

11:45 Oct 30, 2019

Jkt 247227

PO 00000

Frm 00426

Fmt 8010

Sfmt 8010

Q:\49\49V2.TXT

PC31

ER31jy03.002</GPH>

EC02MR91.020</GPH>

ER22JY97.022</GPH>

EC02MR91.022</GPH>

kpayne on VMOFRWIN702 with $$_JOB

background image

417

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.423

(b) In addition to complying with

§ 172.407, the background color on the
FLAMMABLE GAS label must be red.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.419

FLAMMABLE LIQUID label.

(a) Except for size and color the

FLAMMABLE LIQUID label must be as
follows:

(b) In addition to complying with

§ 172.407, the background color on the
FLAMMABLE LIQUID label must be
red.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.420

FLAMMABLE SOLID label.

(a) Except for size and color, the

FLAMMABLE SOLID label must be as
follows:

(b) In addition to complying with

§ 172.407, the background on the FLAM-
MABLE SOLID label must be white
with vertical red stripes equally spaced
on each side of a red stripe placed in
the center of the label. The red vertical
stripes must be spaced so that, vis-
ually, they appear equal in width to
the white spaces between them. The
symbol (flame) and text (when used)
must be overprinted. The text ‘‘FLAM-
MABLE SOLID’’ may be placed in a
white rectangle.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.422

SPONTANEOUSLY COMBUS-

TIBLE label.

(a) Except for size and color, the

SPONTANEOUSLY COMBUSTIBLE
label must be as follows:

(b) In addition to complying with

§ 172.407, the background color on the
lower half of the SPONTANEOUSLY
COMBUSTIBLE label must be red and
the upper half must be white.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991, as
amended at 57 FR 45458, Oct. 1, 1992]

§ 172.423

DANGEROUS WHEN WET

label.

(a) Except for size and color, the

DANGEROUS WHEN WET label must
be as follows:
