Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.420

NON-FLAMMABLE GAS label must be
green.

[Amdt. 172–123, 56 FR 66256, Dec. 20, 1991]

§ 172.416

POISON GAS label.

(a) Except for size and color, the POI-

SON GAS label must be as follows:

(b) In addition to complying with

§ 172.407, the background on the POI-
SON GAS label and the symbol must be
white. The background of the upper di-
amond must be black and the lower
point of the upper diamond must be 14
mm (0.54 inches) above the horizontal
center line.

[62 FR 39405, July 22, 1997]

§ 172.417

FLAMMABLE GAS label.

(a) Except for size and color, the

FLAMMABLE GAS label must be as
follows:

(b) In addition to complying with

§ 172.407, the background color on the
FLAMMABLE GAS label must be red.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.419

FLAMMABLE LIQUID label.

(a) Except for size and color the

FLAMMABLE LIQUID label must be as
follows:

(b) In addition to complying with

§ 172.407, the background color on the
FLAMMABLE LIQUID label must be
red.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.420

FLAMMABLE SOLID label.

(a) Except for size and color, the

FLAMMABLE SOLID label must be as
follows:
