428

49 CFR Ch. I (10–1–23 Edition)

§ 172.422

(b) In addition to complying with

§ 172.407, the background on the FLAM-
MABLE SOLID label must be white
with vertical red stripes equally spaced
on each side of a red stripe placed in
the center of the label. The red vertical
stripes must be spaced so that, vis-
ually, they appear equal in width to
the white spaces between them. The
symbol (flame) and text (when used)
must be overprinted. The text ‘‘FLAM-
MABLE SOLID’’ may be placed in a
white rectangle.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.422

SPONTANEOUSLY COMBUS-

TIBLE label.

(a) Except for size and color, the

SPONTANEOUSLY COMBUSTIBLE
label must be as follows:

(b) In addition to complying with

§ 172.407, the background color on the
lower half of the SPONTANEOUSLY
COMBUSTIBLE label must be red and
the upper half must be white.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991, as
amended at 57 FR 45458, Oct. 1, 1992]

§ 172.423

DANGEROUS WHEN WET

label.

(a) Except for size and color, the

DANGEROUS WHEN WET label must
be as follows:

(b) In addition to complying with

§ 172.407, the background color on the
DANGEROUS WHEN WET label must
be blue.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.426

OXIDIZER label.

(a) Except for size and color, the OXI-

DIZER label must be as follows:

(b) In addition to complying with

§ 172.407, the background color on the
OXIDIZER label must be yellow.

[Amdt. 172–123, 56 FR 66257, Dec. 20, 1991]

§ 172.427

ORGANIC PEROXIDE label.

(a) Except for size and color, the OR-

GANIC PEROXIDE label must be as
follows:

429

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.427

430

49 CFR Ch. I (10–1–23 Edition)

§ 172.429

(b) In addition to complying with

§ 172.407, the background on the OR-
GANIC PEROXIDE label must be red in
the top half and yellow in the lower
half.

[71 FR 78627, Dec. 29, 2006]

§ 172.429

POISON INHALATION HAZ-

ARD label.

(a) Except for size and color, the POI-

SON INHALATION HAZARD label
must be as follows:

(b) In addition to complying with

§ 172.407, the background on the POI-
SON INHALATION HAZARD label and
the symbol must be white. The back-
ground of the upper diamond must be
black and the lower point of the upper
diamond must be 14 mm (0.54 inches)
above the horizontal center line.

[62 FR 39406, July 22, 1997]

§ 172.430

POISON label.

(a) Except for size and color, the POI-

SON label must be as follows:

(b) In addition to complying with

§ 172.407, the background on the POI-
SON label must be white. The word
‘‘TOXIC’’ may be used in lieu of the
word ‘‘POISON’’.

[Amdt. 172–123, 56 FR 66258, Dec. 20, 1991, as
amended by Amdt. 172–139, 59 FR 67490, Dec.
29, 1994]

§ 172.431

[Reserved]

§ 172.432

INFECTIOUS SUBSTANCE

label.

(a) Except for size and color, the IN-

FECTIOUS SUBSTANCE label must be
as follows:

(b) In addition to complying with

§ 172.407, the background on the INFEC-
TIOUS SUBSTANCE label must be
white.

(c) Labels conforming to require-

ments in place on August 18, 2011 may
