445

Pipeline and Haz. Matls. Safety Admin., DOT

§ 172.532

(b) In addition to meeting the re-

quirements of § 172.519 for minimum du-
rability and strength, the square back-
ground must consist of a white square
measuring 14

1

⁄

4

inches (362.0 mm.) on

each side surrounded by a black border
extending to 15

1

⁄

4

inches (387.0 mm.) on

each side.

[Amdt. 172–29, 41 FR 15996, Apr. 15, 1976, as
amended by Amdt. 172–64, 46 FR 5316, Jan. 19,
1981; Amdt. 172–78, 48 FR 10226, Mar. 10, 1983]

§ 172.528

NON-FLAMMABLE GAS

placard.

(a) Except for size and color, the

NON-FLAMMABLE GAS placard must
be as follows:

(b) In addition to complying with

§ 172.519, the background color on the
NON-FLAMMABLE GAS placard must
be green. The letters in both words
must be at least 38 mm (1.5 inches)

high. The symbol, text, class number
and inner border must be white.

[Amdt. 172–123, 56 FR 66261, Dec. 20, 1991]

§ 172.530

OXYGEN placard.

(a) Except for size and color, the OX-

YGEN placard must be as follows:

(b) In addition to complying with

§ 172.519 of this subpart, the background
color on the OXYGEN placard must be
yellow. The symbol, text, class number
and inner border must be black.

[Amdt. 172–123, 56 FR 66262, Dec. 20, 1991]

§ 172.532

FLAMMABLE GAS placard.

(a) Except for size and color, the

FLAMMABLE GAS placard must be as
follows:

(b) In addition to complying with

§ 172.519, the background color on the

446

49 CFR Ch. I (10–1–23 Edition)

§ 172.536

FLAMMABLE GAS placard must be
red. The symbol, text, class number
and inner border must be white.

[Amdt. 172–123, 56 FR 66262, Dec. 20, 1991]

§ 172.536

[Reserved]

§ 172.540

POISON GAS placard.

(a) Except for size and color, the POI-

SON GAS placard must be as follows:

(b) In addition to complying with

§ 172.519, the background on the POI-
SON GAS placard and the symbol must
be white. The background of the upper
diamond must be black and the lower
point of the upper diamond must be 65
mm (2

5

⁄

8

inches) above the horizontal

center line. The text, class number,
and inner border must be black.

[62 FR 39408, July 22, 1997]

§ 172.542

FLAMMABLE placard.

(a) Except for size and color, the

FLAMMABLE placard must be as fol-
lows:

(b) In addition to complying with

§ 172.519, the background color on the
FLAMMABLE placard must be red.
The symbol, text, class number and
inner border must be white.

(c) The word ‘‘GASOLINE’’ may be

used in place of the word ‘‘FLAM-
MABLE’’ on a placard that is displayed
on a cargo tank or a portable tank
being used to transport gasoline by
highway. The word ‘‘GASOLINE’’ must
be shown in white.

[Amdt. 172–123, 56 FR 66262, Dec. 20, 1991]

§ 172.544

COMBUSTIBLE placard.

(a) Except for size and color, the

COMBUSTIBLE placard must be as fol-
lows:

(b) In addition to complying with

§ 172.519, the background color on the
COMBUSTIBLE placard must be red.
