(3) A rail carrier need not perform a

rail transportation route analysis, al-
ternative route analysis, or route se-
lection process for any hazardous ma-
terial other than the materials speci-
fied in paragraph (a) of this section.

(g)

Rail carrier point of contact on rout-

ing issues.

Each rail carrier must iden-

tify a point of contact (including the
name, title, phone number and e-mail
address) on routing issues involving
the movement of materials covered by
this section in its security plan and
provide this information to:

(1) State and/or regional Fusion Cen-

ters that have been established to co-
ordinate with state, local and tribal of-
ficials on security issues and which are
located within the area encompassed
by the rail carrier’s rail system; and

(2) State, local, and tribal officials in

jurisdictions that may be affected by a
rail carrier’s routing decisions and who
directly contact the railroad to discuss
routing decisions.

(h)

Storage, delays in transit, and noti-

fication.

With respect to the materials

specified in paragraph (a) of this sec-
tion, each rail carrier must ensure the
safety and security plan it develops
and implements under this subpart in-
cludes all of the following:

(1) A procedure under which the rail

carrier must consult with offerors and
consignees in order to develop meas-
ures for minimizing, to the extent
practicable, the duration of any stor-
age of the material incidental to move-
ment (see § 171.8 of this subchapter).

(2) Measures to prevent unauthorized

access to the materials during storage
or delays in transit.

(3) Measures to mitigate risk to pop-

ulation centers associated with in-
transit storage.

(4) Measures to be taken in the event

of an escalating threat level for mate-
rials stored in transit.

(5) Procedures for notifying the con-

signee in the event of a significant
delay during transportation; such noti-
fication must be completed within 48
hours after the carrier has identified
the delay and must include a revised
delivery schedule. A significant delay
is one that compromises the safety or
security of the hazardous material or
delays the shipment beyond its normal
expected or planned shipping time. No-

tification should be made by a method
acceptable to both the rail carrier and
consignee.

(i)

Recordkeeping.

(1) Each rail carrier

must maintain a copy of the informa-
tion specified in paragraphs (b), (c), (d),
(e), and (f) of this section (or an elec-
tronic image thereof) that is accessible
at, or through, its principal place of
business and must make the record
available upon request, at a reasonable
time and location, to an authorized of-
ficial of the Department of Transpor-
tation or the Department of Homeland
Security. Records must be retained for
a minimum of two years.

(2) Each rail carrier must restrict the

distribution, disclosure, and avail-
ability of information collected or de-
veloped in accordance with paragraphs
(c), (d), (e), and (f) of this section to
covered persons with a need-to-know,
as described in parts 15 and 1520 of this
title.

(j)

Compliance and enforcement.

If the

carrier’s route selection documenta-
tion and underlying analyses are found
to be deficient, the carrier may be re-
quired to revise the analyses or make
changes in route selection. If DOT finds
that a chosen route is not the safest
and most secure practicable route
available, the FRA Associate Adminis-
trator for Safety, in consultation with
TSA, may require the use of an alter-
native route. Prior to making such a
determination, FRA and TSA will con-
sult with the Surface Transportation
Board (STB) regarding whether the
contemplated alternative route(s)
would be economically practicable.

[73 FR 20771, Apr. 16, 2008, as amended at 73
FR 72193, Dec. 26, 2008; 76 FR 56314, Sept. 13,
2011; 80 FR 26746, May 8, 2015; 85 FR 45029,
July 24, 2020]

§ 172.822

Limitation on actions by

states, local governments, and In-
dian tribes.

A law, order, or other directive of a

state, political subdivision of a state,
or an Indian tribe that designates, lim-
its, or prohibits the use of a rail line
(other than a rail line owned by a
state, political subdivision of a state,
or an Indian tribe) for the transpor-
tation of hazardous materials, includ-
ing, but not limited to, the materials

background image

463

Pipeline and Haz. Matls. Safety Admin., DOT

Pt. 172, App. A

specified in § 172.820(a), is preempted. 49
U.S.C. 5125, 20106.

[73 FR 20772, Apr. 16, 2008]

A

PPENDIX

TO

P

ART

172—O

FFICE OF



H

AZARDOUS

M

ATERIALS

T

RANSPOR

-

TATION

C

OLOR

T

OLERANCE

C

HARTS



AND

T

ABLES



The following are Munsell notations and

Commission Internationale de L’Eclairage
(CIE) coordinates which describe the Office
of Hazardous Materials Transportation Label
and Placard Color Tolerance Charts in tables
1 and 2, and the CIE coordinates for the color
tolerances specified in table 3. Central colors

and tolerances described in table 2 approxi-
mate those described in table 1 while allow-
ing for differences in production methods
and materials used to manufacture labels
and placards surfaced with printing inks.
Primarily, the color charts based on table 1
are for label or placard colors applied as
opaque coatings such as paint, enamel or
plastic, whereas color charts based on table
2 are intended for use with labels and plac-
ards surfaced only with inks.

For labels printed directly on packaging

surfaces, table 3 may be used, although com-
pliance with either table 1 or table 2 is suffi-
cient. However, if visual reference indicates
that the colors of labels printed directly on
package surfaces are outside the table 1 or 2
tolerances, a spectrophotometer or other in-
strumentation may be required to insure
compliance with table 3.

T

ABLE

1—S

PECIFICATIONS FOR

C

OLOR

T

OLERANCE

C

HARTS FOR

U

SE

W

ITH

L

ABELS AND

P

LACARDS



S

URFACED

W

ITH

P

AINT

, L

ACQUER

, E

NAMEL

, P

LASTIC

, O

THER

O

PAQUE

C

OATINGS

OR

I

NK

1



Color

Munsell notations

CIE data for source C

Red:

Central color ................................................................

7.5R 4.0/14 ....................................

12.00

.5959

.3269

Orange .........................................................................

8.5R 4.0/14 ....................................

12.00

.6037

.3389

Purple and vivid ...........................................................

6.5R 4.0/14 ....................................

12.00

.5869

.3184

Grayish ........................................................................

7.5R 4.0/12 ....................................

12.00

.5603

.3321

Vivid .............................................................................

7.5R 4.0/16 ....................................

12.00

.6260

.3192

Light .............................................................................

7.5R 4.5/14 ....................................

15.57

.5775

.3320

Dark .............................................................................

7. 5R 3.5/14 ...................................

09.00

.6226

.3141

Orange:

Central color ................................................................

5.OYR 6.0/15 .................................

30.05

.5510

.4214

Yellow and Grayish .....................................................

6.25YR 6.0/15 ................................

30.05

.5452

.4329

Red and vivid ..............................................................

3.75YR 6.0/15 ................................

30.05

.5552

.4091

Grayish ........................................................................

5.OYR 6.0/13 .................................

30.05

.5311

.4154

Vivid .............................................................................

5.OYR 6.0/16 .................................

30.05

.5597

.4239

Light .............................................................................

5.OYR 6.5/15 .................................

36.20

.5427

.4206

Dark .............................................................................

5.OYR 5.5/15 .................................

24.58

.5606

.4218

Yellow:

Central color ................................................................

5.OY 8.0/12 ....................................

59.10

.4562

.4788

Green ...........................................................................

6.5Y 8.0/12 .....................................

59.10

.4498

.4865

Orange and vivid .........................................................

3.5Y 8.0/12 .....................................

59.10

.4632

.4669

Grayish ........................................................................

5.OY 8.0/10 ....................................

59.10

.4376

.4601

Vivid .............................................................................

5.OY 8.0/14 ....................................

59.10

.4699

.4920

Light .............................................................................

5.OY 8.5/12 ....................................

68.40

.4508

.4754

Dark .............................................................................

5.OY 7.5/12 ....................................

50.68

.4620

.4823

Green:

Central color ................................................................

7.5G 4.0/9 ......................................

12.00

.2111

.4121

Bluish ...........................................................................

0.5BG 4.0/9 ....................................

12.00

.1974

.3809

Green-yellow ...............................................................

5.0G 4.0/9 ......................................

12.00

.2237

.4399

Grayish A .....................................................................

7.5G 4.0/7 ......................................

12.00

.2350

.3922

Grayish B

2

...................................................................

7.5G 4.0/6 ......................................

12.00

.2467

.3822

Vivid .............................................................................

7.5G 4.0/11 ....................................

12.00

.1848

.4319

Light .............................................................................

7.5G 4.5/9 ......................................

15.57

.2204

.4060

Dark .............................................................................

7.5G 3.5/9 ......................................

09.00

.2027

.4163

Blue:

Central color ................................................................

2.5PB 3.5/10 ..................................

09.00

.1691

.1744

Purple ..........................................................................

4.5PB 3.5/10 ..................................

09.00

.1796

.1711

Green and vivid ...........................................................

10.0B 3.5/10 ...................................

09.00

.1557

.1815

Grayish ........................................................................

2.5PB 3.5/8 ....................................

09.00

.1888

.1964

Vivid .............................................................................

2.5PB 3.5/12 ..................................

09.00

.1516

.1547

Light .............................................................................

2.5PB 4.0/10 ..................................

12.00

.1805

.1888

Dark .............................................................................

2.5PB 3.0/10 ..................................

06.55

.1576

.1600

Purple:

Central color ................................................................

10.0P 4.5/10 ...................................

15.57

.3307

.2245

Reddish purple ............................................................

2.5RP 4.5/10 ..................................

15.57

.3584

.2377

Blue purple ..................................................................

7.5P 4.5/10 .....................................

15.57

.3068

.2145

Reddish gray ...............................................................

10.0P 4.5/8 .....................................

15.57

.3280

.2391
